SR Mini HG SYSTEM
Power Supply/CPU Module
H-PCP-J

PLC Communication

Instruction Manual
[For OMRON PLC]
IMS01J04-E1
RKC INSTRUMENT INC.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Mini HG SYSTEM H-PCP-J and is the answer not in the manual?

Questions and answers

Related Manuals for RKC INSTRUMENT SR Mini HG SYSTEM H-PCP-J

Summary of Contents for RKC INSTRUMENT SR Mini HG SYSTEM H-PCP-J

  • Page 1: Plc Communication

    SR Mini HG SYSTEM Power Supply/CPU Module H-PCP-J PLC Communication Instruction Manual [For OMRON PLC] IMS01J04-E1 RKC INSTRUMENT INC. ®...
  • Page 2 The name of each programmable controller (PLC) means the products of each manufacturer. Company names and product names used in this manual are the trademarks or registered trademarks of the respective companies. All Rights Reserved, Copyright  2004, RKC INSTRUMENT INC.
  • Page 3 Thank you for purchasing this RKC instrument. In order to achieve maximum performance and ensure proper operation of your new instrument, carefully read all the instructions in this manual. Please place this manual in a convenient location for easy reference.
  • Page 4 The figures, diagrams and numeric values used in this manual are only for purpose of illustration. RKC is not responsible for any damage or injury that is caused as a result of using this instrument, instrument failure or indirect damage.

  • Page 5: Table Of Contents

    CONTENTS Page 1. OUTLINE................1 2. COMMUNICATION SPECIFICATIONS........ 3 3. CONNECTIONS ..............4 4. SETTING ON THE H-PCP-J MODULE SIDE....... 6 4.1 PLC Data Memory Address Setting..............6 4.2 Protocol Selection and Communication Setting..........8 4.3 PLC Scanning Time Setting................9 5. SETTING ON THE PLC SIDE..........10 6.
  • Page 6 MEMO IMS01J04-E1...

  • Page 7: Outline

    1. OUTLINE This manual describes the communication function of the SR Mini HG SYSTEM and the OMRON programmable controller (hereafter called PLC). This manual is attached when the model code of H-PCP-J module is H-PCP-J- -D∗ -03E. For details of the H-PCP-J module, see the Power Supply/CPU Module H-PCP-J Instruction Manual (IMS01J02-E ).
  • Page 8 The following function module data can be used in PLC communication (see “Data map” on page 24). In addition, data on other modules connected (TI, AI, AO, etc.) can be used on one more communication port (RKC communication or Modbus). Function module...

  • Page 9: Communication Specifications

    2. COMMUNICATION SPECIFICATIONS Interface: Based on RS-422A, EIA standard Connection method: RS-422A: 4-wire system, multi-drop connection Synchronous method: Start/stop synchronous type Communication speed: 9600 bps, 19200 bps, 38400 bps Communication speed can be selected with switch Data bit configuration: Start bit: 1 Data bit: 7 Parity bit: Even Stop bit:...

  • Page 10: Connections

    3. CONNECTIONS RS-422A Pin layout of modular connector (RS-422A) COM.PORT1 H-PCP-J module R (A) R (B) T (B) T (A) Connector pin number and signal details (RS-422A) Pin No. Signal name Symbol Receive data R (A) Receive data R (B) Signal ground Send data T (B)
  • Page 11 Because there is not SG, in case of SYSMAC CS1 series, electric wiring is unnecessary. Customer is requested to prepare a communication cable fit for the control unit to be connected by the PLC. Connection cable W-BF-01 * (RKC product) can use to connect PLC.

  • Page 12: Setting On The H-Pcp-J Module Side

    4. SETTING ON THE H-PCP-J MODULE SIDE 4.1 PLC Data Memory Address Setting Set the data memory address of each control unit using the unit address setting switch at the front of the H-PCP-J module. For this setting, use a small blade screwdriver. Unit address setting switch Setting range: 0 to 15 (0 to F: hexadecimal)
  • Page 13 4. SETTING ON THE H-PCP-J MODULE SIDE Setting example: When group 2 is used Unit address 4 SR Mini HG SYSTEM Data memory control unit address: D3000 to D3499 Unit address 5 SR Mini HG SYSTEM Data memory control unit address: Address in the same D3500 to D3999...

