Instructions for use: CombBind C110e
Getting Started
• Plug the power cord into an appropriate power receptacle
Determine Sheet Width (fig. A)
• Rotate the edge guide to the paper / cover size you wish to bind:
- Letter (8-1/2" x 11")
- A4 (297mm x 210mm)
- Oversized (222mm x 286mm)
Punching Paper (fig. B)
To turn the machine "ON" press the ON / OFF (I/O) switch located in
the rear of the machine. A green light will illuminate to indicate that
the power is on.
Jog or align the sheets or covers and insert the edge to be punched
into the punch throat opening.
Fully insert the sheets into the throat opening and against the edge
guide.
To punch, press the punch button
punch up to 15 sheets of 80 gsm paper. Do not punch more than 1
clear cover at a time to prevent jams.
Determine Plastic Comb Size (fig. C)
Rotate the binding handle towards you to open the hooks away
from the comb support.
Place the document including the covers straight up against the
comb support to the right side aligning with the binding size scale.
Rotate the binding lever away from you to close the hooks until they
make contact with the document.
Binding (fig. D)
Place the plastic comb binding element behind the vertical comb
with the open portion of the element facing you.
Rotate the binding lever toward you until the comb binding element
opens sufficiently to insert your document.
Place the front cover (finished side down) onto the opened binding
element fingers. Place the document pages (face down) onto the
element. Repeat for larger documents as required. Place the back
cover (finished side up) on the open binding element fingers last.
Empty Chip Drawer (fig. E)
• Your CombBind C110e has a chip drawer located on the right side of
the machine.
• When it is full of punched paper chips, a red light
illuminate.
. The CombBind C110e will
(fig. B) will
• When using oversized covers, rotate the edge guide to the oversize
position, punch all of the covers for your documents and set aside.
• Rotate the edge guide to either Letter or A4 position and punch the
paper for your document.
If the punch jams the red jam light
that the machine has jammed. The machine will automatically
reverse the punches to clear the jam and the red jam light will
remain illuminated. Remove the paper and push the punch button
to re-set the machine. The red jam light will turn off indicating that
the machine is ready to punch. Reduce some of the sheets and
repeat steps 2 to 4 to avoid jams on additional lifts.
When finished punching turn the machine OFF by pressing the
ON / OFF (I/O) switch located at the rear of the machine.
Read the line closest to the document follow it to the right to the
corresponding comb binding element size. This is the comb binding
element size required to bind the document. Your CombBind C110e
can bind books up to 330 sheets (38mm). For best results, always
use GBC brand covers with GBC color-coordinated binding combs.
Rotate the binding lever away from you, back to its original position
to close the binding element.
Remove the book by lifting upward. Your document is now
complete.
Once you become familiar with your CombBind C110e you will find
that you can bind as you punch, increasing your productivity.
• Gently pull the drawer to open it and remove from machine, empty
and re-insert the drawer back in machine until it snaps in place.
will illuminate to indicate
