DVD Player
Service
Service Manual
TABLE OF CONTENTS
. Technical Specifications.............................................................1-2
. Safety Instruction, Warning & Notes............................................1-3
. Mechanical and Dismantling Instructions.........................................2-1
. Region Code, Software Version& Upgrades...................................
. Trouble Shooting Chart..........................................................
. Wiring Diagram.......................................................................5-1
. Electrical Diagrams and Print-layouts...........................................
. Set Mechanical Exploded View ......................................................
. Revision List............................................................................
©Copyright 2007 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by TCL-ET 0734 Service Audio
Version 1.1
Printed in The Netherlands
Subject to modification
DVP3156, DVP3160K DVP3166(K)
DVP3160K/55/77/78
DVP3166/94,DVP3166X/94
DVP3166K/93
Page
3-1
.
.
4-1
..
.
6-1
...
7-1
.....
8-1
...
LASER PRODUCT
GB
PHILIPS
DVP3156/93
CLASS 1
3139 785 32471
