SR Mini HG SYSTEM
Power Supply/CPU Module
H-PCP-J
Instruction Manual
IMS01J02-E2
RKC INSTRUMENT INC.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Mini HG System H-PCP-J and is the answer not in the manual?

Questions and answers

Related Manuals for RKC INSTRUMENT SR Mini HG System H-PCP-J

Summary of Contents for RKC INSTRUMENT SR Mini HG System H-PCP-J

  • Page 1 SR Mini HG SYSTEM Power Supply/CPU Module H-PCP-J Instruction Manual IMS01J02-E2 RKC INSTRUMENT INC. ®...
  • Page 2 The name of each programmable controller (PLC) means the products of each manufacturer. Company names and product names used in this manual are the trademarks or registered trademarks of the respective companies. All Rights Reserved, Copyright  2004, RKC INSTRUMENT INC.
  • Page 3 Thank you for purchasing this RKC instrument. In order to achieve maximum performance and ensure proper operation of your new instrument, carefully read all the instructions in this manual. Please place this manual in a convenient location for easy reference.
  • Page 4 The figures, diagrams and numeric values used in this manual are only for purpose of illustration. RKC is not responsible for any damage or injury that is caused as a result of using this instrument, instrument failure or indirect damage.

  • Page 5: Table Of Contents

    CONTENTS Page 1. OUTLINE................1 1.1 Features ......................1 1.2 Handling Procedures ..................2 1.3 Checking the Products ..................3 1.4 Confirmation of the Model Code ..............4 1.5 System Configuration ..................6 1.6 Parts Description ...................12 2. SPECIFICATIONS .............. 14 3. MOUNTING ................. 20 3.1 Mounting Cautions..................20 3.2 Dimensions....................21 3.3 Mounting the Mother Block ................22...
  • Page 6 Page 6. RKC COMMUNICATION ............ 52 6.1 Protocol ......................52 6.1.1 Polling ........................ 52 6.1.2 Selecting ......................57 6.1.3 Communication data structure ................60 6.1.4 Examples of polling and selecting check programs ........... 61 6.2 Communication Identifier List ................65 6.3 Initial Setting (Extended Communication)............81 7.
  • Page 7 Page 8.2.6 Scale correction ....................179 8.2.7 Output change rate limiter................181 8.2.8 Alarm hold function ..................182 8.2.9 Assignment of channels ................... 183 9. TROUBLESHOOTING............184 10. ASCII 7-BIT CODE TABLE ..........190 IMS01J02-E2...
  • Page 8 MEMO IMS01J02-E2...

  • Page 9: Outline

    COM.PORT3 COM.PORT1/COM.PORT2 Interface: RS-422A Interface: RS-232C RS-422A RS-485 RS-485 Protocol: RKC communication protocol Protocol: RKC communication protocol Modbus protocol The protocol corresponding to each PLC * Modbus protocol (Any can be selected with switch) (Any can be selected with switch)

  • Page 10: Handling Procedures

    See PLC Communication Instruction Manual LG MASTER-K and GLOFA-GM series [For LG PLC] (IMS01J06-E ) Settings prior to operation RKC and MODBUS communication See P. 43 Protocol Selection and Host Communication Setting See P. 48 Unit Address Setting PLC communication...

  • Page 11: Checking The Products

    1.3 Checking the Products When unpacking your new instrument, please confirm that the following products are included. If any of the products are missing, damaged, or if your manual is incomplete, please contact RKC sales office or agent for replacement.

  • Page 12: Confirmation Of The Model Code

    The model code for the instrument you received is listed below. Please confirm that you have received the correct instrument by checking the model code label, located on the left side of the module, with this list. If the product you received is not the one ordered, please contact RKC sales office or agent for replacement.
  • Page 13 1. OUTLINE Initial code NNNN - (1) (2) (3) (4) (3) AI alarm 1 function (1) TI alarm 1 function N: No alarm function N: No alarm function : See TI/AI alarm code table (P. 5) : See TI/AI alarm code table (P. 5) (4) AI alarm 2 function (2) TI alarm 2 function N: No alarm function...

  • Page 14: System Configuration

    RS-422A Function module (10 modules max.) H-PCP-J Touch panel RS-422A SR Mini HG SYSTEM control unit RS-422A To RKC operation panel RS-422A RS-485 RS-232C To host computer To touch panel Up to 4 units per communication port of PLC : The protocol corresponding to...
  • Page 15 RS-422A H-CT-A module (10 modules max.) H-PCP-J Touch panel RS-422A SR Mini HG SYSTEM control unit RS-422A To RKC operation panel RS-422A RS-485 RS-232C To host computer To touch panel Up to 16 units per communication port of PLC : PLC special protocol...
  • Page 16 (10 modules max.) H-PCP-J RS-422A RS-485 RS-232C SR Mini HG SYSTEM control unit RS-422A When the RKC operation panel is connected: Up to 8 units : RKC communication protocol : RKC communication protocol Modbus protocol Any can be selected IIMS01J02-E2...
  • Page 17 SR Mini HG SYSTEM control unit RS-422A RS-485 When the host computer is connected: Up to 16 units When the is touch panel connected: Up to 16 units : RKC communication protocol : RKC communication protocol Modbus protocol Any can be selected IIMS01J02-E2...
  • Page 18 1. OUTLINE Usable modules The following function modules can be used in combination with the H-PCP-J module. However, usable module is different by protocol. RKC communication protocol/Modbus protocol Function module Type Temperature control module H-TIO-A H-TIO-B H-TIO-C H-TIO-D H-TIO-E H-TIO-F...

  • Page 19: Omron Sysmac Series

    1. OUTLINE Precautions for PLC communication system configuration When a system is configured by connecting a PLC, the protocol dedicated to the PLC (for temperature control) cannot be used together with the current transformer (CT) monitor. MITSUBISHI MELSEC series SR Mini HG SYSTEM control unit MITSUBISHI MELSEC series H-PCP-J module Set the MITSUBISHI MELSEC series special protocol...

  • Page 20: Parts Description

    1. OUTLINE 1.6 Parts Description H-PCP-J module (10) (11) Front Side Name Description Unit address setting switch Set unit address number of control unit Setting range: 0 to 15 (0 to F, hexadecimal) Status indication lamps RX1 (data reception) lamp [Yellow] ON during COM.PORT1/COM.PORT2 data is correctly received RX2 EVENT FAIL...
  • Page 21 1. OUTLINE Continued from the previous page. Name Description Modular connector (COM.PORT3) Connector for connection with the host computer, touch panel or operation panel (Conforming to RS-232C/RS-422A/RS-485) DO connector Connector for digital output Power terminals Power supply and ground terminals Modular connector (COM.PORT2) Connector for the control unit addition (Conforming to RS-422A/RS-485)

  • Page 22: Specifications

    2. SPECIFICATIONS Basic functions Data supervision: Operating and system data Control unit diagnosis: Function modules configuration check Self-diagnostic: Check item: ROM/RAM check Watchdog timer Power supply monitoring If error occurs in self-diagnosis, the hardware will automatically return the module outputs to the OFF position. Memory backup: Lithium battery for RAM backup, approximate 10 years life for data retention.

  • Page 23: Digital Output

    2. SPECIFICATIONS Digital output Number of outputs: 8 points Output type: Open collector output Number of common points: Vcc: 2 points, GND: 2 points (8 points/common) Isolation method: Photocoupler isolation Load voltage: 12 to 24 V DC Maximum load current: 0.1 A/point, 0.8 A/common Output data: Digital output can be selected from the following:...

