SR Mini HG SYSTEM
Power Supply/CPU Module
H-PCP-J

PLC Communication

Instruction Manual
[For LG PLC]
IMS01J06-E1
RKC INSTRUMENT INC.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Mini HG SYSTEM H-PCP-J and is the answer not in the manual?

Questions and answers

Related Manuals for RKC INSTRUMENT SR Mini HG SYSTEM H-PCP-J

Summary of Contents for RKC INSTRUMENT SR Mini HG SYSTEM H-PCP-J

  • Page 1: Plc Communication

    SR Mini HG SYSTEM Power Supply/CPU Module H-PCP-J PLC Communication Instruction Manual [For LG PLC] IMS01J06-E1 RKC INSTRUMENT INC. ®...
  • Page 2 The name of each programmable controller (PLC) means the products of each manufacturer. Company names and product names used in this manual are the trademarks or registered trademarks of the respective companies. All Rights Reserved, Copyright  2004, RKC INSTRUMENT INC.
  • Page 3 Thank you for purchasing this RKC instrument. In order to achieve maximum performance and ensure proper operation of your new instrument, carefully read all the instructions in this manual. Please place this manual in a convenient location for easy reference.
  • Page 4 The figures, diagrams and numeric values used in this manual are only for purpose of illustration. RKC is not responsible for any damage or injury that is caused as a result of using this instrument, instrument failure or indirect damage.

  • Page 5: Table Of Contents

    CONTENTS Page 1. OUTLINE................1 2. COMMUNICATION SPECIFICATIONS........ 3 3. CONNECTIONS ..............4 4. SETTING ON THE H-PCP-J MODULE SIDE....... 6 4.1 PLC Register Address Setting .................6 4.2 Protocol Selection and Communication Setting..........8 4.3 PLC Scanning Time Setting................9 5. SETTING ON THE PLC SIDE..........10 6.
  • Page 6 MEMO IMS01J06-E1...

  • Page 7: Outline

    1. OUTLINE This manual describes the communication function of the SR Mini HG SYSTEM and the LG Industrial Systems programmable controller (hereafter called PLC). This manual is attached when the model code of H-PCP-J module is H-PCP-J- -D∗ -05E. For details of the H-PCP-J module, see the Power Supply/CPU Module H-PCP-J Instruction Manual (IMS01J02-E ).
  • Page 8 The following function module data can be used in PLC communication (see “Data map” on page 24). In addition, data on other modules connected (TI, AI, AO, etc.) can be used on one more communication port (RKC communication or Modbus). Function module...

  • Page 9: Communication Specifications

    2. COMMUNICATION SPECIFICATIONS Interface: Based on RS-422A, EIA standard Connection method: RS-422A: 4-wire system, multi-drop connection Synchronous method: Start/stop synchronous type Communication speed: 9600 bps, 19200 bps, 38400 bps Communication speed can be selected with switch Data bit configuration: Start bit: 1 Data bit: 8 Parity bit: Without Stop bit:...

  • Page 10: Connections

    3. CONNECTIONS RS-422A Pin layout of modular connector (RS-422A) COM.PORT1 H-PCP-J module R (A) R (B) T (B) T (A) Connector pin number and signal details (RS-422A) Pin No. Signal name Symbol Receive data R (A) Receive data R (B) Signal ground Send data T (B)
  • Page 11 Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD.,) Customer is requested to prepare a communication cable fit for the control unit to be connected by the PLC. Connection cable W-BF-01 * (RKC product) can use to connect PLC. * Shields of the cable are connected to SG (No. 6 pin) of the H-PCP-J connector.

  • Page 12: Setting On The H-Pcp-J Module Side

    4. SETTING ON THE H-PCP-J MODULE SIDE 4.1 PLC Register Address Setting Set the file register address of each control unit using the unit address setting switch at the front of the H-PCP-J module. For this setting, use a small blade screwdriver. Unit address setting switch Setting range: 0 to 15 (0 to F: hexadecimal)
  • Page 13 4. SETTING ON THE H-PCP-J MODULE SIDE Setting example: When group 2 is used (for the GLOFA-GM series) Unit address 4 SR Mini HG SYSTEM Register address: control unit MW2000 to MW2499 Unit address 5 SR Mini HG SYSTEM Register address: control unit MW2500 to MW2999 Address in the...

