Instructions for use
GB
English,1
IWD 7145
WASHING MACHINE
Contents
Installation, 2-3-4-5
Wash cycles, 8
Table of wash cycles
Detergent dispenser drawer
Bleach cycle
Cutting off the water or electricity supply
Troubleshooting, 13
Service and Guarantee, 14-15-16
GB
1
Advertisement
Table of Contents
Related Manuals for Indesit IWD 7145
Summary of Contents for Indesit IWD 7145
-
Page 1: Table Of Contents
Instructions for use English,1 IWD 7145 WASHING MACHINE Contents Installation, 2-3-4-5 Unpacking and levelling Connecting the electricity and water supplies The first wash cycle Technical data Description of the washing machine and starting a wash cycle, 6-7 Control panel Indicator lights... -
Page 2: Installation
Connecting the water inlet hose 3. Remove the 4 protective screws (used during tran- sportation) and the rubber washer with the correspon- ding spacer, located on the rear part of the appliance (see figure). 3. Make sure that the hose is not folded over or bent. - Page 3 Connecting the drain hose Connect the drain hose, without bending it, to a draining duct or a wall drain situated between 65 and 100 cm from the floor; The drain hose may be connected to an under- sink trap. Before connec- ting the drain hose from the machine ensure that any blanks or removable...
-
Page 4: The First Wash Cycle
As the colours of the wires in the lead may not corre- spond with the coloured markings identifyng the terminals in your plug, proceed as follows: Connect Green & Yellow wire to terminal marked E or or coloured Green or Green & Yellow. Connect Brown wire to terminal marked L or coloured Red. -
Page 5: Technical Data
Technical data Model IWD 7145 width 59.5 cm Dimensions height 85 cm depth 53,5 cm Capacity from 1 to 7 kg Electrical please refer to the technical data plate fixed to the machine connections maximum pressure 1 MPa (10 bar) Water connection minimum pressure 0.05 MPa (0.5 bar) -
Page 6: Description Of The Washing Machine And Starting A Wash Cycle
Description of the washing machine and starting a wash cycle Control panel Detergent dispenser drawer Detergent dispenser drawer: used to dispense detergents and washing additives (see “Detergents and laundry”). ON/OFF button: switches the washing machine on and off. WASH CYCLE knob: programmes the wash cycles. Du- ring the wash cycle, the knob does not move. -
Page 7: Indicator Lights
Indicator lights The indicator lights provide important information. This is what they can tell you: Wash cycle phase indicator lights Once the desired wash cycle has been selected and has begun, the indicator lights switch on one by one to indicate which phase of the cycle is currently in progress. -
Page 8: Wash Cycles
Wash cycles Table of wash cycles Description of the wash cycle Daily 1 Withe Cotton: extremely soiled whites. 1 Withe Cotton (1): heavily soiled whites and resistant colours. 1 Withe Cotton (2): heavily soiled whites and delicate colours. 2 Cotton: heavily soiled whites and resistant colours. 3 Coloured Cotton (3): lightly soiled whites and delicate colours. -
Page 9: Personalisation
Personalisation Setting the temperature Turn the TEMPERATURE knob to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash The washing machine will automatically prevent you from selecting a temperature which is higher than the maximum value set for each wash cycle. -
Page 10: Detergents And Laundry
Detergents and laundry Detergent dispenser drawer Good washing results also depend on the correct dose of detergent: adding too much detergent will not necessa- rily result in a more efficient wash, and may in fact cause build up on the inside of your appliance and contribute to environmental pollution. -
Page 11: Precautions And Tips
Precautions and tips This washing machine was designed and constructed in accordance with international safety regulations. The fol- lowing information is provided for safety reasons and must therefore be read carefully. General safety • This appliance was designed for domestic use only. •... -
Page 12: Care And Maintenance
Care and maintenance Cutting off the water and electricity supplies • Turn off the water tap after every wash cycle. This will limit wear on the hydraulic system inside the washing machine and help to prevent leaks. • Unplug the washing machine when cleaning it and during all maintenance work. -
Page 13: Troubleshooting
Troubleshooting Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: The washing machine does not switch on. The wash cycle does not start. The washing machine does not take in water (“H2O”... -
Page 14: Before Calling For Assistance
Service Before calling for Assistance: • Check whether you can solve the problem alone (see “Troubleshooting”); • Restart the programme to check whether the problem has been solved; • If this is not the case, contact an authorised Technical Assistance Centre using the telephone number provided on the guarantee certificate. -
Page 15: Guarantee
We have a dedicated team who can provide free advice and assistance with your appliance if you experience any technical difficulties within the first 90 days of ownership. Simply call our Indesit Service Hotline on 08709 066 066 (ROI 0818 313 413) for telephone assistance, or, where necessary, to arrange for an engineer to call. -
Page 16: After Sales Service
No one is better placed to care for your Indesit appliance during the course of its working life than us - the manufacturer. We are the largest service team in Europe offering you access to 400 skilled telephone advisors and 1100 fully qualified...