  • Page 24: Communication Functions

    Specify when ordering Connection method: RS-422A: 4-wire system, multi-drop connection RS-485: 2-wire system, multi-drop connection • Based on ANSI X3.28 subcategory 2.5 B1 (RKC communication) Protocol: Error control: Vertical parity (when parity bit is selected) Horizontal parity Data types: ASCII 7-bit code •...
  • Page 25 2. SPECIFICATIONS Synchronous method: Start/stop synchronous type Communication speed: 9600 bps, 19200 bps, 38400 bps Communication speed can be selected with switch Data bit configuration: Start bit: Data bit: 7 or 8 Parity bit: Without, Odd or Even Without for 8 data bits Stop bit: 1 or 2 Data bit configuration can be selected with switch...
  • Page 26 Connection method: RS-232C: Point-to-point connection RS-422A: 4-wire system, multi-drop connection RS-485: 2-wire system, multi-drop connection • Based on ANSI X3.28 subcategory 2.5 B1 (RKC communication) Protocol: Error control: Vertical parity (when parity bit is selected) Horizontal parity Data types: ASCII 7-bit code •...

  • Page 27: General Specifications

    2. SPECIFICATIONS Signal logic: RS-232C Signal voltage Logic +3 V or more 0 (SPACE) −3 V or less 1 (MARK) RS-422A/RS-485 Signal voltage Logic V (A) − V (B) ≥ 2 V 0 (SPACE) V (A) −V (B) ≤ −2 V 1 (MARK) Voltage between V (A) and V (B) is the voltage of (A) terminal for the (B) terminal.

  • Page 28: Mounting

    3. MOUNTING This chapter describes the mounting procedures for the H-PCP-J modules. For details of the mounting procedures for other modules and the mounting position of the control unit, see the Hardware Quick Manual (IMS01V01-E ). WARNING To prevent electric shock or instrument failure, always turn off the power before mounting or removing the modules.

  • Page 29: Dimensions

    3. MOUNTING 3.2 Dimensions External dimensions (Unit: mm) Module mounting depth The mounting depth of each module is 108 mm from the mounting surface inside the panel to the front of the module with the module mounted on the DIN rail. However, when modular connector cables are plugged in, additional depth is required.

  • Page 30: Mounting The Mother Block

    3. MOUNTING 3.3 Mounting the Mother Block The mother block can be mounted to a panel or DIN rail. Mount the H-PCP-J module on the left side of the control unit. Panel mounting directions 1. Refer to both the panel mounting dimensions below and the external dimensions in previous section when selecting the location.
  • Page 31 3. MOUNTING DIN rail mounting directions 1. Remove the module mainframe from the mother block. For details of removing the module mainframe, see 3.5 Removing the Module Mainframe (P. 24). 2. Pull down both locking devices at the bottom of the mother block. (Figure 1) 3.

  • Page 32: Mounting The Module Mainframe

    3. MOUNTING 3.4 Mounting the Module Mainframe 1. Place the module mainframe opening on top of the mother block tab. (Figure 1) 2. Snap the lower part of module mainframe on to the mother block. (Figure 2) A snapping sound will be heard when module mainframe is securely connected to mother block. Opening at top of module Tab at top of mother block Figure 1...

  • Page 33: Wiring

    4. WIRING 4.1 Wiring WARNING To prevent electric shock or instrument failure, do not turn on the power until all the wiring is completed. CAUTION Power supply wiring: Use power supply as specified in power supply voltage range. Power supply wiring must be twisted and have a low voltage drop. Provide separate power supply for this instrument independent of other input/output circuits, motors, equipment and operating circuits.
  • Page 34 4. WIRING Terminal configuration Power terminals 24 V 200-240 V 100-120 V − Ground terminal Terminal Screws Screw size: M3 Recommended tightening torque: 0.4 N⋅m (4 kgf⋅cm) Power supply 90 to 132 V AC Including power supply voltage variations (Rating: 100 to 120 V AC, Single phase 50/60 Hz) 180 to 264 V AC Including power supply voltage variations (Rating: 200 to 240 V AC, Single phase 50/60 Hz)

  • Page 35: Connections

    4. WIRING 4.2 Connections WARNING To prevent electric shock or instrument failure, turn off the power before connecting or disconnecting the instrument and peripheral equipment. CAUTION Connect connectors correctly in the right position. If it is forcibly pushed in with pins in the wrong positions, the pins may be bent resulting in instrument failure.

  • Page 36: Do Connector Connection

    4. WIRING 4.2.1 DO connector connection Output type: Open collector output Number of common points: DO connector Vcc: 2 points, GND: 2 points (8 points/common) Isolation method: Photocoupler isolation Load voltage: 12 to 24 V DC Maximum load current: 0.1 A/point, 0.8 A/common Connector used: MIL connector AXM220011 (Manufactured by Matsushita...
  • Page 37 4. WIRING Open collector output wiring example COM (+) Load ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ In using the open collector output, ⋅ ⋅ an external power supply of 24 V Load DC is required. 12 to 24 V DC Note that if this power supply is not −...

  • Page 38: Connection To The Host Computer

    4. WIRING 4.2.2 Connection to the host computer Connection block diagram The communication interface for control unit are RS-232C *, RS-422A and RS-485. When using the RS-422A or RS-485, a maximum of 16 control units can be connected. However, when connecting to the computer which only has a RS-232C driver, RS-232C/RS-422A converter or RS-232C/RS-485 converter will be necessary.
  • Page 39 (Recommended type: TM12RV-64-H manufactured by HIROSE ELECTRIC CO., LTD.) when connector of host computer is D-SUB 25-pin. Cable type: W-BF-28-3000 (RKC product, Sold separately) [Standard cable length: 3 m] Pin layout of modular connector (RS-232C) H-PCP-J module COM.PORT3 Unused...
  • Page 40 Customer is requested to prepare a communication cable fit for the control unit to be connected by the host computer. Connection cable W-BF-02 * and W-BF-28 * (RKC product) can use to connect host computer. * Shields of the cable are connected to SG (No. 6 pin) of the H-PCP-J connector.
  • Page 41 W-BF-02-3000 (RKC product, Sold separately) D-SUB 25-pin. [Standard cable length: 3 m] W-BF-28-3000 (RKC product, Sold separately) [Standard cable length: 3 m] Recommended RS-232C/RS-422A converter: COM-A (RKC product) For the COM-A, see the COM-A/COM-B Instruction Manual (IMSRM33-E ). IMS01J02-E2...
  • Page 42 Shielded twisted pair wire Customer is requested to prepare a communication cable fit for the control unit to be connected by the host computer. Connection cable W-BF-02 * and W-BF-28 * (RKC product) can use to connect host computer. * Shields of the cable are connected to SG (No. 6 pin) of the H-PCP-J connector.
  • Page 43 Connect to the communication connector Host computer Cable type: W-BF-01-3000 (RKC product, Sold separately) [Standard cable length: 3 m] When the host computer (master) uses Windows 95/98/NT, use a RS-232C/RS-485 converter with an automatic send/receive transfer function. Recommended: CD485, CD485/V manufactured by Data Link, Inc. or equivalent.
  • Page 44 Shielded twisted pair wire Customer is requested to prepare a communication cable fit for the control unit to be connected by the host computer. Connection cable W-BF-01 * (RKC product) can use to connect host computer. * Shields of the cable are connected to SG (No. 6 pin) of the H-PCP-J connector.

