American Dryer Corp. AD-120ES Parts Manual

24 vac phase 5
Hide thumbs Also See for AD-120ES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual, Installation & Operator's Manual
AD-120ES Parts Manual
24 VAC Phase 5
1995-2001
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
www.amdry.com
120195
072997WL/tf
ADC Part No. 450160

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. AD-120ES

Summary of Contents for American Dryer Corp. AD-120ES

  • Page 1 AD-120ES Parts Manual 24 VAC Phase 5 1995-2001 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com 120195 072997WL/tf ADC Part No. 450160...
  • Page 2 For your convenience, log the following information: MODEL NO. __________________________________________ “IMPORTANT NOTE TO PURCHASER” POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. AD-120ES...

  • Page 3: Table Of Contents

    Control Door Assembly... 3 Control Door Assembly (Sprinkler Option) ... 4 Microprocessor Control Panel Assembly ... 5 Microprocessor Control Box Assembly ... 6, 7 Dual Timer Control Panel Assembly ... 8, 9 Dual Timer Control Box Assembly ... 10, 11 Front Panel/Main Door Assemblies For Models Mfd.
  • Page 4 Direct Spark Ignition (DSI) Module Assembly For Gas Models Mfd. as of April 1, 2000 ... 42 Direct Spark Ignition (DSI) Module Assembly For Gas Models Mfd. prior to April 1, 2000 ... 43 Electric Oven Assembly For Electric Models Only ... 44, 45 Electric Oven Relay Box Assembly 208-240 VAC 3ø...

  • Page 5: Control Door Assembly

    Control Door Assembly Illus. No. Part No. Qty. Description 820004* Control Door Assembly ONLY (for gas models and electric models Only) 820003 Stainless Steel Control Door Assembly ONLY (for gas models and electric models Only) 820006* Short Control Door ONLY (for steam models Only) 820009 Stainless Steel Control Door Assembly ONLY...

  • Page 6: Control Door Assembly (Sprinkler Option)

    Illus No. Part No. Qty. Description 881314 Control Door Assembly ONLY 160005 Spring Turn Latch (2-piece) 112360 ADC Logo ONLY 870011 Double Tape Kit 150415 #10-16 x 1/2” Phillips Round Head Crimptite Screw 102600 Control Door Support Rod Catch 102601 Control Door Rod Retainer Clip 102505 Control Door Support Rod...

  • Page 7: Microprocessor Control Panel Assembly

    Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 Non-Coin English Keyboard Label Assembly 112276 Non-Coin Stick-On Label (English Only)* 112275 3-Language Non-Coin Stick-On Label (Spanish, Italian, and Hebrew)* 112277 3-Language Non-Coin Stick-On Label (English, Spanish, and Hebrew)* 112278 5-Language Non-Coin Stick-On Label (Italian, Dutch, French, German, and Chinese)*...
  • Page 8 Microprocessor Control Box Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 9: Microprocessor Control Box Assembly

    Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 150100 #8-32 x 1/2” Round Head Machine Screw 141403 24 VAC Transformer - 50/60 Hz (for gas and steam models Only) 151001 #8-23 Pal Nut 150002 #6-32 x 1” Round Head Machine Screw 120715 30-Position Terminal Block 151000...
  • Page 10 Dual Timer Control Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 11: Dual Timer Control Panel Assembly

    Dual Timer Control Panel Assembly Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 880838 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus. nos. 1 through 15 and 17 through 21) 880837 Dual Timer Control Panel ONLY 131917...

  • Page 12: Dual Timer Control Box Assembly

    Dual Timer Control Box Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 13: Dual Timer Control Box Assembly

    Dual Timer Control Box Assembly Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool, Not Illustrated 315010 9-Pin Connector Bracket 150300 #10-16 x 1/2” Hex Washer TEK Screw 150100 # 8-32 x 1/2” Phillips Round Head Machine Screw 141403 24 VAC Transformer - 50/60 Hz (for gas models and steam models Only) 151001...

