Summary of Contents for Indesit IWD 61450

  • Page 1: Table Of Contents

    Table of wash cycles Personalisation, 9 Setting the temperature Setting the spin speed Functions Detergents and laundry, 10 Detergent dispenser drawer IWD 61450 Bleach cycle Preparing the laundry Garments requiring special care Load balancing system Precautions and tips, 11 General safety...
  • Page 2: Installation

    Installation Levelling the machine correctly will provide it with stability, This instruction manual should be kept in a safe place for help to avoid vibrations and excessive noise and prevent it future reference. If the washing machine is sold, transferred from shifting while it is operating.
  • Page 3 Connecting the drain hose ted on the Technical Data Plate fixed on the machine; Connect the drain hose, without bending it, to a draining duct or a wall drain situated between the socket or the plug. 65 and 100 cm from the floor;...
  • Page 4: The First Wash Cycle

    The first wash cycle As the colours of the wires in the lead may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: Once the appliance has been installed, and before you use Connect Green & Yellow wire to terminal marked E or it for the first time, run a wash cycle with detergent and no or coloured Green or Green &...
  • Page 5: Technical Data

    Technical data Model IWD 61450 width 59.5 cm Dimensions height 85 cm depth 52,5 cm Capacity from 1 to 6 kg Electrical please refer to the technical data plate fixed to the machine connections maximum pressure 1 MPa (10 bar) Water connection minimum pressure 0.05 MPa (0.5 bar)
  • Page 6: Description Of The Washing Machine And Starting A Wash Cycle

    Description of the washing machine and starting a wash cycle Control panel WASH CYCLE DELAY TIMER PROGRESS button START/ FUNCTION DISPLAY PAUSE ON/OFF button buttons with button with indicator lights indicator light TEMPERATURE DOOR LOCKED knob Detergent dispenser drawer indicator light WASH CYCLE SPIN SPEED knob...
  • Page 7: Indicator Lights

    Indicator lights Door locked indicator light When the indicator light is on, the porthole door is locked The indicator lights provide important information. to prevent it from being opened; make sure the indicator This is what they can tell you: light is off before opening the door (wait approximately 3 minutes).
  • Page 8: Wash Cycles

    Wash cycles Table of wash cycles Detergents Max. load (kg) Max. Max. Description of the wash cycle temp. speed Cycle duration Fabric (°C) (rpm) Wash Normal softener Time Daily 1 White Cotton: extremely soiled whites. 90° 1400 1 White Cotton (1): heavily soiled whites and resistant colours. 60°...
  • Page 9: Personalisation

    Personalisation Setting the temperature Turn the TEMPERATURE knob to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash The washing machine will automatically prevent you from selecting a temperature which is higher than the maximum value set for each wash cycle.
  • Page 10: Detergents And Laundry

    Detergents and laundry Detergent dispenser drawer Silk: use special wash cycle 7 to wash all silk garments. We recommend the use of special detergent which has Good washing results also depend on the correct dose of been designed to wash delicate clothes. detergent: adding too much detergent will not necessa- Curtains: fold curtains and place them in a pillow case or rily result in a more efficient wash, and may in fact cause...
  • Page 11: Precautions And Tips

    Precautions and tips This washing machine was designed and constructed in Consumers should contact their local authority or accordance with international safety regulations. The fol- retailer for information concerning the correct lowing information is provided for safety reasons and must disposal of their old appliance.
  • Page 12: Care And Maintenance

    Care and maintenance Cutting off the water and electricity 2. unscrew the lid by rota- supplies ting it anti-clockwise (see figure): a little water may trickle out. This is perfectly normal; limit wear on the hydraulic system inside the washing machine and help to prevent leaks.
  • Page 13: Troubleshooting

    Troubleshooting Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. The wash cycle does not start.
  • Page 14 The machine is noisy. The machine wont spin properly. happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly. This is a safety feature to prevent damage. Out of Balance can be caused by washing a single heavy item (eg duvet, quilt, etc).
  • Page 15: Assistance

    We have a dedicated team who can provide free advice and assistance with your appliance if you experience any technical difficulties within the first 90 days of ownership. Simply call our Indesit Service Hotline on 08448 224 224 (Republic of...
  • Page 16 195089914.00 12/2010 - Xerox Fabriano After Sales Service No one is better placed to care for your Indesit appliance during the course of its working life than us - the manufacturer. Essential Contact Information Indesit Service We are the largest service team in Europe offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service.
