  • Page 1 ™ 1620 cf Que 1620 GPS navigator module applications guide...
  • Page 2 Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the Garmin web site (www.garmin.com) for current updates and supplemental information concerning the use and operation of this and...

  • Page 3: Software License Agreement

    1200 EAST 151st STREET, OLATHE, KS 66062 WITHIN 10 DAYS OF THE DATE YOU ACQUIRED IT FOR A FULL REFUND. 1. LICENSE: GARMIN (“we” or “us”) provides you with storage media containing computer software (the “Program”) which may also include digital cartographic data and “online”...
  • Page 4 Introduction 4. TERM: This License shall continue for as long as you use the Product. However, this License will terminate automatically without notice from GARMIN if you fail to Software comply with any of its terms or conditions. You must agree, upon termination, to License Agreement destroy all copies of the Product.

  • Page 5: Fcc Compliance Information

    The cf Que does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service center. Unauthorized repairs or modi- fi cations could result in permanent damage to the equipment, and void your war- ranty and your authority to operated this device under Part 15 regulations.
  • Page 6 Do not mount the PDA in a place where the driver or passengers are likely to impact it in a collision. The mounting hardware provided by Garmin is not war- ranted against collision damage or the consequences thereof.

  • Page 7: Table Of Contents

    FCC Compliance Information...iii Warnings and Precautions...iii-iv Table of Contents...v About the Manuals...vi Chapter 2: GPS Applications...1-27 Starting Up the cf Que 1620...1 Viewing the Map Page...1 Initializing the Receiver...1 Using the Map Page...2-3 Setting Up the Map Page Data Fields...3-4 The Main Menu...6...

  • Page 8: About The Manuals

    Que Applications Guide. If you purchased your Pocket PC at the same time as the Garmin cf Que and are not yet familiar with its opera- tion, it is strongly recommended that you learn how to operate the Pocket PC first.

  • Page 9: Chapter 2: Gps Applications

    Settings and the Menus application on the Personal page. From the Menus page place a check next to Garmin Que to place it on the Start List. It is important to remember that the cf Que GPS receiver will continue to operate when the application is not visible.

  • Page 10: Using The Map Page

    To use the Map Page: 1. Tap Start to open the Main Menu and then tap Programs. 2. Select Garmin Que to display the Map Page. When first accessing the Map Page it will take a few moments for the GPS Receiver to locate satellites overhead before it determines your location.
  • Page 11 ™ 1620 GPS Applications The Map Page Map Pointer and Item Description Information Page with Lat/Lon Coordinates New Waypoint Page Accuracy Circle and Track The Map Page also displays detailed geographic information such as highways and roads, lakes and rivers, cities, waypoints and residential streets, depending on the detail of map data being used.

  • Page 12: Setting Up The Map Page Data Fields

    Mapping Data Field Setup Setting Up the Map Page Data Fields The Garmin Que software allows you to customize the display of Map Page Data Fields. You can customize the background and text colors from black to white or create a transparent background to increase the amount of map area displayed along with overlaying mapping and routing data.
  • Page 13 ™ 1620 GPS Applications The Map Page Mapping Data Field Options Routing Data Field Setup Routing Data Field Options To determine what data to display in each Data Field: 1. With the Data Fields Options Menu displayed and the Mapping tab selected, tab and hold the stylus on the data fi...

  • Page 14: Using The Main Menu

    GPS Info Using the Main Menu The Map Page Main Menu is the starting point for accessing all of the Garmin Que application features. Using the Main Menu you can access Que Help, Map Dis- play Setup, make System Settings, use the Find feature, monitor GPS status from the Satellite Page, manage a Route, record a Track Log, and observe the Trip Computer.

  • Page 15: Map Setup

    Information at the top of the page is the description of the map set you loaded to Garmin Que using MapSource. To learn how to name map sets, refer to the MapSource User’s Manual. The information at the bottom of the page indicates details of the selected map.

  • Page 16: Line Settings

    1620 ™ GPS Applications Map Setup Map GPS Settings Map Road Settings Map Point Settings GPS Settings To set the Maximum Zoom level for Course Line, Bearing Line, Track Log, Saved Tracks, Lat/Lon Grid and Grid Labels: 1. For Maximum Zoom select from “OFF”, “AUTO”, or an increment from a scale of 120 feet to 800 miles.

  • Page 17: Map Setup

    ™ 1620 GPS Applications Map Setup Area Feature Settings City Settings Marine Settings Area Settings To set the Text Size for Waypoints, Interstate Exits, and Points of Interest: 1. Tap the Area tab from the Map Setup Pages. 2. Select the text size for each type of map item. To set the Maximum Zoom level: 1.

  • Page 18: System Setup

    2. Choose from two operating modes “Enabled” and “Disabled”. To run Garmin Que on cf Que insertion: 1. Tap “Run Garmin Que” to place a check mark in the adjacent box and automatically start up the Garmin Que application whenever you insert the cf Que into the Pocket PC.

  • Page 19: System Setup

    ™ 1620 GPS Applications System Setup Avoid Roads/Areas Page Units Settings Page Language Selection Page Avoidance Settings You can select specific sections of roads and define areas to avoid when calculating a route. This helps you to avoid road construction, heavy traffic areas, etc. To select roads and areas to avoid: Refer to page 25 for detailed instructions.