  • Page 45: Connection To The Operation Panel

    4. WIRING 4.2.3 Connection to the operation panel For the connection cable, use the RKC product (Sold separately). Cable type: W-BF-02-3000 [Standard cable length: 3 m] Control unit RS-422A Connect to the modular connector on operation panel W-BF-02 [COM.PORT] OPM-HL4...

  • Page 46: Connection To The Touch Panel

    4. WIRING 4.2.4 Connection to the touch panel RS-232C Pin layout of modular connector (RS-232C) H-PCP-J module COM.PORT3 Unused Unused Connector pin number and signal details (RS-232C) Pin No. Signal name Symbol Unused － Send data SD (TXD) Signal ground Receive data RD (RXD) －...
  • Page 47 4. WIRING RS-422A Pin layout of modular connector (RS-422A) COM.PORT1 H-PCP-J module COM.PORT3 R (A) R (B) T (A) T (B) T (B) T (A) R (B) R (A) Connector pin number and signal details (RS-422A) Pin No. Signal name Symbol Receive data R (A)
  • Page 48 4. WIRING RS-485 Pin layout of modular connector (RS-485) COM.PORT1 H-PCP-J module COM.PORT3 1 T/R (A) 2 T/R (B) Unused Unused Unused Unused T/R (B) 2 T/R (A) 1 Connector pin number and signal details (RS-485) Pin No. Signal name Symbol Send/receive data T/R (A)

  • Page 49: Multiple Control Unit Connections

    (Unit address 1) Connect to the [COM.PORT2] on H-PCP-J module W-BF-02 Extension control unit (Unit address 2) Connect to the [COM.PORT1] on H-PCP-J module Unit address 3 Cable type: W-BF-02-3000 (RKC product, Sold separately) [Standard cable length: 3 m] IMS01J02-E2...
  • Page 50 Extension control unit (Unit address 2) Junction terminals or Control unit (Unit address 3) RS-422A RS-485 Connect to the [COM.PORT3] Cable type: W-BF-01-3000 (RKC product, Sold separately) on H-PCP-J module [Standard cable length: 3 m] [RS-422A] Orange R(B) R(B) White...

  • Page 51: Settings Before Operation

    5. SETTINGS BEFORE OPERATION 5.1 Protocol Selection and Host Communication Setting WARNING To prevent electric shock or instrument failure, always turn off the power before setting the switch. To prevent electric shock or instrument failure, never touch any section other than those instructed in this manual.
  • Page 52 5. SETTINGS BEFORE OPERATION COM.PORT1/COM.PORT2 setting switch (SW2) Data bit configuration Data 8-bit, Without parity, Stop 1-bit Data 7-bit, Odd parity, Stop 1-bit Data 7-bit, Even parity, Stop 1-bit Data 7-bit, Even parity, Stop 2-bit Factory set value: Data 8-bit, Without parity, Stop 1-bit Communication speed 9600 bps 19200 bps...
  • Page 53 5. SETTINGS BEFORE OPERATION COM.PORT1/COM.PORT2 setting switch (SW2) Protocol RKC communication protocol (Based on ANSI X3.28 subcategory 2.5 B1) See 6. RKC COMMUNICATION (P. 52). Modbus protocol See 7. MODBUS (P. 109). MITSUBISHI MELSEC series special protocol AnA/AnUCPU common command (QW/QR) See PLC Communication Instruction Manual [For MITSUBISHI PLC] (IMS01J03-E ).
  • Page 54 Don't set this one Factory set value: 9600 bps Protocol RKC communication protocol (Based on ANSI X3.28 subcategory 2.5 B1) See 6. RKC COMMUNICATION (P. 52). Modbus protocol See 7. MODBUS (P. 109). Factory set value: RKC communication protocol Initialize...
  • Page 55 5. SETTINGS BEFORE OPERATION COM.PORT3 setting switch (SW3) Modbus mode selection Modbus mode 1 (Data time interval judges time-out with 24-bit time or more.) This mode is based on Modbus RTU standard. Modbus mode 2 (Data time interval judges time-out with 24-bit time + 2 ms or more.) As time intervals between each data configuring one message become longer than the 24-bit time when sending a command message from the master, it is set when the slave does not make a response.

  • Page 56: Unit Address Setting

    5. SETTINGS BEFORE OPERATION 5.2 Unit Address Setting When each control unit is multi-drop connected to host computer, set the unit address of each control unit using the unit address setting switch at the front of the H-PCP-J module. For this setting, use a small blade screwdriver.

  • Page 57: Start-Up Procedures

    5. SETTINGS BEFORE OPERATION 5.3 Start-up Procedures Check prior to power on Check the following items before turning on the power to the control unit. Operation environments conform to 3.1 Mounting Cautions (P. 20). Wiring and connections conform to 4. WIRING (P. 25). Power supply voltage conforms to 2.

  • Page 58: Communication Requirements

    SR Mini HG SYSTEM to send data: -Response wait time after SR Mini HG SYSTEM sends BCC in polling procedure -Response wait time after SR Mini HG SYSTEM sends ACK or NAK in selecting procedure RKC communication (Polling procedure) Time (ms) Procedure details Response send time after SR Mini HG SYSTEM receives ENQ −...
  • Page 59 5. SETTINGS BEFORE OPERATION RS-485 (2-wire system) send/receive timing The sending and receiving of RS-485 communication is conducted through two wires; consequently, the transmission and reception of data requires precise timing. Typical polling and selecting procedures between the host computer and SR Mini HG SYSTEM are described below: Polling procedure Possible Send data...

  • Page 60: Rkc Communication

    6. RKC COMMUNICATION 6.1 Protocol RKC communication uses the polling/selecting method to establish a data link. The basic procedure is followed ANSI X3.28 subcategory 2.5, B1 basic mode data transmission control procedure (Fast selecting is the selecting method used in SR Mini HG SYSTEM).
  • Page 61 6. RKC COMMUNICATION Polling procedures (1) Data link initialization Host computer sends EOT to the controllers to initiate data link before polling sequence. (2) Data sent from host computer - Polling sequence Host computer sends polling sequence with the format shown below:...
  • Page 62 6. RKC COMMUNICATION 1. STX STX is the transmission control character which indicates the start of the text transmission (identifier and data). 2. Identifier (2 digits) The identifier indicates the type of data (measured value, status and set value) sent to the host computer.
  • Page 63 6. RKC COMMUNICATION (4) EOT send (Ending data transmission from the SR Mini HG SYSTEM) In the following cases, the SR Mini HG SYSTEM sends EOT to terminate the data link: • When the specified identifier is invalid • When there is an error in the data format •...
  • Page 64 6. RKC COMMUNICATION Polling procedure example (When the host computer requests data) Normal transmission Host computer send Host computer send 04H 30H 31H 53H 31H 05H … Address Identifier 02H 53H 31H 30H 31H 20H 20H 34H 30H 30H 2EH 30H...

  • Page 65: Selecting

    6. RKC COMMUNICATION 6.1.2 Selecting Selecting is the action where the host computer requests one of the connected SR Mini HG SYSTEM to receive data. An example of the selecting procedure is shown below: Host computer Host computer send SR Mini HG SYSTEM...
  • Page 66 6. RKC COMMUNICATION (3) Data sent from the host computer The host computer sends data for the selecting sequence with the following format: Identifier Data Identifier Data If the length of send data (from STX to BCC) exceeds 128 bytes, it is divided into blocks by ETB.
  • Page 67 6. RKC COMMUNICATION Selecting procedure example (when the host computer sends data) Normal transmission Host computer send … 04H 30H 31H 02H 53H 31H 30H 31H 20H 20H 34H 30H 30H 2EH 30H 03H 57H Address Identifier Channel No. Data...

