  • Page 1 Crestron QM-MD5x1 QuickMedia™ Matrix Switcher/Mixer Operations Guide...
  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.

  • Page 3: Table Of Contents

    Crestron QM-MD5x1 Contents QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 Introduction ... 1 Features and Functions ... 1 Applications... 4 Specifications ... 6 Physical Description... 7 Industry Compliance ... 14 Setup ... 14 Network Wiring... 14 QuickMedia Wiring... 16 Identity Code ... 18 Rack Mounting ...

  • Page 5: Quickmedia™ Matrix Switcher/Mixer: Qm-Md5X1

    • Local audio output features electronically adjustable volume, bass, treble, mute and 12-band parametric/graphic equalizer • Separate switching of audio and video portions of each input signal QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 1...
  • Page 6 (monaural). The microphone mix can be mixed into the stereo program and the stereo program can be mixed into the speech. After mixing, volume, equalization and tone control can be applied. 2 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • Auto Compensation automatically recalls microphone EQ settings,...
  • Page 7 Inputs QM Mic 1 + 2 ALL QM MICROPHONE MIX SIGNALS FROM THE QM-MD5X1 ARE SENT OUT ON THE MIC 1 CHANNEL OF THE QM OUTPUT. THERE ARE NO MICROPHONE SIGNALS ON THE MIC 2 CHANNEL OF THE QM OUTPUT.

  • Page 8: Applications

    QM-MD4x2 switcher or any combination of QM switching devices. This provides additional inputs for one MD5x1 as shown in the following diagrams. QM-MD5x1 Connected with Other QM-Switching Devices NOTE: When connecting multiple QM devices, the route between a QM origination point (e.g.
  • Page 9 Crestron QM-MD5x1 The following diagram shows an MD5x1 in a lectern application. QM Solution in Lectern using QM-MD5x1 For more information on this and other QM applications, refer to the latest revision of the Crestron MediaManager Control, Switching and Management Applications Guide (Doc.

  • Page 10: Specifications

    QuickMedia™ Matrix Switcher/Mixer Specifications Specifications for the QM-MD5x1 are listed in the following table. QM-MD5x1 Specifications Cresnet Power Usage Default Net ID Control System Update Files Input Channels Output Channels Video Input Details (BNC) RGBHV Input Details (DB15HD) (continued on next page) 6 •...

  • Page 11: Physical Description

    QM devices. Longer lengths of cable may experience eventual loss of bandwidth when viewing higher resolution sources. For more information, refer to “QuickMedia Wiring” on page 16. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 7 DETAILS unbalanced, 4 V balanced ®...
  • Page 12 QM-MD5x1 Physical View (Front) QM-MD5x1 Physical View (Rear) QM-MD5x1 Physical Views 1.70 in (4.32 cm) 17.03 in (43.24 cm) 6.44 in (16.35 cm) 7.15 in (18.17 cm) 16.92 in (42.98 cm) 8 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 Operations Guide - DOC. 6300...
  • Page 13 Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer SIGNAL COMP/P TYPE Component Blue Green S-video Not connected Luma Composite Composite Not Connected PIN NAME SIGNAL NAME Left Ground Right QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 9 SYNC SENSE Chroma Luma Not Connected Composite...
  • Page 14 Refer to “QuickMedia Wiring” on page 16 for cable specifications. NOTE: When using Crescat-QM wiring, four additional wires are included for making Cresnet connections. Refer to “QuickMedia Wiring” on page 16 for cable specifications. 10 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 FUNCTION Red Video Green Video...

  • Page 15: Audio Out

    MD5x1 is established (the unit is polled on the network). Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer PIN NAME SIGNAL NAME Positive Negative Ground PIN NAME SIGNAL NAME Positive (left) Negative (left) Ground (right and left) Positive (right) Negative (right) QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 11...
  • Page 16 For more information on the MD5x1’s operating modes, refer to “Operating Modes” on page 58. Press this button to switch the audio portion of an input signal when operating in the local mode. When the accompanying LED is illuminated, only the audio portion of a QM signal will be switched.
  • Page 17 Crestron QM-MD5x1 IN (1 through 5) Select an input source to view or switch (depending on the selected operating mode) by pressing the corresponding IN button. If audio break is enabled (indicated by the AUDIO BREAK LED), only the audio or video portion (indicated by the A or V LED) will be switched or viewed (depending on the selected mode).