  • Page 20: The Find Feature

    1620 ™ GPS Applications The Find Feature Find Menu Item Options Menu Find Item Details Page Using the Find Feature to search for a Destination The Find feature allows you to search for any map data item and create a route to it.

  • Page 21: Searching For Cities

    ™ 1620 GPS Applications The Find Feature List of Cities By Name Drop-Down Item Options Menu City Details Page Searching for Cities The Find feature allows you to search for a city and create a route to it. The cities listed are part of the basemap and detailed mapping data downloads.

  • Page 22: Searching For An Address

    1620 ™ GPS Applications The Find Feature Searching for an Address The Find feature allows you to search for an address and create a route to it. When you enter an address, the Find feature matches it with those contained in the basemap and detailed mapping data downloads.

  • Page 23: Searching For An Intersection

    ™ 1620 GPS Applications The Find Feature Searching for an Intersection The Find feature allows you to search for an intersection and create a route to it. When you enter two street names to create an intersection, the Find feature matches it with those contained in the basemap and detailed mapping data downloads.

  • Page 24: Searching For A Point Of Interest

    1620 ™ GPS Applications The Find Feature Find Menu Icons Food and Drink Categories List Searching for a Point of Interest Because of the amount of information available in the Points of Interest category is so extensive, it is divided into smaller categories to refine your search for an item. To find a Point of Interest: 1.

  • Page 25: Searching For A Waypoint

    ™ 1620 GPS Applications The Find Feature Waypoint Drop Down Menu Waypoint Options Menu Waypoint Filter List Searching for a Waypoint A waypoint is a geographical location which you have created by marking your current location, tapping a specific point on the map or selecting an item from the Find feature list of map items.

  • Page 26: Creating A Waypoint

    1620 ™ GPS Applications Creating Waypoints Mark Waypoint Page Find Feature “Save as Waypoint” Option A Waypoint as a Route Destination Creating a Waypoint A waypoint can be created three different ways as explained below. All waypoints are accessed from the Find Feature Waypoints List. A Waypoint can be renamed, assigned a graphic symbol, a more accurate altitude, moved to a new location, given new lat/lon coordinates, and provided with special comments.

  • Page 27: The Find Feature

    ™ 1620 GPS Applications Editing Waypoints Map Pointer Location Page Waypoint Details Page Waypoint Symbols List Delete Waypoint Query Editing Waypoints A waypoint can be edited while being created or when you desire to change a previously saved waypoint from the Waypoints List in the Find Feature. You can change the name of the waypoint, assign a specific symbol to display on the map, add information about the waypoint in the form of comments, and delete it from the waypoints list when no longer needed.

  • Page 28: Gps Info Page

    GPS receiver. To view the GPS Info Page: 1. Tap Start to display the main menu, tap Programs and then Garmin Que to display the Map Page. 2. Tap Menu on the menu bar at the bottom of the page and then select GPS Info to display the Satellite Status Page.

  • Page 29: Routes

    Recalculate, Detour, Edit Vias and Turns Page options in addition to those previously mentioned. A route cannot be calculated unless the GPS receiver has determined your current location and you have selected a destination. Check the GPS status message at the top of the Map Page before selecting a desti- nation.
  • Page 30 1. From the Contacts List, use the stylus to select an entry with an address. 2. Then hold the stylus in place to display the drop-down menu and select Locate in Garmin Que to display the Find Address Page. 3. If the address from the Contacts List is in the map database, the City, Number, Street and Postal Code fi...

  • Page 31: Route Navigation

    ™ 1620 GPS Applications Routes Route Navigation Data Fields Route Turns List Turn Preview Page Route Navigation Once active, the route provides you with a variety of navigation aids. The data fields at the top of the Map Page change to display your speed, the distance to the next turn on your route, the time to the next turn based on your current speed and the time of arrival at your destination.

  • Page 32: Customizing Route Navigation

    1620 ™ GPS Applications Routes General Preferences Routing Preferences Road Speed Adjustment Page Guidance Preferences Customizing Route Navigation You can use the Route Preferences, Detour, Edit Vias, and Recalculate options to customize route navigation to meet your requirements. To determine the way a route is calculated, whether or not some routing features are implemented automatically, modified or turned Off, you can use the System Setup and Routing options from the Main Menu on the Map Page.

  • Page 33: Road And Area Avoidance

    ™ 1620 GPS Applications Routes Avoid Roads and Areas Page Tap “Measure from Pointer” icon - Tap Start Point on Map and drag to End Point Road Section to Avoid Defi ned Area to avoid defi ned by the stylus Avoid Areas Selection Page Road and Area Avoidance You can select specific sections of roads and define areas to avoid when calculating...

  • Page 34: Setting A Home Point

    1620 ™ GPS Applications Routes Set Home Point Page Route Via Points List Set Home Point You can select specific location as a Home Point to route to at any time you desire to stop navigating a route and return to that location. The Routing feature will create a route back to the Home Point from your current location.