  • Page 14: Protocol Selection And Communication Setting

    4. SETTING ON THE H-PCP-J MODULE SIDE 4.2 Protocol Selection and Communication Setting Match the setting of data bit configuration, communication speed and communication protocol with the PLC communication specification by COM.PORT1/COM.PORT2 setting switch (SW2). Setting example to recommend is shown in the following. COM.PORT1/COM.PORT2 setting switch (SW2) GLOFA-GM...

  • Page 15: Plc Scanning Time Setting

    4.3 PLC Scanning Time Setting Set the PLC scanning time (time of waiting for a response from the PLC) so as to adapt to the environment used. The PLC scanning time is set via host communication (RKC communication or Modbus).

  • Page 16: Setting On The Plc Side

    5. SETTING ON THE PLC SIDE Set the PLC as follows. (Recommend setting example) Item Description Mode Channel RS422 side Station Type RS422 Data bit Parity bit Without Stop bit Transmission speed 38400 bps Termination resistor Termination resistor is inserted The setting item varies depending on the PLC.

  • Page 17: Communication Data

    6. COMMUNICATION DATA 6.1 Request Command and Data Transfer Data transfer between PLC and SR Mini HG SYSTEM are executed by request command. Request command “0: Monitor (PLC ← SR Mini HG SYSTEM)” Command which requests the SR Mini HG SYSTEM to write data such as temperature measured values, etc.
  • Page 18 6. COMMUNICATION DATA Data transfer procedures Change each set value of SR Mini HG SYSTEM from the PLC after the initial settings are made. If each set value of SR Mini HG SYSTEM is changed from the PLC without setting the initial values, it is re-written to 0 with each set value of the PLC at that time set to 0.
  • Page 19 6. COMMUNICATION DATA Data setting (When transmit data of temperature setting values from PLC to SR Mini HG SYSTEM) Start Set temperature set value (SV) and other setting data to each register (memory) in the PLC. [Data setting] Set “1” to the request When 1 (Setting) is set to request command, the command starts reading the temperature set...
  • Page 20 6. COMMUNICATION DATA Continued from the previous page. [Confirmation of setting data] Set “2” to the request When 2 (Set value monitor) is set to request command, command starts writing the temperature SR Mini HG SYSTEM set value data set to the PLC side. PCP communication If 3 (Writing on setting data) is set to PCP state = 3 ?

  • Page 21: Data Processing Precautions

    6. COMMUNICATION DATA 6.2 Data Processing Precautions With PLC communication, the maximum number of channels per unit address is 20. Read data of unused channel and undefined address is 0. The data type is treated as binary data with a sign and without a decimal point. For this reason, carefully express and set the data.
  • Page 22 6. COMMUNICATION DATA Some communication data may become invalid depending on the module selection or the configuration of the SR Mini HG System control unit. If any one of the conditions listed below occurs and data items written are within the setting range, read data becomes 0.

  • Page 23: Communication Data List

    6. COMMUNICATION DATA 6.3 Communication Data List • Name Item stored in the memory area. [ ]: The functional module name that data becomes valid is written. • Attributes RO: At the time of request command “0: Monitor,” SR Mini HG SYSTEM writes in data. (SR Mini HG SYSTEM →...
  • Page 24 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Heater break alarm 0.0 to 100.0 A or 0.0 to 30.0 A set value For the current transformer (CT) input of the [H-CT-A] H-CT-A module.
  • Page 25 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value Integral time H-TIO- , 1 to 3600 seconds [H-TIO- , H-CIO-A, H-CIO-A: H-SIO-A] H-SIO-A: Derivative time H-TIO- , 0 to 3600 seconds (0: PI action) [H-TIO- , H-CIO-A, H-CIO-A: H-SIO-A]...
  • Page 26 6. COMMUNICATION DATA Continued from the previous page. Conditions which will cause the autotuning to stop: • When the temperature set value (SV) is changed. • When the memory area is changed. • When the PV bias value is changed. •...
  • Page 27 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  Temperature measured TC/RTD input: value (PV) Within input range [H-TIO- , H-CIO-A] Current/voltage input: Within display scale range Motor speed measured Within display scale range ...
  • Page 28 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value 0: Monitor Request command Command which requests the SR Mini HG [H-PCP-J] SYSTEM to write data such as temperature measured values, etc. (attribute: RO) to the PLC side.
  • Page 29 6. COMMUNICATION DATA Continued from the previous page. Attri- Struc- Factory Name Data range bute ture set value  PCP normal The numbers 0 and then 1 are repeated in communication flag every communication period. [H-PCP-J] The SR Mini HG SYSTEM rewrites 0 and 1 in this area alternately like 0 →...