  • Page 18: Industry Compliance

    QuickMedia™ Matrix Switcher/Mixer Industry Compliance As of the date of manufacture, the QM-MD5x1 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to...
  • Page 19 R = Resistance (refer to the following table). L = Length of run (or chain) in feet. L x P P = Cresnet power usage of entire run (or chain). RESISTANCE (R) WIRE GAUGE Doubled CAT5 Tripled CAT5 QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 15...

  • Page 20: Quickmedia Wiring

    NOTE: The length of CAT5/5E/6 cable that can be used can vary. However, the total skew must be ≤ 15 ns. NOTE: Longer lengths of cable may experience eventual loss of bandwidth when viewing higher resolution sources. 16 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 Crestron QM-MD5x1 Operations Guide - DOC. 6300...
  • Page 21 WHITE/GREEN - RGB GREEN BLUE WHITE/BLUE GREEN + RGB GREEN WHITE/BROWN BROWN + RGB BLUE QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 17 QM ASSIGNMENT COMPOSITE, S-VIDEO AND AUDIO - RGB RED - CHROMINANCE + RGB RED + CHROMINANCE - LUMINANCE + AUDIO...

  • Page 22: Identity Code

    Crestron Viewport version 3.35 or later. Use the appropriate method to set the Net ID. Method A (Cresnet address-settable ID) 18 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 1. Ensure that the device requiring a Net ID change is the only unit connected to the control system.
  • Page 23 TSID-enabled devices found. The list is similar to the report produced by pressing F4 (Report Network Devices); the first eight digits of each line constitute the TSID number (hexadecimal form of the serial number). QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 19...
  • Page 24 Alpha characters in serial numbers or TSID numbers may be entered in upper or lower case. 20 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 5. Enter either the serial number or TSID number of the device that requires a change. The list scrolls to and highlights the device listing. The listing should show the device’s default Cresnet ID (a.k.a.

  • Page 25: Rack Mounting

    3. Secure the ear to the unit with three screws from step 1, as shown in the following diagram. 4. Repeat procedure (steps 1 through 3) to attach the remaining ear to the opposite side. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 21 USE COVER SCREWS...

  • Page 26: Stacking

    The ratings on the connecting unit's supply input should be considered to prevent overloading the wiring. Hardware Connections for the QM-MD5x1 (Back of the Unit is Shown) STEREO AUDIO INPUTS: (PAIR WITH THE 2 VIDEO...

  • Page 27: Programming Software

    Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer Signal Ground Jumper  ® Pro-e (VT Pro-e) software packages). QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 23 Signal + Ground Signal - -based programming software.