  • Page 14: Front Panel/Main Door Assemblies

    Front Panel/Main Door Assemblies For Models Mfd. as of August 31, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 15: For Models Mfd. As Of August 31, 2000

    Front Panel/Main Door Assemblies For Models Mfd. as of August 31, 2000 Illus. No. Part No. Qty. Description 883081 Door Hinge (black) 150683 1/4-20 x 5/8” Carriage Bolt 151012 #10-32 Acorn Nut (white) 883082 Main Door Handle (black) 102214 30” Door Glass 170730 Door Glass Adhesive (10.3 oz.

  • Page 16: For Models Mfd. Prior To August 31, 2000

    Front Panel/Main Door Assemblies For Models Mfd. prior to August 31, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 17: For Models Mfd. Prior To August 31, 2000

    Front Panel/Main Door Assemblies For Models Mfd. prior to August 31, 2000 Illus. No. Part No. Qty. Description 820012* Right Hand Front Panel Assembly (includes illus. nos. 1, 4, and 5) 820014 Stainless Steel Right Hand Front Panel Assembly (includes illus. nos. 1, 4, and 5) 150309 #10-16 x 1/2”...

  • Page 18: Main Door Switch Assembly For Models Mfd. As Of August 31, 2000

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single-Pole Door Switch 150445 1/4-20 x 3/4” Socket Head Cap Screw 881687 Main Door Switch Housing ONLY (white) 881695 Main Door Switch Housing ONLY (blue) 881702...

  • Page 19: Main Door Switch Assembly For Models Mfd. Prior To August 31, 2000

    Main Door Switch Assembly For Models Mfd. prior to August 31, 2000 Illus. No. Part No. Qty. Description 821098 Main Door Switch Assembly Complete (includes illus. nos. 1 through 4 and 6) 821097 Main Door Switch Bracket Assembly ONLY 102405 Main Door Switch Actuator ONLY 150415 #10-16 x 1/2”...

  • Page 20: Lint Drawer/Lint Drawer Switch Box Assemblies

    Illus. No. Part No. Qty. Description 802106 Lint Basket Assembly 802125 Stainless Steel Lint Basket Assembly 122116 Lint Drawer Switch ONLY 122605 4-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool, Not Illustrated 882507 Lint Drawer Switch Box Assembly Complete (includes illus.

  • Page 21: For Models Mfd. Between December 1, 1994 And August 30, 1999

    Lint Drawer/Lint Drawer Switch Box Assemblies For Models Mfd. Between December 1, 1994 and August 30, 1999 Illus. No. Part No. Qty. Description 881141* Lint Drawer Assembly with Safety Switch Actuator Complete 881173 Stainless Steel Lint Drawer Assembly with Safety Switch Actuator 820017 Lint Screen Assembly ONLY 153562...

  • Page 22: Lint Door Assembly

    Illus. No. Part No. Qty. Description 824256* Lint Door Assembly (includes illus. nos. 1, 2, and 4) For Models Mfd. as of August 30, 1999 820015* Lint Drawer Assembly (includes illus. nos. 1, 2, and 4) For Models Mfd. Between December 1, 1994 and August 30, 1999 820021 Stainless Steel Lint Door Assembly 117602...

  • Page 23: Microprocessor Controller (Computer) Temperature Sensor Bracket Assembly

    Microprocessor Controller (Computer) Temperature Sensor Bracket Assembly Illus. No. Part No. Qty. Description 820022 Microprocessor Controller (computer) Temperature Sensor Bracket Assembly Complete (includes illus. nos. 1 through 10) 331295 Temperature Sensor Bracket ONLY 154007 1/4” Tinnerman Push On Fastener 880251 1/4”...
  • Page 24 Dual Timer Temperature Sensor Bracket Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 25: Dual Timer Temperature Sensor Bracket Assembly

    Dual Timer Temperature Sensor Bracket Assembly Illus. No. Part No. Qty. Description 801404 Dual Timer Sensor Bracket Assembly Complete (includes illus. nos. 1 through 11 and 15) 331295 Sensor Bracket ONLY 152000 #6-32 Hex Nut 153010 #6 Star Washer 130302 225°...