  • Page 14: Protocol Selection And Communication Setting

    4. SETTING ON THE H-PCP-J MODULE SIDE 4.2 Protocol Selection and Communication Setting Match the setting of data bit configuration, communication speed and communication protocol with the PLC communication specification by COM.PORT1/COM.PORT2 setting switch (SW2). Setting example to recommend is shown in the following. COM.PORT1/COM.PORT2 H-PCP-J module setting switch (SW2)

  • Page 15: Plc Scanning Time Setting

    4.3 PLC Scanning Time Setting Set the PLC scanning time (time of waiting for a response from the PLC) so as to adapt to the environment used. The PLC scanning time is set via host communication (RKC communication or Modbus).

  • Page 16: Setting On The Plc Side

    5. SETTING ON THE PLC SIDE Set the PLC as follows. (Recommend setting example) Item Description Serial communication mode High-order link Unit number (Model number) 0 Start bit Data bit Stop bit Parity bit Even Transmission speed Set the same as SR Mini HG SYSTEM I/O port selection RS-422A Synchronization selection...

  • Page 17: Communication Data

    6. COMMUNICATION DATA 6.1 Request Command and Data Transfer Data transfer between PLC and SR Mini HG SYSTEM are executed by request command. Request command “0: Monitor (PLC ← SR Mini HG SYSTEM)” Command which status requests the SR Mini HG SYSTEM to write data such as temperature measured values, etc.
  • Page 18 6. COMMUNICATION DATA Data transfer procedures Change each set value of SR Mini HG SYSTEM from the PLC after the initial settings are made. If each set value of SR Mini HG SYSTEM is changed from the PLC without setting the initial values, it is re-written to 0 with each set value of the PLC at that time set to 0.
  • Page 19 6. COMMUNICATION DATA Data setting (When transmit data of temperature setting values from PLC to SR Mini HG SYSTEM) Start Set temperature set value (SV) and other setting data to each register (memory) in the PLC. [Data setting] Set “1” to the request When 1 (Setting) is set to request command, the command starts reading the temperature set...
  • Page 20 6. COMMUNICATION DATA Continued from the previous page. [Confirmation of setting data] Set “2” to the request When 2 (Set value monitor) is set to request command, command starts writing the temperature SR Mini HG SYSTEM set value data set to the PLC side. PCP communication If 3 (Writing on setting data) is set to PCP state = 3 ?

  • Page 21: Data Processing Precautions

    6. COMMUNICATION DATA 6.2 Data Processing Precautions With PLC communication, the maximum number of channels per unit address is 20. Read data of unused channel and undefined address is 0. The data type is treated as binary data with a sign and without a decimal point. For this reason, carefully express and set the data.
  • Page 22 6. COMMUNICATION DATA Some communication data may become invalid depending on the module selection or the configuration of the SR Mini HG System control unit. If any one of the conditions listed below occurs and data items written are within the setting range, read data becomes 0.

  • Page 23: Communication Data List

    6. COMMUNICATION DATA 6.3 Communication Data List • Name Item stored in the memory area. [ ]: The functional module name that data becomes valid is written. • Attributes RO: At the time of request command “0: Monitor,” SR Mini HG SYSTEM writes in data. (SR Mini HG SYSTEM →...
  • Page 24 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Heater break alarm 0.0 to 100.0 A or 0.0 to 30.0 A set value For the current transformer (CT) input of the [H-CT-A] H-CT-A module.
  • Page 25 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Integral time H-TIO- , 1 to 3600 seconds [H-TIO- , H-CIO-A, H-CIO-A: H-SIO-A] H-SIO-A: Derivative time H-TIO- , 0 to 3600 seconds (0: PI action) [H-TIO- , H-CIO-A, H-CIO-A: H-SIO-A]...
  • Page 26 6. COMMUNICATION DATA Continued from the previous page. Conditions which will cause the autotuning to stop: • When the temperature set value (SV) is changed. • When the memory area is changed. • When the PV bias value is changed. •...
  • Page 27 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  Temperature measured TC/RTD input: value (PV) Within input range [H-TIO- , H-CIO-A] Current/voltage input: Within display scale range Motor speed measured Within display scale range ...
  • Page 28 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value 0: Monitor Request command Command which requests the SR Mini HG [H-PCP-J] SYSTEM to write data such as temperature measured values, etc. (attribute: RO) to the PLC side.
  • Page 29 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  PCP normal The numbers 0 and then 1 are repeated in communication flag every communication period. [H-PCP-J] The SR Mini HG SYSTEM rewrites 0 and 1 in this area alternately like 0 →...

  • Page 30: Data Map

    7. DATA MAP 7.1 Reference to Data Map This data map summarizes the data (data memory) addresses, channels and names that can be used with PLC. For details on each data range, see the 6.3 Communication Data List (P. 17). Unit Unit Unit...