  • Page 28: Earliest Version Software Requirements For The Pc

    NOTE: The following assumes that the reader has knowledge of SIMPL Windows. If not, refer to the extensive help information provided with the software. 24 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • (Optional) SystemBuilder version 2.0 (due in first quarter of 2005) or later with SystemBuilder Templates version 1.0.1or later.
  • Page 29 Expanded QM-RMCRX System Tree C2Net-Device Slot in Configuration Manager To incorporate an MD5x1 into the system, drag the QM-MD5x1 from the Cresnet Control Modules | QM Series folder of the Device Library and drop it in System Views. The QM-RMCRX system tree displays the QM-MD5x1 in Slot 5, with a default Net ID of 1D as shown in the following illustration.
  • Page 30 C2Net Device, Slot 5 Setting the Net ID in Device Settings Double-click the QM-MD5x1 icon in the upper pane to open the “Device Settings” window. This window displays the device information for the MD5x1. The Net ID can be changed in this window using the Net ID tab, as shown in the following figure.
  • Page 31 The remote microphone pair from IN 5 can be switched and mixed into the MIC 1 channel of OUT. The same mic mix will be routed to the mixing section of AUDIO OUT. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 27 Slot 4 contains the...
  • Page 32 The two methods should not be used simultaneously. While using the SIMPL Windows Programming Manager, double-click on Slot 1 of the QM-MD5x1 to view the details of the Input Switching symbol as shown in the following diagram. Input Switching Symbol (Slot 1) in SIMPL Windows Programming Manager NOTE: The symbol image has been altered to fit the page.
  • Page 33 Crestron QM-MD5x1 QM-MD5x1, Slot 1 Digital Input Signal Descriptions NOTE: When the front panel is locked, the MD5x1 will switch to the system mode and use the switch configuration and preset settings specified by the control system. Operations Guide - DOC. 6300 QuickMedia™...
  • Page 34 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 1 Analog Input Signal Descriptions (continued on next page) 30 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT QMLinkPeakToSave Sets the peaking value that will be saved to the preset given by QMLinkPreset#ToSave when SaveQMLinkPreset is held high.
  • Page 35 Crestron QM-MD5x1 QM-MD5x1, Slot 1 Analog Input Signal Descriptions (continued) (continued on next page) Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT QMLink5Preset# [This signal is operative only if Auto Compensation is NOT enabled.] Sets the preset number that will be recalled when RecallQMLink5Preset is held high.
  • Page 36 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 1 Analog Input Signal Descriptions (continued) NOTE: When programming the MD serial input signals should not be used. Signal Values for VideoInpSelect Selections Signal Values for AudioInpSelect Selections Signal Values for RemoteMicSelectA and RemoteMicSelectB Selections NOTE: Use an Analog Initialize to send a decimal input signal to the symbol.
  • Page 37 Crestron QM-MD5x1 QM-MD5x1, Slot 1 Serial Input Signal Descriptions NOTE: When programming the MD5x1 using serial commands, digital and analog switching commands should not be used. However, digital and analog mixing commands can still be used. Similarly, if the MD5x1 is to be programmed with digital and analog switching commands, serial commands should not be used.
  • Page 38 QM origination point. While using the SIMPL Windows programming manager, double-click on Slot 2 of the QM-MD5x1 to view the details of the Remote Microphone EQ Controls symbol as shown in the following diagram.
  • Page 39 Crestron QM-MD5x1 Remote Microphone Controls Symbol (Slot 2) in SIMPL Windows Programming Manager NOTE: The symbol image has been altered to fit the page. QM-MD5x1, Slot 2 Digital Input Signal Descriptions Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT...
  • Page 40 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 2 Analog Input Signal Descriptions QM-MD5x1, Slot 2 Analog Output Signal Descriptions 36 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT Mic1EQ1ToSave through Sets the four MIC 1 EQ trims (at 160Hz, 500Hz, Mic1EQ4ToSave 1.2kHz, and 3kHz) that will be saved when SaveMicEQPreset is held high.
  • Page 41 After mixing, volume, equalization and tone control can be applied (via the While using the SIMPL Windows programming manager, double-click on Slot 3 of the QM-MD5x1 to view the details of the Mixer symbol as shown in the following diagram. Operations Guide - DOC. 6300 QuickMedia™...
  • Page 42 QuickMedia™ Matrix Switcher/Mixer Mixer Symbol (Slot 3) in SIMPL Windows Programming Manager NOTE: The symbol image has been altered to fit the page. QM-MD5x1, Slot 3 Digital Input Signal Descriptions (continued on next page) 38 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1...