  • Page 30: Data Map

    7. DATA MAP 7.1 Reference to Data Map This data map summarizes the data (M register and D register) addresses, channels and names that can be used with PLC. For details on each data range, see the 6.3 Communication Data List (P. 17). Unit Unit Unit...

  • Page 31: Data Map List

    7. DATA MAP 7.2 Data Map List 7.2.1 GLOFA-GM series Unit address 0 to 3 (Group 1) Unit Unit Unit Unit address address address address Name MW0000 to MW0500 to MW1000 to MW1500 to Temperature set value (SV) CH1 to CH20 MW0019 MW0519 MW1019...
  • Page 32 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name MW0382 MW0882 MW1382 MW1882 PCP normal communication flag MW0383 to MW0883 to MW1383 to MW1883 to Do not use this address range MW0389 MW0889 MW1389 MW1889...
  • Page 33 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name MW2220 to MW2720 to MW3220 to MW3720 to Derivative time CH1 to CH20 MW2239 MW2739 MW3239 MW3739 MW2240 to MW2740 to MW3240 to MW3740 to PID/AT transfer CH1 to CH20...
  • Page 34 7. DATA MAP Unit address 8 to B (Group 3) Unit Unit Unit Unit address address address address Name MW4000 to MW4500 to MW5000 to MW5500 to Temperature set value (SV) CH1 to CH20 MW4019 MW4519 MW5019 MW5519 MW4020 to MW4520 to MW5020 to MW5520 to...
  • Page 35 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name MW4390 MW4890 MW5390 MW5890 Memory area number MW4391 MW4891 MW5391 MW5891 Control RUN/STOP transfer MW4392 to MW4892 to MW5392 to MW5892 to Do not use this address range MW4399 MW4899 MW5399...
  • Page 36 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name MW6260 to MW6760 to MW7260 to MW7760 to Temperature measured value (PV) MW6279 MW6779 MW7279 MW7779 CH1 to CH20 MW6280 to MW6780 to MW7280 to MW7780 to Heat-side manipulated output value...

  • Page 37: Master-K Series

    7. DATA MAP 7.2.2 MASTER-K series Unit address 0 to 3 (Group 1) Unit Unit Unit Unit address address address address Name DW0000 to DW0500 to DW1000 to DW1500 to Temperature set value (SV) CH1 to CH20 DW0019 DW0519 DW1019 DW1519 DW0020 to DW0520 to...
  • Page 38 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name DW0390 DW0890 DW1390 DW1890 Memory area number DW0391 DW0891 DW1391 DW1891 Control RUN/STOP transfer DW0392 to DW0892 to DW1392 to DW1892 to Do not use this address range DW0399 DW0899 DW1399...
  • Page 39 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name DW2260 to DW2760 to DW3260 to DW3760 to Temperature measured value (PV) DW2279 DW2779 DW34279 DW3779 CH1 to CH20 DW2280 to DW2780 to DW3280 to DW3780 to Heat-side manipulated output value...
  • Page 40 7. DATA MAP Unit address 8 to B (Group 3) Unit Unit Unit Unit address address address address Name DW4000 to DW4500 to DW5000 to DW5500 to Temperature set value (SV) CH1 to CH20 DW4019 DW4519 DW5019 DW5519 DW4020 to DW4520 to DW5020 to DW5520 to...
  • Page 41 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name DW4390 DW4890 DW5390 DW5890 Memory area number DW4391 DW4891 DW5391 DW5891 Control RUN/STOP transfer DW4392 to DW4892 to DW5392 to DW5892 to Do not use this address range DW4399 DW4899 DW5399...
  • Page 42 7. DATA MAP Continued from the previous page. Unit Unit Unit Unit address address address address Name DW6260 to DW6760 to DW7260 to DW7760 to Temperature measured value (PV) DW6279 DW6779 DW7279 DW7779 CH1 to CH20 DW6280 to DW6780 to DW7280 to DW7780 to Heat-side manipulated output value...
  • Page 43 The first edition: SEP. 2004 [IMQ00] The fifth edition: OCT. 2003 [IMQ00]...
  • Page 44 RKC INSTRUMENT INC. HEADQUARTERS: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN PHONE: 03-3751-9799 (+81 3 3751 9799) E-mail: info@rkcinst.co.jp FAX: 03-3751-8585 (+81 3 3751 8585) IMS01J06-E1 SEP. 2004...
