OWNER'S MANUAL
AIR PURIFIER
Read before using product (safety instruction), use properly.
About ensuring users safety and property.
Product warranty card is enclosed with the user manual.
After careful read through the user manual, do keep it in a handy place.
PS-S200 Series
P/No.: MFL31040016
Made in Korea
www.lg.com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for LG PS-S200WC
Summary of Contents for LG PS-S200WC
- Page 1 Read before using product (safety instruction), use properly. About ensuring users safety and property. Product warranty card is enclosed with the user manual. After careful read through the user manual, do keep it in a handy place. PS-S200 Series www.lg.com P/No.: MFL31040016 Made in Korea...
-
Page 2: The Advantages Are
By following the use and care instructions in this manual, your air purifier will provide you with many years of reliable service. Easy to use HEPA filter system. - Filter cleaning is easy with LG's convenient filter separation system. - Filters can be washed over and over again. Quiet Operation - Minimum noise levels for a better nights rest. -
Page 3: Table Of Contents
Table of Contents Getting Started Care and Cleaning ❏ The advantages are .............2 ❏ Filter cleaning ...............22~23 ❏ Safety Precautions ............4~13 ❏ Exterior cleaning and Storage ..........24 ❏ Installation ................14 ❏ Troubleshooting before calling for service....25~26 ❏ How to Use.................15 ❏... -
Page 4: Safety Precautions
Safety Precautions For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death. Warning / Caution This symbol will alert you to any product detail or operation that could lead to a safety hazard if the instructions in the manual are not followed properly. - Page 5 Safety Precautions Warning Installation If the power cord becomes worn Do not plug other appliances Do not remove the round or damaged, the cord should into the same outlet. grounding plug prong from only be replaced by a qualified Overloading of any outlet can the plug.
- Page 6 Safety Precautions Do not use this or any appliance If you hear abnormal sounds or Make sure the unit and cord are near flammable gases or liquids, smell smoke, immediately unplug positioned where it does not liquids or other combustibles your unit and the unit checked by create a tipping hazard.
- Page 7 Safety Precautions Operation Make sure the power Do not operate with wet If the power cord ever Never pull the power plug cord is plugged firmly hands. becomes frayed or away from the outlet by and completely into the damaged, do not attempt pulling on the wire.
- Page 8 Safety Precautions Keep objects such as curtains Do not run power cords under Do not place the power cord or away from the air opening in the carpeting or other coverings which unit near a heater, radiator, or unit. The openings must be free could fray the cord and expose the any other heat source.
- Page 9 Safety Precautions Do not move the unit by pulling or Do not use the top of the unit for Other then cleaning and pushing on the front panel. storage. Keep liquids away from replacing the filters, there are no the top of the unit. user replaceable components in your unit.
- Page 10 Safety Precautions Cautions Installation When using the unit, maintain a Avoid installing the unit in direct Never use your unit to remove distance of at least 3 feet sunlight and never operate the toxic gasses such as Carbon between the unit and any unit near or around open flames Monoxide, Natural or Liquefied television or audio product.
- Page 11 Safety Precautions Do not use except AC 220-240 V. This unit is not designed to Your unit is not designed to be Otherwise, it may cause fire or electrical remove combustion by products used in moving vehicles such as shock. such as those produced by open cars, RV's or boats.
- Page 12 Safety Precautions Operation To prevent damage to plants or Clean with a soft cloth and mild Do not start or stop operation injury to pets, make sure they are detergent. Filter should be by plugging or unplugging the not exposed to direct air flow from cleaned monthly.