  • Page 43 Crestron QM-MD5x1 QM-MD5x1, Slot 3 Digital Input Signal Descriptions (continued) QM-MD5x1, Slot 3 Analog Input Signal Descriptions (continued on next page) Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT RecallMicMixerPreset Recalls the preset given by MicMixerPreset# when the input is held high.
  • Page 44 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 3 Analog Input Signal Descriptions (continued) (continued on next page) 40 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT MicA-2ToMicMix Sets the mixing level for remote MIC A-2. Remote MIC A-2 is mixed with remote MIC A-1.
  • Page 45 Crestron QM-MD5x1 QM-MD5x1, Slot 3 Analog Input Signal Descriptions (continued) (continued on next page) Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT RightToAudioOutSp Sets the mixing level for the Right program channel of the selected audio source (audio source selection is accomplished via the Input Switching module on slot 01).
  • Page 46 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 3 Analog Input Signal Descriptions (continued) (continued on next page) 42 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT RightToAudioOutL Sets the mixing level for the Right program channel of the selected audio source (audio source selection is accomplished via the Input Switching module on slot 01).
  • Page 47 Crestron QM-MD5x1 QM-MD5x1, Slot 3 Analog Input Signal Descriptions (continued) QM-MD5x1, Slot 3 Analog Output Signal Descriptions (continued on next page) Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT RightToAudioOutR Sets the mixing level for the Right program channel of the selected audio source (audio source selection is accomplished via the Input Switching module on slot 01).
  • Page 48 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 3 Analog Output Signal Descriptions (continued) Slot 4: Graphic EQ The MD5x1 provides a line-level audio output labeled AUDIO OUT. The output has three channels labeled PRG L, PRG R and SP. The MD5x1 provides graphic and parametric EQ for each of the three AUDIO OUT channels.
  • Page 49 DMT Software). While using the SIMPL Windows programming manager, double-click on Slot 4 of the QM-MD5x1 to view the details of the Graphic EQ symbol as shown in the following diagram. Graphic EQ Symbol (Slot 4) in SIMPL Windows Programming Manager NOTE: The symbol image has been altered to fit the page.
  • Page 50 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 4 Digital Input Signal Descriptions QM-MD5x1, Slot 4 Analog Input Signal Descriptions (continued on next page) 46 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT SaveAudioOutTrimPreset Saves the 30 trim values to the trim preset given by the analog signal AudioOutTrimPreset# when the input is held high.
  • Page 51 Crestron QM-MD5x1 QM-MD5x1, Slot 4 Analog Input Signal Descriptions QM-MD5x1, Slot 4 Analog Output Signal Descriptions Slot 5: General Audio Controls The MD5x1 provides a line-level audio output labeled AUDIO OUT. The output contains three channels labeled PRG L, PRG R and SP.
  • Page 52 QM-FTSC Origination Point The QM-MD7x2 and QM-MD5x1 can also act as a midpoint between a QM origination point and a QM endpoint. When acting as a midpoint, these devices pass on the audio parameters stored by the QM origination point.
  • Page 53 Crestron QM-MD5x1 QuickMedia™ Matrix Switcher/Mixer General Audio Controls Symbol (Slot 5) in SIMPL Windows Programming Manager NOTE: The symbol image has been altered to fit the page. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 49 Operations Guide - DOC. 6300...
  • Page 54 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 5 Digital Input Signal Descriptions 50 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT MuteAudioOutSp Mutes the SP channel of AUDIO OUT, for as long as the input is high. This soft mute smoothly attenuates the speech audio to avoid audible pops.
  • Page 55 Crestron QM-MD5x1 QM-MD5x1, Slot 5 Analog Input Signal Descriptions (continued on next page) Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer INPUT CompToSave [This signal is operative only if Auto Compensation is NOT enabled.] Sets the source gain compensation that will be...
  • Page 56 QuickMedia™ Matrix Switcher/Mixer QM-MD5x1, Slot 5 Analog Input Signal Descriptions (continued) QM-MD5x1, Slot 5 Digital Output Signal Descriptions 52 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 INPUT AudioOutPrgCompPreset# [This signal is operative only if Auto Compensation is NOT enabled.] Sets the source gain compensation preset number that will be recalled when the digital signal RecallCompPreset is held high.