  • Page 68: Communication Data Structure

    6. RKC COMMUNICATION 6.1.3 Communication data structure Data description (Transmission/receive data structure) ......................Data Part of the data above is shown below. Data for each channel Data length 6 digits 1 0 0 Identifier Channel Data Channel Data Channel Data...

  • Page 69: Examples Of Polling And Selecting Check Programs

    6. RKC COMMUNICATION 6.1.4 Examples of polling and selecting check programs The following is the sample program for NEC PC-9800 series computers in BASIC language for carrying out polling and selecting checking by RS-232C specification. There will be some differences in the computer languages according to the type of computer.
  • Page 70 6. RKC COMMUNICATION 1320 ' 1330 DT$=DT$+K$ 1340 GOTO *J10 1350 ' 1360 *ETXRX 1370 DT$=DT$+K$ 1380 BCCRX$=INPUT$(1,#1) 1390 BCCRX=ASC(BCCRX$) BCC checking 1400 GOSUB *BCCCH 1410 IF BCC<>BCCRX THEN GOSUB *NAKTX 1420 IF BCC<>BCCRX THEN GOSUB *RXDT: GOTO *J10 1430 ' 1440 PRINT "Data has been correctly received"...
  • Page 71 6. RKC COMMUNICATION Example of temperature set values selecting checking program 1000 '-------------------- Identifier setting ---------------------- 1010 ID$="S1" Identifier setting 1020 ' 1030 '--------------- Communications initial setting --------------- 1040 CM$="N81NN" Communications data configuration setting 1050 STX$=CHR$(&H2) : EOT$=CHR$(&H4) : ENQ$=CHR$(&H5) Communications character setting 1060 ACK$=CHR$(&H6) : NAK$=CHR$(&H15): ETX$=CHR$(&H3)
  • Page 72 6. RKC COMMUNICATION 1360 '--------------------- Sub-routine ---------------------- 1370 ' 1380 *RXDT' 1390 DT$="" 1400 RETURN Clearing of circuit buffer 1410 ' 1420 *TEXT 1430 PRINT #1,DT$; 1440 RETURN Transfer of selection data 1450 ' 1460 *BCCCH 1470 FOR II=1 TO LEN(DT$)

  • Page 73: Communication Identifier List

    6. RKC COMMUNICATION 6.2 Communication Identifier List Note that there are identifiers which indicate that communication is not possible depending on the specification. • Name Item stored in the memory area. [ ]: The functional module name that data becomes valid is written.
  • Page 74 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value  Heat-side manipulated −5.0 to +105.0 % output value [H-TIO- , H-CIO-A]  Cool-side manipulated −5.0 to +105.0 % output value...
  • Page 75 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value PID/AT transfer * 0: PID control operation [H-TIO- , H-CIO-A, 1: AT (Autotuning) operation H-SIO-A] * Autotuning (AT) is the function which automatically measures, calculates and sets the optimum PID constants according to the set temperature.
  • Page 76 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Temperature set value TC/RTD input: (SV) Within input range [H-TIO- , H-CIO-A] (Within setting limiter) Current/voltage input: Within display scale range...
  • Page 77 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value See Factory Alarm 1 set value TC/RTD input: [H-TIO- , H-CIO-A, set value Within input range or span H-SIO-A] table of...
  • Page 78 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Operation mode transfer 0: Unused [H-TIO- , H-CIO-A, If set to “Unused,” no control, H-SIO-A] monitor or alarm monitor is performed.
  • Page 79 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value 0: Normal communication Initial setting mode Normal communication is [H-PCP-J] possible. 1: Extended communication Normal and initial setting communication are possible.
  • Page 80 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Temperature rise 0: Unused 1: Used completion trigger Do not set “1: Used” in [H-TIO- , H-CIO-A] H-TIO-H/J module and...
  • Page 81 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Control loop break  0: OFF 1: ON alarm (LBA) status [H-TIO- , H-CIO-A] LBA use selection 0: Unused 1: Used...
  • Page 82 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value AO corresponding 1 to 20 (TIO channel) channel setting 1 to 40 (AI and TI channel) [H-AO-A/B] Setting will be valid in recorder output mode.
  • Page 83 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Event DO status 0 to 255  [H-DO-C] Contact output status is expressed as a bit image in decimal number.
  • Page 84 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value  TI measured value Within input range [H-TI-A/B/C]  TI alarm 1 status 0: OFF 1: ON [H-TI-A/B/C]  TI alarm 2 status...
  • Page 85 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Event DI contact input 0 to 255  monitor Contact input status is [H-DI-B] expressed as a bit image in decimal number.
  • Page 86 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value H-CT-A module heater  0: Normal break alarm status 1: Break [H-CT-A] 2: Welding Comprehensive alarm 0 to 2047 * ...
  • Page 87 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value H-DO-G manipulated −5.0 to +105.0 %  output value [H-DO-G] H-DO-G  0 to 65535 * DO output status Output status is expressed as...
  • Page 88 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value PLC scanning time 0 to 3000 ms setting * [H-PCP-J] Integral time limiter at 1 to 3600 seconds 3600 AT end...

  • Page 89: Initial Setting (Extended Communication)

