Page 1: Repair Parts
DRYER Repair Parts List MODEL NUMBER HYE3657AYW When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: CONTROL PANEL Model: HYE3657AYW LD11-139...
-
Page 3: Control Panel
Section: CONTROL PANEL Part No. Description Series Qty 31001555 PANEL, CONTROL 25-3092 SCREW 21001519 ENDCAP (WHT-LT) 21001523 ENDCAP (WHT-RT) 25-3092 SCREW 33001848 SIGNAL, END OF CYCLE (CHIME) 31001554 KNOB/SKIRT, TIMER 31001190 SWITCH, TWO POSITION ROTARY 25-3092 SCREW 21002005 FRAME, CONTROL PANEL (WHT) 21001527 SHIELD, REAR (BACK PANEL) 25-3092... - Page 4 Section: CABINET Model: HYE3657AYW LD12-111...
- Page 5 Section: CABINET Part No. Description Series Qty 31001423 TOP, CABINET (WHT) N 31001527 REINFORMENT, TOP 31001220 DAMPER, CABINET 53-2559 CABINET & BASE ASM (WHT) 2 N 31001714 CABINET & BASE ASM (WHT) 25-3092 SCREW 63-5712 HINGE, CABINET TOP 35-4128 PAD, HINGE 12002126 REINFORCEMENT BRACE/GLIDE KIT 25-3034...
- Page 6 Section: TUMBLER Model: HYE3657AYW LD13-22...
- Page 7 Section: TUMBLER Part No. Description Series Qty 25-7741 SCREW LA-1054 DRYER BULKHEAD KIT Note: BULKHEAD 53-0281 SEAL ASSY (WHITE) Note: SEAL, TUMBLER (REAR) 53-1250 CYLINDER (W/BAFFLE) Note: TUMBLER ASSY. (W/BAFFLES) N 25-7759 SCREW Note: SCREW, BAFFLE 53-1249 BAFFLE, WHITE 31531589 BELT, CYLINDER Note: BELT, TUMBLER 53-0197 SUPPORT ASSY.-CYLINDER REAR Note: SUPPORT ASSEMBLY (REAR)
-
Page 8: Supplemental Information
Section: SUPPLEMENTAL INFORMATION Part No. Description Series Qty 53-4350 MANUAL, USE & CARE 16008334 MANUAL, SRVC DRYER-NO REFUND 31001488 HARNESS, WIRE 53-4450 HARNESS, WIRING 12001928 KIT, SIDE VENT 21001495 RACK, DRYING 12002417 WIRE KIT (HERRIN LAUNDRY) *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available... - Page 9 Section: WIRING INFORMATION Model: HYE3657AYW 15003266...
- Page 10 Section: TUMBLER (SERIES 12) Model: HYE3657AYW LD13-61...
- Page 11 Section: TUMBLER (SERIES 12) Part No. Description Series Qty 31001575 BULB, CYLINDER LIGHT 31001579 RECEPTACLE ASM, CLYINDER LIGHT 31001581 BULKHEAD WITH SEAL 53-1518 BLOCK, TERMINAL 25-3122 WASHER, FLAT 25-0027 NUT (#10-32) 31001585 LENS, CYLINDER LIGHT 31001580 SCREW, 6-32 HEX WASHER HEAD 31001548 SEAL ASSEMBLY (REAR) 25-7101...
- Page 12 Section: WIRING INFORMATION (SERIES 13) Model: HYE3657AYW 15003455...
- Page 13 Section: WIRING INFORMATION (SERIES 13) Part No. Description Series Qty N 15003455 WIRING INFORMATION *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available...
- Page 14 Section: MOTOR & DRIVE Model: HYE3657AYW LD14-63...
-
Page 15: Motor & Drive
Section: MOTOR & DRIVE Part No. Description Series Qty 31001572 CLIP, VENT PIPE GROUND 53-0134 DUCT, EXHAUST 31001589 MOTOR (115V-60HZ 1/3HP) 25-7733 SCREW 31001535 PULLEY, MOTOR (60HZ) 53-1801 HOUSING, BLOWER 31001470 GLIDE, TUMBLER (LT) 31001356 PAD, GLIDE 31001469 GLIDE, TUMBLER (RT) 31001356 PAD, GLIDE 25-7807... - Page 16 Section: DOOR (SERIES 14 EXCEPT HYE3658AZW) Model: HYE3657AYW LD17-41...
- Page 17 Section: DOOR (SERIES 14 EXCEPT HYE3658AZW) Part No. Description Series Qty 31001771 PANEL, FRONT (WHT) 53-0120 CLIP, FRONT PANEL 31001526 LOCK, TOP 31001733 CLIP, SWITCH 31001541 SEAL, BLOWER/COLLECTOR DUCT 25-7810 SCREW 8-18X1/2 TRUSS H 12001324 DUCT KIT, COLLECTOR 53-0204 SEAL 31001732 SWITCH, DOOR 53-0918...
- Page 18 Section: DOOR Model: HYE3657AYW LD17-33...
- Page 19 Section: DOOR Part No. Description Series Qty 53-0726 PANEL, FRONT (WHT) 53-0120 CLIP, FRONT PANEL 31001526 LOCK, TOP 33-2653 BUMPER, CABINET 31001541 SEAL, BLOWER/COLLECTOR DUCT 12001324 DUCT KIT, COLLECTOR 25-7810 SCREW 8-18X1/2 TRUSS H 53-0204 SEAL LA-1005 SWITCH KIT (INCL. 23 & 24) 53-0918 FILTER, LINT 53-0281...
- Page 20 Section: HEATER Model: HYE3657AYW LD15-10...
- Page 21 Section: HEATER Part No. Description Series Qty 31001499 ELEMENT, HEATING (4750W) 25-7863 SCREW 53-1232 HEATER HOUSING ASSEMBLY 53-0771 THERMOSTAT, HI-LIMIT 53-0285 BRACKET, THERMOSTAT 25-6121 SCREW 53-1182 FUSE, THERMAL 53-1181 BRACKET, THERMAL FUSE *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available...
- Page 22 Section: WIRING INFORMATION (SERIES 15 ELEC) Model: HYE3657AYW 15003591...
- Page 23 Section: WIRING INFORMATION (SERIES 15 ELEC) Part No. Description Series Qty N 15003591 WIRING INFORMATION *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available...