  • Page 57: Programming With Visiontools Pro-E

    Crestron QM-MD5x1 QM-MD5x1, Slot 5 Analog Output Signal Descriptions Example Program An example program for the MD5x1 is available from the "Example Programs" section of the Crestron website (www.crestron.com/exampleprograms). Search for QM-MD5x1.zip. Programming with VisionTools Pro-e Touchpanel screens should be created in VT Pro-e to allow switching of source signals to the outputs, control audio functions, and recall and/or store preset settings.

  • Page 58: Communication Settings

    “null modem” cable. To connect to other control systems refer to the Operations Guide included with the control system. Typical Connection Diagram when Uploading 54 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 Belkin (large model) F5U103 I/O Gear GUC232A Keyspan USA-19QW (Discontinued) Crestron QM-MD5x1 Operations Guide - DOC.
  • Page 59 (COM 1 is shown after this step) is selected, and that all communication parameters and necessary options from the “Port Settings” window are selected as shown after this step. Click the OK button to save the settings and close the window. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 55...

  • Page 60: Uploading A Simpl Windows Program

    Reference Guide (Doc. 6256) or the respective Operations Guide for the control system for details about the other fields shown on the “Send Program” window. 56 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 4. To verify communication, select Diagnostics | Establish Communications (Find Rack). This should display a window that gives the COM port and baud rate.

  • Page 61: Firmware Upgrade

    2. As shown after this step, select File Transfer | Update Network Device Firmware… from the Viewport menu bar. 3. As shown after this step, select the Net ID of the MD5x1 and then click OK. The “Open” window appears (refer to the subsequent graphic). QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 57...

  • Page 62: Operation

    The LOCAL LED will rapidly flash three times and turn off to indicate that the local mode is not available when the front panel is locked. 58 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 4. Browse to the desired .upg file and click Open to begin the transfer. Crestron QM-MD5x1...

  • Page 63: Viewing Signal Routes In The System Mode

    Switching Audio & Video Simultaneously: NOTE: When disabling the audio break function, routes will switch if needed so that the audio output will have the same input as the video output. This means that when an audio output has a different input than the video output, the output's selected audio input will change to match the selected video input.

  • Page 64: Adjusting Speech And Program Audio Levels

    60 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 2. Enable the audio break function by pressing AUDIO BREAK. When audio break is enabled, the AUDIO BREAK and A LEDs will illuminate.
  • Page 65 When raising the volume, the K LED will flash. When the upper limit is reached, the J LED will stop flashing. When lowering the volume, the J LED will flash. When the lower limit is reached, the J LED will stop flashing. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 61...

  • Page 66: Problem Solving

    You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. 62 • QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 TROUBLE POSSIBLE CAUSE(S)

  • Page 67: Future Updates

    Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the QM-MD5x1, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.

  • Page 68: Appendix: Serial Protocol

    The default setting for the verbose mode is off. If the verbose mode is on, whenever a parameter of the switch changes, a message is sent from the MD5x1 that indicates the new state of the parameter. If verbose mode is off, the MD5x1 will only send messages when queried.

  • Page 69: Switching/Routing Functions

    5;. Thus to route a digital audio source from IN 4 (RGB) to the QM output, set the Control$ input to “I4O1A\r”. Alternatively, the command string can consist of 2-digit values, e.g.,“I04O01A\r”. QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 65 FUNCTION DEFINITION...

  • Page 70: Switch All" Example

    Switching/Routing Status Replies If a switch command is sent and an output is already at the new setting, serial feedback will not be provided for that output. NOTE: There is no serial feedback for any switches made while the MD5x1 is in the local mode, even if the verbose mode is on.

  • Page 71: Return And Warranty Policies

    All brand names, product names, and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are trademarks of Microsoft Corporation. Operations Guide - DOC. 6300 QuickMedia™ Matrix Switcher/Mixer QuickMedia™ Matrix Switcher/Mixer: QM-MD5x1 • 67...
  • Page 72 Crestron Electronics, Inc. Operations Guide – DOC. 6300 15 Volvo Drive Rockleigh, NJ 07647 01.05 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
