  • Page 1 Crestron QM-MD16X16 16X16 QuickMedia™ Matrix Switcher Operations Guide...
  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2007 Crestron Electronics, Inc.
  • Page 3: Table Of Contents

    Crestron QM-MD16X16 16X16 QuickMedia™ Matrix Switcher Contents 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 Introduction ..........................1 Features and Functions ....................1 Applications......................... 2 Block Diagrams......................3 Specifications ......................6 Physical Description....................7 Industry Compliance ....................11 Setup ............................12 Network Wiring......................12 QuickMedia Wiring....................
  • Page 5: 16X16 Quickmedia™ Matrix Switcher: Qm-Md16X16

    Up to two QuickMedia Matrix Switchers and Distribution Centers may be cascaded in a given QuickMedia signal path* to support larger system configurations. For instance, a QM-MD16X16 may be used to expand the input capacity of a QM-MD7X2, or multiple QM Matrix Switchers can be combined to support applications such as room-combining with numerous inputs and outputs.
  • Page 6: Applications

    Complete system operation can be made transparent to the end-user with all signal routing occurring under the command of the MediaManager control system. Control and monitoring of the QM-MD16X16 is also possible independent of the control system using its front panel pushbuttons and LEDs. Customizable label strips are provided to easily designate inputs and outputs by name using Crestron Engraver software or standard 3/8"...
  • Page 7: Block Diagrams

    QM-MD16X16, and the tiering abilities of multiple QM-MD16X16s in a QucikMedia environment. Switching Abilities The QM-MD16X16 can be operated locally (Local mode) using buttons on the front panel, or remotely from a control system (System mode). For more information, refer to “Operating Modes” on page 22.
  • Page 8 Internal Cresnet Hub The QM-MD16X16 has an internal four-segment Cresnet hub for routing Cresnet data. Each segment operates independent of each other to allow the QM-MD16X16 to continue functioning in the event of a hub segment experiencing an electrical short or a device error.
  • Page 9 Tiering Up to two tiers of QM-MD16X16s can be cascaded to provide up to 256 QM inputs through one QM-MD16X16 as shown in the following block diagram. Multiple QM-MD16X16s Cascaded to One QM-MD16X16 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 • 5...
  • Page 10: Specifications

    10.42 in (26.47 cm) Weight 6.75 lbs (3.07 kg) 1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following these footnotes. 2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems.
  • Page 11: Physical Description

    16X16 QuickMedia™ Matrix Switcher Physical Description This section provides information on the connections, controls and indicators available on your QM-MD16X16. QM-MD16X16 Physical View (Front) QM-MD16X16 Physical View (Rear) 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 • 7 Operations Guide – DOC. 6538A...
  • Page 12 16X16 QuickMedia™ Matrix Switcher Crestron QM-MD16X16 QM-MD16X16 Overall Dimensions 16.90 in 42.93 (cm) 10.03 in (25.48 cm) 10.42 in (26.47 cm) 17.03 in (43.24 cm) 3.47 in (8.81 cm) 8 • 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 Operations Guide – DOC. 6538A...
  • Page 13 IN 1 through 16 (16) pushbuttons & red LEDs, select inputs to be routed in Local mode, select routing view for a given input in System mode. (Continued on following page) 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 • 9 Operations Guide – DOC. 6538A...
  • Page 14 3. The eight-pin RJ-45 QuickMedia transport port accepts CAT5E/CAT6 carrying audio, video and microphone signals. The QM input port conforms to the 568B wiring standard. Refer to the following table for connector pinouts. 10 • 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 Operations Guide – DOC. 6538A...
  • Page 15: Industry Compliance

    QM midpoint devices may be inserted in a given QM signal path; exceptions apply, refer to each respective product manual for full detail. Industry Compliance As of the date of manufacture, the QM-MD16X16 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.
  • Page 16: Setup

