Inter-m PA-6000A Specification

PA
- 6000A
PUBLIC ADDRESS AMPLIFIER
FEATURES
A public Address amplifier with rated output of 240W
SIX INPUT CHANNELS WITH ADJUSTABLE INPUT
SENSITIVITY AND INDIVIDUAL LEVEL CONTROLS
Rear-panel level controls adjust each input
channel from Mic to Aux level.
FIVE-BAND GRAPHIC EQUALIZER
Five-band graphic equalizer allows you to shape
the tonal balance of your program material.
SPEAKER SELECT
Six speaker select switches enable you to select
any combination of up to five speakers.
PHONO LEVEL INPUT
(CD LEVEL SOURCE FOR USA/CANADA & ASSOCIATED VERSION)
Switchable input level on Channel 6 allows for
connection of phono level source.
ANNOUNCEMENT CHIME AND SIREN
Convenient four-tone chime and electronic siren
for use with announcements.
EXTERNAL MUTE FUNCTION
TELEPHONE INPUT FUNCTION
SPECIFICATIONS
ELECTRICAL
·Rated Output (RMS) .............................................240W
·Frequency Response ..............CH1~CH6:120Hz-10kHz
....................................................Telephone In:330Hz-3.3kHz
............................Link In:80Hz-12kHz, Amp In:60Hz-15kHz
·T.H.D ........................CH 1~CH 6, Phono:Less than 1%
...................................Telephone In, Link In:Less than 0.5%
............................................................Amp In:Less than 0.5%
·S/N ......................................CH1~CH6:more than 50dB
...........Phono(CD for USA/CANADA):more than 55dB(more than 70dB)
..................................Telephone In, Link In:more than 65dB
...........................................................Amp In:more than 95dB
·Graphic Equalizer.................................................±12dB
..........................................(100Hz,330Hz, 1kHz, 3.3kHz, 10kHz)
·Input Sensitivity/Impedance ..CH 1~CH 6:-70~-22dB/600Ω
..............Phono(CD for USA/CANADA):-54dB/22kΩ(-6dB/20kΩ)
....................................................................Link In-20dB/15kΩ
·Telephone In .......EC & Associated:-2dB(0.775V)/600Ω
.................USA/CANADA & Associated:-10dB(0.3V)/600Ω
...................................................................Amp In:0dB/4700Ω
·Speaker Output/Impedance ...EC & Associated:4Ω/30V
...USA/CANADA & Associated:4Ω/30V, 8Ω/43V, 21Ω/70V
·Amp Out/Impedance ......................................0dB/600Ω
·Link Out/Impedance ......................................-6dB/600Ω
GENERAL
·Power Source....AC 100-120VAC or 220-240VAC, 50/60Hz
(supplied AC mains transformer depends on country requirements)
·Power Consumption..............................................240W
·Weight.....................................................13.5kg/29.76lb
·Dimensions .........................420(W)x133(H)x320(D)mm
..................................................16.5(W)x5.2(H)x12.5(D)in