    If they are changed unnecessarily, it may result in malfunction or failure of the instrument. RKC will not bear any responsibility for malfunction or failure as a result of improper changes in the Initial setting.
  • Page 90 6. RKC COMMUNICATION Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Input range number The factory H-TIO-A/B/C/D/K/P: [H-TIO- , H-CIO-A, set value 0 to 63 H-SIO-A] varies H-TIO-E/F/G/R, H-CIO-A: depending 0 to 120 on the H-TIO-H/J, H-CIO-A:...
  • Page 91 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Input error TC/RTD input: Input range determination point Within input range (low) (low) Current/voltage input, Display [H-TIO- , H-CIO-A, H-SIO-A:...
  • Page 92 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value 0.00 to 10.00 % of span ON/OFF control 0.02 differential gap (upper) [H-TIO- , H-CIO-A, H-SIO-A] ON/OFF control 0.00 to 10.00 % of span 0.02...
  • Page 93 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Hot/Cold start selection 0: Hot start [H-TIO- , H-CIO-A, At restarting H-SIO-A] Operation mode → Same as mode before the power failure Output value →...
  • Page 94 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Control RUN/STOP 0: Not hold holding * Start-up from control stop [H-PCP-J] status 1: Hold Start-up from before the stop status...
  • Page 95 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value 0.00 to 10.00 % of span Alarm 1 differential gap 0.10 [H-TIO- , H-CIO-A, H-SIO-A] 0.00 to 10.00 % of span Alarm 2 differential gap 0.10...
  • Page 96 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Alarm 1 action at input 0: Normal alarm action error 1: Forced alarm ON when [H-TIO- , H-CIO-A, temperature measured...
  • Page 97 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value This identifier is unused 0000 to 9999 CH1: 9 with this module CH2: 1 Do not set this module (H-PCP-J).
  • Page 98 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value DI function selection 0: Unused [H-DI-A] 1: Function mode 1 − Memory area transfer (ENABLE terminal is used) After area selection setting,...
  • Page 99 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value AI input range number The factory 0: 0 to 10 mV DC [H-AI-A/B] set value 1: −10 to +10 mV DC...
  • Page 100 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value AI alarm 1 type The factory 0: Process high alarm selection set value 1: Process low alarm [H-AI-A/B] varies 2 to 6: No alarm function...
  • Page 101 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Display scale high H-TIO-H/J, Span 10000 or less [H-TIO-H/J, H-CIO-A, H-CIO-A: (Within −9999 to +10000) H-SIO-A] 100.0 H-SIO-A: Display scale low...
  • Page 102 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Event DO function 0 to 30 * selection [H-DO-C] Event DO corresponding 1 to 40 * channel setting [H-DO-C] Event DO mode select...
  • Page 103 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value 0: Unused Cascade DI function selection 1: Cascade control ON/OFF only [H-CIO-A] 2: Auto/Manual transfer only 3: DI1 valid (Cascade control ON/OFF) ,...
  • Page 104 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value TI input range number 0 to 120 The factory [H-TI-A/B/C] set value If the input range number is varies changed, all of the settings...
  • Page 105 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Event DI type selection 1 0 to 30 * [H-DI-B] (17 to 30: Not settable) Event DI type selection 2...
  • Page 106 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value Number of HBA trigger 0 to 255 times points [H-CT-A] Positioning adjustment 0 to 100 counter [H-TIO-K] H-PCP-J module 0 to 255...
  • Page 107 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value H-SIO-A input frequency 10 to 50000 Hz at full scale [H-SIO-A] H-SIO-A control range 0.00 to 50.00 % 10.00 [H-SIO-A]...
  • Page 108 6. RKC COMMUNICATION Continued from the previous page. Factory Iden- Attri- Struc- Name Digits Data range tifier bute ture value PV bias unit selection 0: % (of span) [H-TIO-H/J, H-CIO-A, 1: Unit of input range H-SIO-A] H-PCP-J module 0: No alarm function...
  • Page 109 6. RKC COMMUNICATION Event output function The event output function enables up to eight points to be output per module of unique alarms different from ordinary temperature and AI alarms (Extension alarm output function), control unit operations (Status output function) and comparison results which are output only under certain conditions (Data comparison output function).
  • Page 110 6. RKC COMMUNICATION Continued from the previous page. Status output function This function is used to output the control unit action status other than the extension alarm output in addition to the ordinary alarm output status (Alarm 1 status, etc.).
  • Page 111 6. RKC COMMUNICATION Continued from the previous page. Data comparison output function This function is used to output the result of comparison between the measured value and measured value (or set value and set value) within the same group. Event DO...
  • Page 112 6. RKC COMMUNICATION Continued from the previous page. [Relationship between output and comparison] Computing equation: The output turns ON at (Data 2) − (Data 1) ≤ 0 This means : The output turns ON if (Data 2) is smaller than or equal to (Data 1). {Data 2 ≤ Data 1} {Data 2 >...
  • Page 113 6. RKC COMMUNICATION Continued from the previous page. Event DI Event DI type selection corresponding (Identifier R1 to R4) Note channel selection Setting data Description (Identifier E1 to E4)  Input always OFF Always ON at “Reversal” selection Event DI input...
  • Page 114 6. RKC COMMUNICATION Positioning adjustment counter Setting data (Setting Item Description Status counter value) Normal status Opening adjustment star, open-side output start (Motor time: 110 %) Opening adjustment Capture the open-side opening value after 3 seconds Automatic stop Close-side output start (Motor time: 110 %)
  • Page 115 6. RKC COMMUNICATION Input range table Thermocouple input (H-TIO-A/B/C/D/E/G/K/P/R, H-TI-B/C, H-CIO-A) Input type Range No. Input type Range No. 0 to 400 °C 0.0 to 400.0 °C 0 to 800 °C 0 to 400 °C 0 to 1300 °C 0 to 200 °C 0.0 to 400.0 °C...
  • Page 116 6. RKC COMMUNICATION RTD input (H-TIO-A/B/C/D/E/F/G/K/P/R, H-TI-A/B, H-CIO-A) Input type Range No. 0.0 to 400.0 °C 0 to 400 °C −200 to +200 °C −200.0 to +200.0 °C −50.00 to +150.00 °C JPt100 −300 to +900 °F 0 to 800 °F 0.0 to 800.0 °F...

  • Page 117: Modbus

    7. MODBUS 7.1 Protocol The master controls communication between master and slave. A typical message consists of a request (query message) sent from the master followed by an answer (response message) from the slave. When master begins data transmission, a set of data is sent to the slave in a fixed sequence. When it is received, the slave decodes it, takes the necessary action, and returns data to the master.

  • Page 118: Function Code

    7. MODBUS 7.1.2 Function code Function code contents Function code Function Contents (Hexadecimal) Measured value, control output value, Current Read holding registers transformer input measured value, alarm status, etc. Set value, PV bias, PID constants, alarm set Preset single register value, etc.

  • Page 119: Slave Responses

    7. MODBUS 7.1.4 Slave responses (1) Normal response • In the response message of the Read Holding Registers, the slave returns the read out data and the number of data items with the same slave address and function code as the query message. •...

  • Page 120: Calculating Crc-16

    7. MODBUS 7.1.5 Calculating CRC-16 The Cyclic Redundancy Check (CRC) is a 2 byte (16-bit) error check code. After constructing the data message, not including start, stop, or parity bit, the master calculates a CRC code and appends this to the end of the message.
  • Page 121 7. MODBUS The flow chart of CRC-16 START FFFFH → CRC Register CRC Register ⊕ next byte of the message → CRC Register 0 → n Shift CRC Register right 1 bit Carry flag is 1 CRC Register ⊕ A001H → CRC Register n + 1 →...
  • Page 122 7. MODBUS Example of a CRC calculation in the ‘C’ language This routine assumes that the data types ‘uint16’ and ‘uint8’ exists. Theses are unsigned 16-bit integer (usually an ‘unsigned short int’ for most compiler types) and unsigned 8-bit integer (unsigned char). ‘z_p’...

  • Page 123: Message Format

    7. MODBUS 7.2 Message Format 7.2.1 Read holding registers [03H] The query message specifies the starting register address and quantity of registers to be read. The contents of the holding registers are entered in the response message as data, divided into two parts: the high-order 8-bit and the low-order 8-bit, arranged in the order of the register numbers.

  • Page 124: Preset Single Register [06H]

    7. MODBUS 7.2.2 Preset single register [06H] The query message specifies data to be written into the designated holding register. The write data is arranged in the query message with high-order 8-bit first and low-order 8-bit next. Only R/W holding registers can be specified.

  • Page 125: Diagnostics (Loopback Test) [08H]

    7. MODBUS 7.2.3 Diagnostics (Loopback test) [08H] The master’s query message will be returned as the response message from the slave. This function checks the communication system between the master and slave (SR Mini HG SYSTEM control unit). Example: Loopback test for slave address 1 Query message Slave address Function code...

  • Page 126: Preset Multiple Registers [10H]

    7. MODBUS 7.2.4 Preset multiple registers [10H] The query message specifies the starting register address and quantity of registers to be written. The write data is arranged in the query message with high-order 8-bit first and low-order 8-bit next. Only R/W holding registers can be specified. Example: Data is written into the two holding registers from 00C8H to 00C9H of slave address 1.