  • Page 26: Basket (Tumbler)/Support Assemblies

    Basket (Tumbler)/Support Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 27: Basket (Tumbler)/Support Assemblies

    Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 820110* Basket (tumbler) ONLY without Felt Collar 820111* Stainless Steel Basket (tumbler) ONLY without Felt Collar 820020 Basket (tumbler) and Support Assembly Complete (includes illus. nos. 1 through 12) 820052 Basket (tumbler) and Support Assembly Complete with Rotational Sensor Option (includes illus.

  • Page 28: Basket (Tumbler) Bearing Mount Assembly

    Basket (Tumbler) Bearing Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 29: Basket (Tumbler) Bearing Mount Assembly

    Basket (Tumbler) Bearing Mount Assembly Illus. No. Part No. Qty. Description 101137 2-1/4” SFX Bushing 100135 AP-74 V-Belt 101136 20” Basket (tumbler) Pulley 150602 5/8-11 x 3” Hex Head Machine Bolt 153016 5/8” Flat Washer 880204 2-1/4” Pillow Block Bearing ONLY 153016 5/8”...
  • Page 30 Idler Bearing Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 31: Idler Bearing Mount Assembly

    Idler Bearing Mount Assembly Illus. No. Part No. Qty. Description 101110 1” Bushing 101113 2A3.0 Pulley 100135 AP-74 V-Belt 101107 1” SK Bushing 100170 3V-710 V-Belt 101112 19” Idler Pulley 100715 1/4” x 1/4” x 4-5/8” Key 301852 1” Idler Shaft ONLY 880205 1”...
  • Page 32 Basket (Tumbler) Drive Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 33: Basket (Tumbler) Drive Motor Mount Assembly

    Basket (Tumbler) Drive Motor Mount Assembly Illus. No. Part No. Qty. Description 101121 5/8” SK Bushing 101114 2.65” Pulley (for 60 Hz models Only) 101120 3.15” Pulley (for 50 Hz models Only) 100170 3V-710 V-Belt 120200 3/8” x 90° Connector 150501 5/16-18 x 3/4”...

  • Page 34: Blower Motor Mount Assembly

    Illus. No. Part No. Qty. Description 150501 5/16-18 x 1” Hex Head Bolt 153001 5/16” Flat Washer 181043 3 hp Motor 208/230/460/416v 50 Hz 100022 3 hp Motor 380v 3ø 60 Hz 100088 3 hp Motor 575v 3ø 60 Hz 152004 5/16-18 Hex Nut 153002...

  • Page 35: Impellor/Fan Assembly

    Impellor/Fan Assembly For Models Mfd. prior to November 6, 2000 Illus. No. Part No. Qty. Description 101194 SDS x 1-3/8” Bushing (for 60 Hz models Only) 101152 SH x 1-3/8” Bushing (for 50 Hz models Only) 101147 2B x 4.8 Pulley (for 60 Hz models Only) 101148 2B x 4.0 Pulley (for 50 Hz models Only) 100706...

  • Page 36: Blower Motor Mount Assembly

    Blower Motor Mount Assembly For Gas Models Mfd. prior to November 6, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 37 Blower Motor Mount Assembly For Gas Models Mfd. prior to November 6, 2000 Illus. No. Part No. Qty. Description 802253 Adjustable Plate Assembly (for models mfd. as of July 20, 1998) 802229 Adjustable Plate Assembly (for models mfd. prior to July 20, 1998) 813025 Blower Motor Mount Assembly Complete (includes illus.

  • Page 38: For Electric Models Mfd. Prior To November 6, 2000

    Blower Motor Mount Assembly For Electric Models Mfd. prior to November 6, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 39: Blower Motor Mount Assembly

    Blower Motor Mount Assembly For Electric Models Mfd. prior to November 6, 2000 Illus. No. Part No. Qty. Description 802253 Adjustable Plate Assembly (for models mfd. as of July 20, 1998) 802229 Adjustable Plate Assembly (for models mfd. prior to July 20, 1998) 813028 60 kW Electric Blower Motor Mount Assembly Complete (includes illus.

