Step 2: Inspect the Fan
1. Unpack the fan carefully to avoid any damage to components.
• Never lift the motor by the wires. Let the motor rest in the carton liner for protection.
2. Check the sack parts. See Figure 2.
Blade Set
Blade Iron Set
1/4-10 Lag Screw
Pull Chain
Blade Assembly
Screw
Armature Screw
Mounting Isolator
© 2003 HUNTER FAN CO.
!CAUTION!
Fan Part s
Canopy
Insert
Canopy
Motor / Housing Assembly
Hardware
Mounting Bracket
(Not Drawn to Scale)
Hanger Bracket
Assembly
Pipe Nipple
Oil Tube
(Drawn to Scale)
Rubber Bushing / Pin
Wire Nut
Canopy Screw
2
Figure 2
41556-01 8/08/03