  • Page 127: Communication Data

    7. MODBUS 7.3 Communication Data 7.3.1 Data configuration The numeric range of data used in Modbus protocol is 0000H to FFFFH. Only the set value within the setting range is effective. FFFFH represents −1. Data processing with decimal points Data with decimal points The Modbus protocol does not recognize data with decimal points during communication.
  • Page 128 7. MODBUS Data with 3 digits below decimal point H-DO-G output ratio set value Cascade gain Example: When heater break alarm set value 1 is 20.0 A, 20.0 is processed as 200, 200 = C8H Heater break alarm High set value 1 Data without decimal points Status Decimal point position...
  • Page 129 7. MODBUS Continued from the previous page. AO function selection DI process selection AO corresponding channel setting Positioning adjustment counter AO decimal point position Heater break alarm status (H-CT-A) Event DI contact input monitor H-DI-A module input status Event DI logic input monitor H-DO-G output cycle time Event DI logic output monitor H-DO-G master channel setting...
  • Page 130 7. MODBUS Data whose decimal point’s presence and/or position depends on input range The position of the decimal point changes depending on the input range type because the Modbus protocol does not recognize data with decimal points during communication. The following data can have one of three decimal point positions: No digit below decimal point, 1 digit below decimal point, 2 digits below decimal point...

  • Page 131: Data Processing Precautions

    7. MODBUS 7.3.2 Data processing precautions With Modbus protocol, the maximum number of channels per slave address is 20. The accessible data (holding register) address range is from 0000H to 1FFFH. If data exceeding the 1FFFH is accessed, an error response message is returned. Do not write data to any address which is not described in a list of data maps.

  • Page 132: Communication Data List

    7. MODBUS 7.3.3 Communication data list • Name Item stored in the memory area. [ ]: The functional module name that data becomes valid is written. • Attributes RO: Read only Slave (SR Mini HG SYSTEM) → Master Slave (SR Mini HG SYSTEM) ↔ Master R/W: Read and Write Slave (SR Mini HG SYSTEM) ←...
  • Page 133 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value The respective channel status is assigned to  Status each bit in the holding register. [H-TIO- , H-CIO-A, bit 0: Alarm 1 status H-SIO-A] bit 1: Alarm 2 status bit 2: Burnout status...
  • Page 134 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  Comprehensive alarm The respective channel status is assigned to status each bit in the holding register. [H-PCP-J] bit 0: Logical OR of alarm 1 status in all channels bit 1: Logical OR of alarm 2 status in all channels...
  • Page 135 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value PID/AT transfer * 0: PID control operation [H-TIO- , H-CIO-A, 1: AT (Autotuning) operation H-SIO-A] * Autotuning (AT) is the function which automatically measures, calculates and sets the optimum PID constants according to the set temperature.
  • Page 136 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value H-TIO- , Heat-side proportional 0.1 to 1000.0 % of span H-CIO-A: band [H-TIO- , H-CIO-A, H-SIO-A: H-SIO-A] 300.0 Cool-side proportional 0.1 to 1000.0 % of span band [H-TIO- , H-CIO-A] H-TIO- ,...
  • Page 137 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value See Factory Alarm 1 set value TC/RTD input: [H-TIO- , H-CIO-A, set value Within input range or span range H-SIO-A] table of Current/voltage input, H-SIO-A: Alarm 1/ Within display scale range or span range Alarm 2...
  • Page 138 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Heat-side proportioning 1 to 100 seconds cycle time Setting will be invalid in current/voltage [H-TIO- , H-CIO-A] output. Cool-side proportioning 1 to 100 seconds cycle time Setting will be invalid in current/voltage output and heat control.
  • Page 139 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Temperature rise 0: Unused 1: Used completion trigger Do not set “1: Used” in H-TIO-H/J module [H-TIO- , H-CIO-A] and H-SIO-A module, because temperature rise completion is not judged.
  • Page 140 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Cascade ON/OFF 0: OFF 1: ON [H-CIO-A] Setting will be valid in master channel. −9.999 to +10.000 Cascade gain 1.000 [H-CIO-A] As the cascade gain is valid only in the slave channel, the polling or selecting of the same value is made also in the master channel.
  • Page 141 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Output limiter (low) [Heat control, Position proportioning control [For heat/cool control: and Speed control] −5.0 % to Output limiter (high) Cool-side output limiter (high)] [Heat/cool control] [H-TIO- , H-CIO-A,...
  • Page 142 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value H-SIO-A control range 0.00 to 50.00 % 10.00 [H-SIO-A] H-SIO-A input 10 to 50000 Hz frequency at full scale [H-SIO-A] H-SIO-A output scale H-SIO-A output scale low to 10000 * high [H-SIO-A]...
  • Page 143 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value H-TIO-H/J, Decimal point position 0: No decimal place [H-TIO-H/J, H-CIO-A, 1: One decimal place H-CIO-A: 1 H-SIO-A] 2: Two decimal places H-SIO-A: 0 3: Three decimal places Input range number The factory...
  • Page 144 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Within ± input span range AT bias [H-TIO- , H-CIO-A, H-SIO-A] 0.00 to 10.00 % of span ON/OFF control 0.02 differential gap (upper) [H-TIO- , H-CIO-A, H-SIO-A] ON/OFF control...
  • Page 145 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value 0.0 to 100.0 % of span (Deviation setting Start determination from the temperature set value) point Setting will be invalid in H-SIO-A module. [H-TIO- , H-CIO-A] 0: Not hold Control RUN/STOP...
  • Page 146 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Temperature rise 0: Not hold completion hold 1: Hold function [H-PCP-J] Interval time setting 0 to 100 ms COM.PORT1/ COM.PORT2 [H-PCP-J] Interval time setting 0 to 100 ms COM.PORT3 [H-PCP-J]...
  • Page 147 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value PV bias unit selection 0: % (of span) [H-TIO- , H-CIO-A, 1: Unit of input range H-SIO-A] Integral time limiter at 1 to 3600 seconds 3600 AT end Setting will be valid in heat/cool control.
  • Page 148 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Number of alarm delay 0 to 255 times times [H-TIO- , H-CIO-A, H-SIO-A] DO function selection The factory 00 to 88 * [H-DO-A/B/D] set value varies depending...
  • Page 149 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value DI using selection 0 to 255 * [H-DI-A] H-PCP-J module 0: No alarm function CH1: 9 DO type selection 1: Alarm 1/TI alarm 1 CH2: 1 [H-PCP-J] 2: Alarm 2/TI alarm 2...
  • Page 150 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Cascade tracking 0: Not provided [H-CIO-A] Cascade monitored value becomes zero. 1: Provided Cascade monitored value just before is hold. Cascade data selection 0: Manipulated outpur value 1: Temperature measured value (PV) [H-CIO-A]...
  • Page 151 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Positioning adjustment 0 to 100 * counter [H-TIO-K]  H-CT-A module 0: Normal heater break alarm status 1: Break [H-CT-A] 2: Welding The respective channel status is assigned to H-DI-A module ...
  • Page 152 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value −5.0 to +105.0 % − H-DO-G manipulated output value [H-DO-G] Output limiter (low) to 105.0 % 100.0 H-DO-G output limiter (high) [H-DO-G] −5.0 % to Output limiter (high) H-DO-G output limiter (low) [H-DO-G]...
  • Page 153 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  AI measured value Within display scale range * [H-AI-A/B]  AI status The respective channel status is assigned to [H-AI-A/B] each bit in the holding register. bit 0: AI alarm 1 status bit 1:...
  • Page 154 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value 0: 0 to 10 mV DC The factory AI input range number 1: −10 to +10 mV DC set value [H-AI-A/B] 2: 0 to 100 mV DC varies 3: −100 to +100 mV DC depending...
  • Page 155 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value AI alarm 1 type 0: Process high alarm The factory selection 1: Process low alarm set value [H-AI-A/B] 2 to 6: No alarm function varies depending on the...
  • Page 156 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  TI measured value Within input range [H-TI-A/B/C]  TI status The respective channel status is assigned to [H-TI-A/B/C] each bit in the holding register. bit 0: TI alarm 1 status bit 1: TI alarm 2 status bit 2: TI Burnout status...
  • Page 157 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value TI alarm 1 differential gap 0.00 to 10.00 % of span 0.10 [H-TI-A/B/C] TI alarm 2 differential gap [H-TI-A/B/C] TI alarm 1 type 0: Process high alarm The factory selection...
  • Page 158 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  AO output value monitor Display scale range * [H-AO-A/B] Data will be valid in manual mode. AO output set value Display scale range * [H-AO-A/B] Setting will be valid in manual mode.
  • Page 159 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value The respective channel status is assigned to  Event DI contact input each bit in the holding register. monitor bit 0: CH1 (DI1) [H-DI-B] bit 1: CH2 (DI2) bit 2: CH3 (DI3)
  • Page 160 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Event DI type selection 1 0 to 30 * [H-DI-B] (17 to 30: Not settable) Event DI type selection 2 0 to 30 * [H-DI-B] (17 to 30: Not settable) Event DI type selection 3...
  • Page 161 7. MODBUS Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value The respective channel status is assigned to  Event DO status each bit in the holding register. [H-DO-C] bit 0: CH1 (DO 1) bit 1: CH2 (DO 2) bit 2: CH3 (DO 3) bit 3: CH4 (DO 4)