  • Page 40: For Steam Models Mfd. Prior To November 6, 2000

    Blower Motor Mount Assembly For Steam Models Mfd. prior to November 6, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 41: For Steam Models Mfd. Prior To November 6, 2000

    Blower Motor Mount Assembly For Steam Models Mfd. prior to November 6, 2000 Illus. No. Part No. Qty. Description 802253 Adjustable Plate Assembly (for models mfd. as of July 20, 1998) 802229 Adjustable Plate Assembly (for models mfd. prior to July 20, 1998) 813069 Blower Motor Mount Assembly Complete (includes illus.

  • Page 42: Direct Spark Ignition (Dsi) Burner Assembly

    Illus. No. Part No. Qty. Description 880874* Direct Spark Ignition (DSI) Natural Gas Burner Assembly Complete Less Orifices (includes illus. nos. 1 through 16 and 18 through 36) 880875* Direct Spark Ignition (DSI) Liquid Propane (L.P.) Gas Burner Assembly Complete Less Orifices (includes illus.
  • Page 43 Direct Spark Ignition (DSI) Burner Assembly For Gas Models ONLY Illus. No. Part No. Qty. Description 17** 140832 #4 Burner Orifice (natural gas) ONLY 140819 #30 Burner Orifice (liquid propane [L.P.] gas) ONLY 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 331288 Manifold Support ONLY 150309...

  • Page 44: Direct Spark Ignition (Dsi) Module Assembly

    Illus. No. Part No. Qty. Description 128935 Direct Spark Ignition (DSI) Module ONLY - 50/60 Hz (for models mfd. as of April 1, 2000) 820100 Direct Spark Ignition (DSI) Module Mount Assembly ONLY 121400 Universal Bushing 150522 1/4-20 x 1/2” Hex Head TEK Screw 150301 #8-18 x 7/16”...

  • Page 45: Direct Spark Ignition (Dsi) Module Assembly

    Direct Spark Ignition (DSI) Module Assembly For Gas Models Mfd. prior to April 1, 2000 Illus. No. Part No. Qty. Description 880815 ADC Direct Spark Ignition (DSI) Module ONLY - 50/60 Hz 820100 Direct Spark Ignition (DSI) Module Mount Assembly ONLY 121400 Universal Bushing 152014...

  • Page 46: Electric Oven Assembly

    Electric Oven Assembly For Electric Models ONLY American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 47 Electric Oven Assembly For Electric Models ONLY Illus. No. Part No. Qty. Description 803015 Electric Oven Box ONLY (for models mfd. as of December 8, 1997) 803002 Electric Oven Box ONLY (for models mfd. prior to December 8, 1997) ---------* Electric Oven Assembly Complete ---------* Electric Element...

  • Page 48: Electric Oven Relay Box Assembly

    Illus. No. Part No. Qty. Description 320902 Electric Oven Relay Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 120710 Power Distribution Block 151001 #8-32 Pal Nut 121400 Universal Bushing 132004 Transformer (for ALL microprocessor controller [computer] models and timer models) 150108 #8-32 x 1/2”...

  • Page 49: 380-416/480 Vac 3Ø 50/60 Hz

    Electric Oven Relay Box Assembly 380-416/480 VAC 3ø 50/60 Hz Illus. No. Part No. Qty. Description 320902 Electric Oven Relay Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150300 #10-16 x 1/2” Hex Washer TEK Screw 132004 Transformer (for ALL electric models - 380 VAC through 480 VAC) 121400 Universal Bushing...

  • Page 50: Sail Switch Assembly

    Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 319202 Sail Switch Damper (flat) 154002 1/8” Push On Fastener 802800 Sail Switch Box Cover and Bracket ONLY 802801 Sail Switch Box Assembly Complete (includes illus. nos. 1 through 4 and 6 through 10) 150309 #10 x 1/2”...