    Use Crestron power supplies for Crestron equipment. • Provide sufficient power to the system. CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the system (http://www.crestron.com/calculators). •...
  • Page 17: Identity Code

    QM-WMC Identity Code The Net ID of the QM-MD16X16 has been factory set to 32. The Net IDs of multiple QM-MD16X16 devices in the same system must be unique. Net IDs are changed from a personal computer (PC) via the Crestron Toolbox™ (refer to “Establishing Communication”...
  • Page 18 Stacking Four “feet” are provided with the QM-MD16X16 so that if the unit is not rack mounted, the rubber feet can provide stability when the unit is placed on a flat surface or stacked. These feet should be attached at the corners of the bottom of the unit prior to the hookup procedure.
  • Page 19: Hardware Hookup

    75 watts of power to each group of QM ports to ensure that sufficient power is available for QM devices that are connected to the QM-MD16X16. Power for the QM-MD16x16 is jumped from the Cresnet input on the C2N-SPWS300.
  • Page 20 C2N-SPWS300 System Power Supply Operations Guide (Doc. 8190). NOTE: Power to the QM ports on the QM-MD16X16 can be applied using other configurations. The total power usage of each port group must not exceed the port group’s available input power.
  • Page 21: Programming Software

    Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com.
  • Page 22: Programming With Simpl Windows

    16X16 QuickMedia™ Matrix Switcher Crestron QM-MD16X16 Programming with SIMPL Windows NOTE: While SIMPL Windows can be used to program the QM-MD16X16, it is recommended to use SystemBuilder QM Tools software for configuring a QuickMedia system. SIMPL Windows is Crestron’s premier software for programming Crestron control systems.
  • Page 23: Example Program

    The symbol can be viewed by double clicking on the icon or dragging it into Detail View. Each signal in the symbol is described in the SIMPL Windows help file (F1). Example Program An example program for the QM-MD16X16 is available from the Crestron website (http://www.crestron.com/exampleprograms). 16X16 QuickMedia™ Matrix Switcher: QM-MD16X16 • 19...
  • Page 24: Uploading And Upgrading

    Use the Address Book in Crestron Toolbox to create an entry for the QM-MD16X16 using the expected communication protocol (Indirect). Select the Cresnet ID of the QM-MD16X16 and the address book entry of the control system that is connected to the QM-MD16X16.
  • Page 25: Program Checks

    16X16 QuickMedia™ Matrix Switcher Program Checks To view a list of actions that can be performed on the QM-MD16X16, use Crestron Toolbox to display the network device tree (Tools | Network Device Tree), which shows all network devices connected to the control system. Right-click on the QM-MD16X16 to display actions that can be performed on the QM-MD16X16.
  • Page 26: Operation

    System mode. Local Mode Operation-Switching Signal Routing Signals coming in to the QM-MD16X16 can be switched to individual or multiple output locations. Additionally, the audio and video portions of an input signal can be switched simultaneously or separately.
  • Page 27 NOTE: If ENTER has not been pressed, you can go back and “undo” changes made to the current routing. Switching Audio & Video 1. Press LOCAL to place the QM-MD16X16 in the Local mode (the LOCAL Separately LED is flashing slowly).
  • Page 28: Problem Solving

    Use the Right Wire In order to ensure optimum performance over the full range of your installation topology, Crestron Certified Wire and only Crestron Certified Wire may be used. Failure to do so may incur additional charges if support is required to identify performance deficiencies because of using improper wire.
  • Page 29 Cresnet power usage of the entire chain. If the unit is home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable length value on the equation’s left side.
  • Page 30: Reference Documents

    For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/offices) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website (http://www.crestron.com/onlinehelp) to ask questions about Crestron products.
  • Page 31: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures.
  • Page 32 Crestron Electronics, Inc. Operations Guide – DOC. 6538A 15 Volvo Drive Rockleigh, NJ 07647 (2016467) Tel: 888.CRESTRON 05.07 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