  • Page 162: Data Map

    7. MODBUS 7.4 Data Map 7.4.1 Reference to data map This data map summarizes the data addresses, channels and names that can be used with Modbus protocol. For details on each data range, see 7.3.3 Communication data list (P. 124). Address Name 0000H (...

  • Page 163: Data Map List

    7. MODBUS 7.4.2 Data map list (1) Read only data Address Name 0000H ( CH1 Temperature measured value (PV) ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ H-TIO- , H-CIO-A ⋅ ⋅ ⋅ ⋅ Motor speed measured value ⋅ ⋅ 0013H ( 19) CH20 H-SIO-A 0014H ( 20) CH1 Heat-side manipulated output value...
  • Page 164 7. MODBUS (2) Read/Write data Address Name Address Name 00C8H ( 200) CH1 Temperature set value (SV) 01CCH ( 460) CH1 Heat-side proportioning ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ cycle time H-TIO- , H-CIO-A ⋅ ⋅ ⋅ ⋅ ⋅...
  • Page 165 7. MODBUS Continued from the previous page. Address Name Address Name Memory area number 0384H ( 900) CH21 Heater break alarm set ⋅ ⋅ ⋅ ⋅  02BDH ( 701) (for each control unit) value 2 ⋅ ⋅ 03ABH ( 939) CH60 H-TIO- , H-CIO-A, H-SIO-A H-CT-A Temperature rise...
  • Page 166 7. MODBUS Read/Write data (initial data) When setting initial setting data items, stop control by normal setting data “control start/stop selection.” Address Name Address Name 03E8H (1000) CH1 Setting change rate limiter 04D8H (1240) CH1 H-SIO-A correction trigger ⋅ ⋅ ⋅...
  • Page 167 7. MODBUS Continued from the previous page. Address Name Address Name 05B4H (1460) CH1 Setting limiter (low) Temperature rise ⋅ ⋅ ⋅ ⋅  06A5H (1701) completion hold function ⋅ ⋅ H-TIO- , H-CIO-A, H-SIO-A 05C7H (1479) CH20 (for each control unit) 05C8H (1480) CH1 Input error determination H-PCP-J ⋅...
  • Page 168 7. MODBUS Continued from the previous page. Address Name Address Name 06EAH (1770) Do not use this address Alarm 2 differential gap ⋅ ⋅   06B9H (1721) (for each control unit) range ⋅ 06F3H (1779) H-TIO- , H-CIO-A, H-SIO-A Alarm 1 type selection 06F4H (1780) DI using selection...
  • Page 169 7. MODBUS (4) Read only data Address Name 085CH (2140) CH1 H-CT-A module heater break alarm status ⋅ ⋅ ⋅ ⋅ H-CT-A ⋅ ⋅ 0897H (2199) CH60 0898H (2200) H-DI-A module input status ⋅ ⋅  (for each module) ⋅ 08A1H (2209) H-DI-A 08A2H (2210)
  • Page 170 7. MODBUS (5) H-DO-G module data Address Name 0BB8H (3000) H-DO-G manipulated output value ⋅ ⋅ ⋅ ⋅ H-DO-G ⋅ ⋅ 0C57H (3159) CH160 0C58H (3160) H-DO-G output limiter (high) ⋅ ⋅ ⋅ ⋅ H-DO-G ⋅ ⋅ 0CF7H (3319) CH160 0CF8H (3320) H-DO-G output limiter (low) ⋅...
  • Page 171 7. MODBUS (6) H-AI-A/B module data Address Name Address Name 1194H (4500) CH1 AI measured value AI alarm 1 differential gap ⋅ ⋅ ⋅ ⋅  ⋅ 139CH (5020) (for each control unit) H-AI-A/B ⋅ 11BBH (4539) CH40 H-AI-A/B 11BCH (4540) CH1 AI status AI alarm 2 differential gap ⋅...
  • Page 172 7. MODBUS (7) H-TI-A/B/C module data Address Name Address Name 13ecH (5100) CH1 TI measured value TI alarm 2 hold action ⋅ ⋅ ⋅ ⋅  ⋅ 1531H (5425) (for each control unit) H-TI-A/B/C ⋅ 1413H (5139) CH40 H-TI-A/B/C 1414H (5140) CH1 TI status TI alarm 1 interlock ⋅...
  • Page 173 7. MODBUS (8) H-AO-A/B module data Address Name 157CH (5500) AO output value monitor ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ H-AO-A/B 15A3H (5539) CH160 15A4H (5540) AO output set value ⋅ ⋅ ⋅ ⋅ H-AO-A/B ⋅ ⋅ 15CBH (5579) CH160 15CCH (5580) AO function selection ⋅...
  • Page 174 7. MODBUS (9) H-DI-B module data (Event DI data) Address Name Address Name 1770H (6000) Event DI contact input 1A18H (6680) Event DI corresponding ⋅ ⋅ ⋅ ⋅   ⋅ monitor (for each module) ⋅ channel selection 4 (for ⋅...
  • Page 175 7. MODBUS (10) H-DO-C module data (Event DO data) Address Name 1C84H (7300) Event DO status ⋅ ⋅  (for each module) ⋅ 1C8DH (7309) H-DO-C 1C8EH (7310) ⋅ ⋅  Do not use this address range ⋅ 1C97H (7319) 1C98H (7320) Event DO manual output value ⋅...