  • Page 51: Steam Damper Assembly

    Steam Damper Assembly For Steam Models ONLY Illus. No. Part No. Qty. Description 165012 Steam Coil Assembly 165019 Steel Steam Coil Assembly (optional) 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 820320 Steam Damper Assembly...

  • Page 52: Microprocessor Reversing Contactor Mounting Panel Assembly

    Microprocessor Reversing Contactor Mounting Panel Assembly Illus. No. Part No. Qty. Description 332346 Contactor/Relay Mounting Panel ONLY 121010 L-70 Ground Lug 150108 #8-32 x 1/2” Pan Head Machine Screw 153001 5/16” Flat Washer 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 120765 End Stop/Bracket 132445...

  • Page 53: Dual Timer Reversing Contactor Mounting Panel Assembly

    Dual Timer Reversing Contactor Mounting Panel Assembly Illus. No. Part No. Qty. Description 332346 Contactor/Relay Mounting Panel ONLY 121010 L-70 Ground Lug 150108 #8-32 x 1/2” Phillips Pan Head Machine Screw 153001 5/16” Flat Washer 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 120765 End Stop/Bracket...

  • Page 54: Extended Back Guard Assembly

    Illus. No. Part No. Qty. Description 813029 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 354000 Gas and Electric Lower Back Guard 354003 Steam Lower Back Guard 112017 ADC Name and Address Label 112229 Installation Instructions Label 112519 Routine Maintenance Label ---------...

  • Page 55: Step Down Transformer Application Listing

    Step Down Transformer Application Listing STEP DOWN TRANSFORMER APPLICATION LISTING (REVERSING RELAY BOX) HEAT VOLTAGE 460/480 STEAM ELECTRIC 460/480 N/A = Not available. N/R = Not required. Telephone: (508) 678-9000 TRANSFORMER PART NUMBER WIRE MICROPROCESSOR SERVICE MODELS 3 or 4 132059 3 or 4 132062...

  • Page 56: Electric Oven Component Application Listing

    VOLTS PHASE WIRE OVEN ASSY. PART NO. QTY. ELEMENTS SIZE PART NO. QTY.* OVEN WIRE SIZE PART NO. QTY. TERMINAL PART NO. BUS BAR PART NO. 121011* VOLTS PHASE WIRE OVEN ASSY. PART NO. QTY. ELEMENTS SIZE PART NO. QTY.* OVEN WIRE SIZE PART NO.

  • Page 57: Electric Oven Power Distribution

    Electric Oven Power Distribution 72 kW 208-240 VAC 3ø 50/60 Hz ELECTRIC QTY. SERVICE ELEMENTS 208v 3ø 3, 4w 240v 3ø 3, 4w Telephone: (508) 678-9000 ELEMENT WIRE SIZE OVEN PART AMPS NUMBER 120008 120009 24 VAC CONTACTOR STEP DOWN TRANSFORMER 131385 132004...

  • Page 58: Electric Oven Power Distribution

    ELECTRIC QTY. SERVICE ELEMENTS 380v 3ø 3, 4w 416v 3ø 3, 4w 480v 3ø 3, 4w American Dryer Corporation Electric Oven Power Distribution 72 kW 380-416/480 VAC 3ø 50/60 Hz ELEMENT WIRE SIZE OVEN PART AMPS NUMBER 1200044 120008 120009 88 Currant Road / Fall River, MA 02720-4781 24 VAC CONTACTOR...

  • Page 59: Electric Oven Power Distribution

    Electric Oven Power Distribution 80 kW 208-240 VAC 3ø 50/60 Hz ELECTRIC QTY. SERVICE ELEMENTS 208v 3ø 3, 4w 240v 3ø 3, 4w Telephone: (508) 678-9000 ELEMENT WIRE SIZE OVEN PART AMPS NUMBER 1200047 120048 24 VAC CONTACTOR STEP DOWN TRANSFORMER 131385 132004...

