Page 1: User Guide
" 24 Wide TFT LCD Monitor USER GUIDE Model EQ246P In order to avoid accident and risk Please “ ” read the Important safety notice to know how to use the monitor before using. -
Page 3: Safety Precautions And Maintenance
Safety Precautions and Maintenance Read this manual carefully and retain for future reference 1 Unplug the monitor before cleaning it with a slightly damp cloth 2 Wiping the screen with a dry cloth is recommendable and only during the power has been switched off 3 Do not use alcohol or ammonia based liquids 4 This monitor is designed with ventilation holes on the cabinet back please do not cover them or block it 5 Also avoid placing the monitor near the electric heater or heater including in an enclosed room with no... -
Page 4: Basic Setup
Basic setup a Insert the VGA cable signal cord to the PC graphic card signal input DC connector VGA connector Audio connector ～ b The monitor has a wide power voltage range it can be used on AC100 240V 50 60Hz power supply c Connect the power cable to the Monitor power socket and to the power source in the room... - Page 5 Functions: Press the MENU Buttion Then the main menu of the appears PICTURE TRACKING SETUP COLOR Main Menu PICTURE Press MENU button the main menu will appear as follows Press UP DOWN button to select PICTURE in the main menu then press MENU button to enter PICTURE...
- Page 6 COLOR Press UP DOWN button to select COLOR in the main menu then press MENU button to enter COLOR PRESET 5400K 6500K 9300K GREEN BLUE PRESET Press UP DOWN button to select Preset then press MENU button confirmation choice And press VOL+ VOL- button to adjust Press...
- Page 7 H Position Press UP DOWN button to select H Position then press MENU button confirmation choice and Press VOL+ button image toward the right migration Press VOL- button image toward the left migration V Position Press UP DOWN button to select V Position then press MENU...
- Page 8 LANGUAGE Press UP DOWN button to select Language then press MENU button confirmation choice and press VOL+ VOL- button to adjust HORIZONTAL Press UP DOWN button to select Horizontal then press MENU button confirmation choice and Press VOL+ button OSD toward the right migration Press VOL- button OSD toward the left migration...
- Page 9 Other function LOCKED 【 】 Press MENU key to long term OSD LOCKED UNLOCKED 【 】key to long term OSD UNLOCKED Then press MENU...
-
Page 10: Troubleshooting
Troubleshooting 1 NO Image on Screen a Check if the power button has been switched on b Verify the brightness and contrast of the monitor is within the normal setting d If the signal indicator is notebook or laptop make sure that the signal has been switched to screen mode. -
Page 11: Specifications
SPECIFICATIONS: Dimension 24 Inch Monitor type Brightness 300cd/m Color 16.7M Resolutions 1920x1080 60Hz Speaker 2 2W Power requirement 100-240V 50/60Hz Power Mains adapter DC12V <60W Power consumption 15pins D-Sub Input connector Audio Input 1 Audio terminal black color Operation Temp: 0 -40 C Humidity Less than 80 Environment Storage Temp: -20 -60 C...