  • Page 31: Data Map List

    7. DATA MAP 7.2 Data Map List Unit address 0 to 3 (Group 1) Unit Unit Unit Unit address address address address Name D1000 to D1500 to D2000 to D2500 to Temperature set value (SV) CH1 to CH20 D1019 D1519 D2019 D2519 D1020 to...
  • Page 32 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name D1383 to D1883 to D2383 to D2883 to Do not use this address range D1389 D1889 D2389 D2889 D1390 D1890 D2390 D2890 Memory area number D1391 D1891 D2391...
  • Page 33 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name D3240 to D3740 to D4240 to D4740 to PID/AT transfer CH1 to CH20 D3259 D3759 D4259 D4759 D3260 to D3760 to D4260 to D4760 to Temperature measured value (PV) CH1 to CH20...
  • Page 34 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name D5080 to D5580 to D6080 to D6580 to Operation mode transfer CH1 to CH20 D5099 D5599 D6099 D6599 D5100 to D5600 to D6100 to D6600 to Auto/Manual transfer CH1 to CH20...
  • Page 35 7. DATA MAP Unit address C to F (Group 4) Unit Unit Unit Unit address address address address Name D7000 to D7500 to D8000 to D8500 to Temperature set value (SV) CH1 to CH20 D7019 D7519 D8019 D8519 D7020 to D7520 to D8020 to D8520 to...
  • Page 36 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name D7390 D7890 D8390 D8890 Memory area number D7391 D7891 D8391 D8891 Control RUN/STOP transfer D7392 to D7892 to D8392 to D8892 to Do not use this address range D7399 D7899 D8399...

  • Page 37: Current Transformer (Ct) Monitor

    8. CURRENT TRANSFORMER (CT) MONITOR Current transformer (CT) monitor function monitors only current transformer input. Control unit is configured with H-PCP-J module and H-CT-A module to do current transformer (CT) monitor. Data of functional module other than the H-CT-A module cannot be used. In addition, set the communication protocol to “OMRON SYSMAC series special protocol [Current transformer (CT) monitor].”...
  • Page 38 8. CURRENT TRANSFORMER (CT) MONITOR Current transformer (CT) monitor dedicated system configuration SR Mini HG SYSTEM control unit H-CT-A module H-PCP-J (10 modules max.) OMRON SYSMAC series module RS-422A SR Mini HG SYSTEM control unit RS-422A H-CT-A module H-PCP-J (10 modules max.) module RS-422A Up to 16 control units per communication port of PLC...

  • Page 39: Setting On The H-Pcp-J Module Side

    8. CURRENT TRANSFORMER (CT) MONITOR 8.1 Setting on The H-PCP-J Module Side PLC data memory address setting Set the data memory address of each control unit using the unit address setting switch at the front of the H-PCP-J module. For this setting, use a small blade screwdriver. Unit address setting switch Setting range: 0 to 15 (0 to F: hexadecimal)
  • Page 40 8. CURRENT TRANSFORMER (CT) MONITOR Continued from the previous page. Unit address PLC data Communication item setting memory switch address D9360 to Unit address 6 Current transformer input measured value D9419 CT1 to CT60 D9967 Unit address 6 PCP normal communication flag D9420 to Unit address 7 Current transformer input measured value D9479...
  • Page 41 8. CURRENT TRANSFORMER (CT) MONITOR Protocol selection and communication setting Match the setting of data bit configuration, communication speed and communication protocol with the PLC communication specification by COM.PORT1/COM.PORT2 setting switch (SW2). Setting example to recommend is shown in the following. COM.PORT1/COM.PORT2 H-PCP-J module setting switch (SW2)
  • Page 42 PLC scanning time setting Set the PLC scanning time (time of waiting for a response from the PLC) so as to adapt to the environment used. The PLC scanning time is set via host communication (RKC communication or Modbus). PLC scanning time setting...

  • Page 43: Setting On The Plc Side

    8. CURRENT TRANSFORMER (CT) MONITOR 8.2 Setting on The PLC Side Set the PLC as follows. (Recommend setting example) Item Description Serial communication mode High-order link Unit number (Model number) 0 Start bit Data bit Stop bit Parity bit Even Transmission speed Set the same as SR Mini HG SYSTEM I/O port selection...

  • Page 44: Communication Data List

    8. CURRENT TRANSFORMER (CT) MONITOR 8.3 Communication Data List Attributes RO: SR Mini HG SYSTEM writes in data. (SR Mini HG SYSTEM → PLC) If the power is turned on, SR Mini HG SYSTEM always writes data to PLC. As for the setting of request command from PLC, there is not requirement.