  • Page 60: Electric Oven Power Distribution

    ELECTRIC QTY. SERVICE ELEMENTS 380v 3ø 3, 4w 416v 3ø 3, 4w 480v 3ø 3, 4w American Dryer Corporation Electric Oven Power Distribution 80 kW 380-416/480 VAC 3ø 50/60 Hz ELEMENT WIRE SIZE OVEN PART AMPS NUMBER 1200022 120047 120048 96.3 88 Currant Road / Fall River, MA 02720-4781 24 VAC...

  • Page 61: Electric Oven Wiring

    Electric Oven Wiring 72/80 kW 208-240 VAC 3ø 50/60 Hz Telephone: (508) 678-9000 Fax: (508) 678-9447...

  • Page 62: Electric Oven Wiring

    Electric Oven Wiring 72/80 kW 380-416/480 VAC 3ø 50/60 Hz American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 63: Sprinkler Pneumatic Assembly

    Sprinkler Pneumatic Assembly Illus No. Part No. Qty. Description 150524 1/4-20 x 2” Long Bolt 153007 1/4” Lock Washer 153018 1/4” Flat Washer 100556 Sprinkler Solenoid Valve, 120 Volt 100462 3/8” Silencer 143283 3/8” Poly x 3/8” M.P.T. Connector, Brass 143151 1/4”...
  • Page 64 Sprinkler Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 65: Sprinkler Panel Assembly

    Sprinkler Panel Assembly Illus No. Part No. Qty. Description 120768 5-1/2 35 x 15 mm Din Rail 150300 #10-16 x 1/2” Self Drilling Sheet Metal Screw 120766 End Section 120758 Feed Thru Terminal Block 136033 3-amp 3AG Fuse 120756 1/4” Fuse Terminal Block with Light Emitting Diode (L.E.D.) 120761 4 Position Feed Thru Terminal Block 120750...

  • Page 66: Sprinkler Pipe Assembly

    Sprinkler Pipe Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 67 Sprinkler Pipe Assembly Illus No. Part No. Qty. Description 143556 1” Ball Valve 142579 3/4” x 2” Nipple 142602 1” Union 142579 3/4” x 2” Nipple 142548 1” x 90º Elbow 152002 1/4-20 Hex Nut 150522 1/4-20 x 1/2” Hex Head TEK Screw 332429 Rear Sprinkler Bracket 142584...
  • Page 68 Relay Panel (Sprinkler Option) American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 69: Relay Panel (Sprinkler Option)

    Relay Panel (Sprinkler Option) Illus No. Part No. Qty. Description 332346 Contactor/Relay Mounting Panel 121010 L-70 Ground Lug 150108 #8-32 x 1/2” Pan Head Machine Screw 153001 5/16” Flat Washer 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 120765 End Stop/Bracket 132445 3 hp Impellor Contactor 132467...

  • Page 70: Temperature Sensor Assembly For Sprinkler

    Illus No. Part No. Qty. Description 331877 Temperature Sensor Mounting Plate 150523 1/4-20 x 3/4” Hex Washer Machine Bolt 881312 Temperature Probe Assembly 143296 1/4” Compression Fitting 120649 1/2” N.P.T. Cord Grip (green) 120914 1/2” Metal Clad “O” Ring 120915 1/2”...

  • Page 71: Back Guard Assembly

    Back Guard Assembly Illus No. Part No. Qty. Description 881306 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 354000 Gas and Electric Lower Back Guard 112017 ADC Name and Address Label 112229 Installation Instructions Label 112519 Routine Maintenance Label ———...

  • Page 72: Additional Parts Available

    Part No. Description 112280 “Clean Lint Screen” Label 114001 “CAUTION-Exhausted/Lint Screen” Label 114006 “WARNING - Fire Hazards” Label 120100 3/8” Straight (BX) Connector 120300 3/8” x 45° (BX) Connector 120400 3/8” Red Jacket (BX) Insulator 120500 3/8” Jiffy Clip (BX retainer clip) 120600 3/8”...
  • Page 73 ADC 450160 11 - 12/04/03-1...