-
Page 13: Safety Precautions
Safety Precautions A damaged filter can create an If a humidifier is used in the same Do not use your unit to remove electrical hazard. room as your unit, keep the food odors while cooking. humidifier a safe distance away Airborne oils that are released from the humidifier could clog the during cooking will clog the... -
Page 14: Installation
Installation Place to Install t u o 1. Plug power cord into its own dedicated properly grounded outlet. 2. Make sure the power cord is positioned where it does not cause a tripping hazard and will receive adequate ventilation. Do not install your unit directly next to furniture or objects that could block the vent openings. -
Page 15: How To Use
How to Use Cleaning the Air Purifier • The air filter should be cleaned on a regular basis. Depending on the air quality, more frequent cleaning maybe required. • The filter can be washed in warm water using a mild detergent. •... -
Page 16: Key Parts And Components
Key Parts and Components Mainframe Pre-filter Front panel Power plug Deodorizer sensor part Operation Mode Button Air Purifier... -
Page 17: Display And Control Panel
Key Parts and Components Display and Control Panel Operation mode indicator AUTO TURBO SLEEP Operation Mode Button Clean Air Indicator Light This is the button to change The indicator light will show the quality of the the operating mode. air in the surrounding area. A white indicator light indicates clean air and a low fan speed. -
Page 18: Filter System
Key Parts and Components Pre-filter HEPA filter Deodorizer filter Filter system (This is the introduction of only the filter part.) Filter name Function Cleaning and replacement frequency Nano silver antibacterial Nano silver antibacterial This filter enables 2 roles of antibacterial process and removal Pre-filter of large dust particles with only one filter to extent the washing Clean frequency of about 1 month... -
Page 19: Operation
Operation Air Purifying Operation Purify Indoor Air. Press Operation Mode Button • Turns the unit on and off. Press once to turn on, again to turn off. • A confirmation tone will sound to indicate that the unit is powering on or turning off. The unit will also produce a tone when the unit is first plugged in. - Page 20 Operation Automatic Mode Air Purifier will automatically set the most appropriate Fan speed. Select Auto Mode by pressing the Operation Mode button. • The Operation Mode button will switch from one setting to the next by repeatedly pressing the Operation Mode button. AUTO TURBO SLEEP...
-
Page 21: Operation
Operation Turbo Mode The air purifier operates at maximum fan level. Select Turbo Mode by pressing the Operation Mode button. • When you press the Operation Mode button, it will switch in the AUTO TURBO SLEEP order of AUTO TURBO SLEEP STOP repeatedly. -
Page 22: Filter Cleaning
Filter Cleaning • Filter maintenance may vary depending on the environment. Turn unit off and unplug before cleaning. Open the front panel. Front panel When disassembling Remove the filter from the mainframe by pulling the handle near the center of the filter. - Page 23 Filter Cleaning Clean the Pre-filter with a vacuum cleaner or a soft brush. (Clean the filter every a month.) Clean the Pre-filter with a vacuum cleaner or a soft brush, and when the contamination is severe, use a neutral detergent and water to clean it off. To clean both the HEPA filter and the Deodorizing filter, soak the filter in warm water with a mild detergent for 1 hour.
-
Page 24: Exterior Cleaning And Storage
Exterior cleaning and Storage Exterior Cleaning Method Wipe the exterior of the unit with a soft cloth using warm water and a mild detergent. • Do not use harsh cleaners or very hot water. Do not wash in the dishwasher. Caution •... -
Page 25: Troubleshooting Before Calling For Service
Is the power plug unplugged? Plug the power properly. start. Is the fuse disconnected? Request service to the LG Electronics Service Center. Is the power shut down? Re-operate the product after the power is reconnected. Is the front panel open? When the front panel is open, the product will not operate. -
Page 26: Troubleshooting Before Calling For Service
Sensor Indicator Is the sensor working properly? LG Air Cleaner odor sensor is the sensor to detect the contaminated gas and sometimes may not react to the food smell (Korean food such as Kimchi, soybean paste, Chunggukjang etc.). -
Page 27: Product Specification
Product Specification The external dimension, design and product standard can change to improve the quality of the product. Model Name PS-S200 Series Power Supply 220-240 V~ 50/60 Hz Effective Space 20 m Weight of Product 7.2 kg Appearance Size(mm) 372 (W) X 463 (H) X 199 (D) Power consumption 18 W Owner’s Manual...
