1. INSTALLATION
The following illustration shows a typical installation. If you have any questions or require information
regarding installation kits, consult your customer car audio dealer or a company suppling kits.
If you are not sure how to install this unit correctly, have it installed by a qualified technician.
To attach the front panel back to the unit chassis,
please insert
the
of
Remove the unit
1. Press the Panel Release button.
2. Push the left side of the panel rightward
3. Pull the panel towards you to disengage it from the chassis.
2
the right side of the panel in
chassis until it is correctly
engaged. Press the left side
the panel until the mechanism
locks it into place.
4
1
2
3
Tr i m
Plate
Panel
EN - 1
1
1 11 m
Dashboard
Sleeve
(Not supplied with this unit)
Bend the appropriate
tabs to hold the sleeve
firmly in place.
m