  • Page 35: Detours

    ™ 1620 GPS Applications Routes Route Detour Options Page Detour Turns List Original Route Detoured Route Detour To navigate around obstacles such as traffic jams, construction, etc., you can use the Detour feature to recalculate your current route. To Detour a specified distance around an obstacle on a Route: 1.

  • Page 36: Utilities

    1620 ™ GPS Applications The Track Log Track Log Page Save Track Dialog Saved Track Options Saved Track Details Page Using the Track Log Utility The Track Log is a feature that allows you to create a log (record) of your travels , which you can save for later use.

  • Page 37: The Sun And Moon Tables

    ™ 1620 GPS Applications The Sun and Moon Tables Sun and Moon Page Location Options Animation Options Menu The Hunt and Fish Tables Hunt and Fish Page Location Options Using the Sun and Moon Tables The Sun and Moon Page is a feature with tables that allow you to view the posi- tion of the sun and moon in relationship to the earth at any time, date and location.

  • Page 38: Measure Distance

    1620 ™ GPS Applications Measure Distance Measure Distance Page Map Scale Control Panel Map Scale Tap to display Control Panel Center Zoom Location Tool Bar Icons Measure Between Two Points Using the Measure Distance Utility Measure Distance is a feature that allows you to determine the distance between two items on the map.

  • Page 39: Using The Trip Computer

    When displayed, the Trip Computer provides you with information fields to show the GPS receiver status, the date and time, direction of travels and current speed. There are fields that display distance traveled for a particular trip, Stopped...

  • Page 40: Chapter 3: Hardware Mapping

    1620 ™ Hardware Mapping The Hard Buttons The Arrow Button Left Right Down (Graphic representation, may not exactly resemble the button on your device.) The Jog Button Button Side of device. Using the Arrow Button to access cf Que features All Pocket PC’...

  • Page 41: Chapter 3: Hardware Mapping

    “Left and right cycle to next page“ option to place a check in that box. Helpful Hints: • To ease the activation of Garmin Que to visible status when running multiple programs, map one of the buttons to display it when pressed. Follow instruc- tions for mapping programs to hard buttons contained in your Pocket PC Owner’...

  • Page 42: Chapter 4: Map Data

    Transferring Other Types of Detailed Maps from MapSource Garmin MapSource offers a wide variety of detailed mapping data other than those provided with your unit, such as topographic and marine charts. If you plan to add additional mapping data or already have other versions of MapSource maps other than those provided with your cf Que, you can transfer those maps to the device using the methods described below.

  • Page 43: Chapter 4: Map Data

    Open Complete Window Transferring Waypoints and Saved Tracks to MapSource Garmin MapSource allows you to transfer lists of waypoints and saved tracks for storage for later use. This allows you to reduce the number of items stored on your Pocket PC in order to add more without the need for deleting those items you would like to save for future reference.

  • Page 44: Chapter 5: Additional Information

    CD-ROM: Accepts downloadable map detail from Garmin PC-based MapSource City Select CD-ROM’s which provide street-level detail, addresses, listings of nearest restaurant, hotels, ATMs and more.

  • Page 45: Specifi Cations

    * Subject to accuracy degradation to 100m 2DRMS under the U.S. Department of Defense Selective Availability Program. Cleaning The Garmin cf Que GPS Receiver is constructed of high quality materials and does not require user maintenance other than occasional cleaning. DO NOT ATTEMPT TO CLEAN THE cf Que WHILE IN-...

  • Page 46: Troubleshooting Guide

    “None Found” If you encounter operational problems that you cannot solve using this guide, fi rst determine that they are not related to operation of your Pocket PC, then: Contact Garmin Product Support at 913/397.8200 or 800/800.1020 Troubleshooting Guide Probable Cause cf Que not inserted or not fully inserted.

  • Page 47: Chapter 5: Additional Information

    Additional MapSource map data sets can be purchased from your Garmin Dealer or on-line from Garmin. Consult your Garmin Dealer for a vial able MapSource maps compatible for use with the cf Que or visit the Garmin website at (www.garmin.com).

  • Page 48: Index

    Water Features 16 Waypoints 17 Antenna 1 Location 2, 20 Mode 1, 10 Receiver 1, 20 Guidance Preferences 10, 24 Help 6 Intersections, Finding 15 Initializing the Receiver 1 Language Selection 11 Location Information 3 Locate in Garmin Que 22...

  • Page 49: Index

    ™ 1620 Index Orientation 3, 7 Panning 3 Pointer 3 Page 2 Scale 2 Selection 7 Setup 4, 7-9 Marking Your location 18 Maximum Speed 31 Measuring Distance 30 Navigating Routes 23 Nearest Current Location 12 New Location 20 Next Turn 23 Night Mode 3, 7 North Up 3, 7 Odometer 31...
  • Page 50 1620 ™ © Copyright 2004 Garmin Ltd. or its subsidiaries Garmin International, Inc. 1200 East 151 Street, Olathe, Kansas 66062, U.S.A. Garmin (Europe) Ltd. Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL, U.K. Garmin Corporation No. 68, Jangshu 2 Road, Shijr, Taipei County, Taiwan www.garmin.com...