  • Page 176: Functions

    When “Auto” was selected with Auto/Manual transfer of H-DO-G module, output ratio operation is done. When “Manual” was selected, value set in H-DO-G manual output value is output as manipulated output value of slave channel. The output ratio function correspond to RKC communication protocol and Modbus protocol. IMS01J02-E2...
  • Page 177 8. FUNCTIONS Output ratio action Manipulated output value of master channel and slave channel are output within the output limiter range. Master channel (H-TIO module) Manipulated output value of master channel Output limiter (high limit) Output limiter PID computation result (low limit) 100 % Slave channel (H-DO-G module)
  • Page 178 8. FUNCTIONS Assignment of the master channels It is possible to assign the master channel corresponding to the slave channel if in the same unit. The master channel is assigned by “H-DO-G master channel setting.” H-DO-G master channel setting Setting range: 0 to The number of H-TIO- module use channel (0: Unused) Example: Setting in the following system configuration.
  • Page 179 8. FUNCTIONS H-DO-G master channel setting example Slave channel No. H-DO-G master Slave channel No. H-DO-G master (H-DO-G module) channel setting (H-DO-G module) channel setting For the H-TIO- module, see the Hardware Quick Manual (IMS01V01-E ). For the H-DO-G module, see the H-DO-G Instruction Manual (IMS01K01-E ). IMS01J02-E2...

  • Page 180: Speed Control

    8. FUNCTIONS 8.2 Speed Control Speed control function inputs pulse from rotary encoder, and motor speed is controlled. Other than H-PCP-J module, H-SIO-A module are requirement to do speed control function. SR Mini HG SYSTEM control unit H-SIO-A module H-PCP-J H-TIO-B module module Temperature control output...

  • Page 181: Display Scale

    8. FUNCTIONS 8.2.1 Display scale This function scales the display range of the input value between −9999 to +10000. However, the maximum span is 10000. H-SIO-A input frequency at full scale: Sets the frequency of encoder when display scale high value (full scale) is displayed. Setting rage: 10 to 50000 Hz Display scale high: Sets the high limit value (full scale) of display scale.

  • Page 182: Measuring Method

    8. FUNCTIONS 8.2.2 Measuring method Can be selected periodic computation method or pulse count method. Periodic computation method Frequency is obtained by measuring the time required for certain pulse intervals. The number of measured pulses can be set in the pulse range of 1 to 1000 by setting divide ratio. Setting range H-SIO-A divide ratio: 1 to 1000 Example: When divide ratio is set to 3.

  • Page 183: Output Scale

    8. FUNCTIONS 8.2.3 Output scale This function scales the output range between −9999 to +10000. H-SIO-A output scale high: Sets the value equivalent to display scale of control output high limit. Setting rage: H-SIO-A output scale low to 10000 H-SIO-A output scale low: Sets the value equivalent to display scale of control output low limit.

  • Page 184: Controls

    8. FUNCTIONS 8.2.5 Controls This instrument controls with open loop control or PID control (closed loop control). (1) Open loop control In a deviation between the motor speed measured value and set value is larger than the H-SIO-A control range set value, or the H-SIO-A open/closed loop control transfer is “1: Open loop control,” the instrument is in open loop control, thereby outputting a constant control output value corresponding to the motor speed set value.
  • Page 185 8. FUNCTIONS (2) PID Control (Closed loop control) If a deviation between the motor speed measured value and set value is within the control range set value, and the H-SIO-A open/closed loop control transfer is “0: Closed loop control,” the instrument performs PID control.
  • Page 186 8. FUNCTIONS Control response parameters This is the function of enabling the setting of response to set value change in select any one of 3 steps (Slow, Medium, Fast) in PID control. In order to achieve faster controlled object response to set value change, select Fast. However, slight overshoot is unavoidable when selecting Fast.

  • Page 187: Ims01J02-E2

    8. FUNCTIONS 8.2.6 Scale correction This is the function of correcting the motor speed measured value and control output when the motor speed measured value differs from the actually measured value or motor speed set value differs from the actually measured value. SR Mini HG SYSTEM Control output (Current/voltage output)
  • Page 188 8. FUNCTIONS Example: Correction in the following value. Control output: Voltage output 0 to 10 V DC Motor speed set value: 250 mm/min Display scale high: 300 mm/min Motor speed measured value: 245 mm/min Display scale low: 0 mm/min Actual measured value: 240 mm/min Output scale high: 400 mm/min Output scale low: 0 mm/min...

  • Page 189: Output Change Rate Limiter

    8. FUNCTIONS 8.2.7 Output change rate limiter The output change rate limiter limits the variation of manipulated output (MV) for a time unit. You can set an output variation, and control the output, when your object requires to avoid sudden variation. The output variation limiter is particularly effective when a sudden variation may cause the controller to crash, or when it may cause a large current.

  • Page 190: Alarm Hold Function

    8. FUNCTIONS 8.2.8 Alarm hold function In the alarm hold function, the alarm function is kept invalid even if the motor speed measured value is in the alarm range when the power is on or the operation mode is switched to RUN from STOP. The alarm function is held until it passes with H-SIO-A alarm hold cancel time.

  • Page 191: Assignment Of Channels

    8. FUNCTIONS 8.2.9 Assignment of channels Channel number of H-SIO-A modules uses the same kind of channel number as H-TIO- modules and H-CIO-A modules. If the H-SIO-A modules are mounted together with H-TIO- modules and H-CIO-A modules, the channel numbers are continued. Channel number is decided in order automatically from the left.

  • Page 192: Troubleshooting

    This section lists some basic causes and solutions to be taken when any problem would arise in this instrument. If you can not solve a problem, please contact RKC sales office or the agent, on confirming the type name and specifications of the product.
  • Page 193 9. TROUBLESHOOTING H-PCP-J module Problem Probable cause Solution RUN lamp does not light up Power not being supplied Check external breaker etc. Appropriate power supply Check the power supply voltage not being supplied Power supply terminal contact Retighten the terminals defect Power supply section defect Replace H-PCP-J module...
  • Page 194 9. TROUBLESHOOTING RKC communication Problem Probable cause Solution No response Wrong connection, no connection or Confirm the connection method or disconnection of the communication cable condition and connect correctly Breakage, wrong wiring, or imperfect Confirm the wiring or connector and...
  • Page 195 9. TROUBLESHOOTING Modbus Problem Probable cause Solution No response Wrong connection , no connection or Confirm the connection method or disconnection of the communication cable condition and connect correctly Breakage, wrong wiring, or imperfect Confirm the wiring or connector and contact of the communication cable repair or replace the wrong one Mismatch of the setting data of...

  • Page 196: Plc Communication

    9. TROUBLESHOOTING PLC communication Problem Probable cause Solution TX1 (data transmission) lamp Wrong connection, no Confirm the connection method does not flash connection or disconnection of or condition and connect the communication cable correctly RX1 (data reception) lamp does not flash Breakage, wrong wiring, or Confirm the wiring or connector imperfect contact of the...
  • Page 197 PLC. long as the maximum scanning time of PLC. For the PLC scanning time setting (Identifier ST), see P. 80 (RKC communication), P. 138 (Modbus communication). IMS01J02-E2...

  • Page 198: Ascii 7-Bit Code Table

    10. ASCII 7-BIT CODE TABLE This table is only for use with RKC communication. b5 to b7 b4 b3 b2 b1 ‘ ” & ’ < ¥ − > ˜ IMS01J02-E2...
  • Page 199 The first edition: SEP. 2004 [IMQ00] The second edition: MAY 2006 [IMQ00]...
  • Page 200 RKC INSTRUMENT INC. HEADQUARTERS: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN PHONE: 03-3751-9799 (+81 3 3751 9799) E-mail: info@rkcinst.co.jp FAX: 03-3751-8585 (+81 3 3751 8585) IMS01J02-E2 MAY 2006...

Table of Contents
