Summary of Contents for American Dryer Corp. AD-120ES

Page 1 For replacement parts, contact the distributor from which the dryer was purchased or American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com...
Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY qualified technicians should service this equipment.
Page 3: For Your Safety
YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUST- ING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
Page 4 The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or specified in the installation and operator's manual included with the dryer.
Page 5: Table Of Contents
SECTION I IMPORTANT INFORMATION A. RECEIVING and HANDLING ... 2 B. SAFETY PRECAUTIONS ... 3 SECTION II SUPER AD-30 SPECIFICATIONS A. SPECIFICATIONS (Gas and Steam Models) ... 5 B. COMPONENT IDENTIFICATION ... 7 SECTION III INSTALLATION PROCEDURES A. LOCATION REQUIREMENTS ... 9 B.
Page 6: Important Information
IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden skid should be visually inspected for shipping damage.
Page 7: Safety Precautions
B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
Page 8 WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubber materials. Drying in a heated basket (tumbler) may damage plastics or rubber and also may be a fire hazard. 7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust duct work, and inside the dryer.
Page 9 SPECIFICATIONS / COMPONENT IDENTIFICATION A. SPECIFICATIONS MAXIMUM CAPACITY (dry weight) BASKET (tumbler) DIAMETER BASKET (tumbler) DEPTH BASKET MOTOR BLOWER MOTOR DOOR OPENING (Diameter) BASKET VOLUME DRYERS PER 20" / 40" TRUCK DRYERS PER 45' / 48" TRUCK VOLTAGE AVAILABLE HEAT INPUT APPROX.
Page 10: Specifications (Gas And Steam Models)
NOTE: OPERATING HEIGHT OF STEAM DRYER is 89 inches (226.1 cm). XHAUST "A" 12" 11-1/4" AS AND 30.5 cm 28.6 LECTRIC 16" 9" TEAM 40.6 cm 22.9 cm NOTE: ADC RESERVES THE RIGHT TO MAKE CHANGES IN SPECIFICATIONS AT ANY TIME, WITHOUT NOTICE or OBLIGATION. Specifications ADG-120ES ADE-120ES...
Page 11: Component Identification
B. COMPONENT IDENTIFICATION 1. DRYER FRONT VIEW Illus. No. Description Microprocessor Control / Keyboard Panel Assembly (Controls) Control (Top Access) Door Assembly Main Door Assembly Lint Door Assembly Lint Drawer Wire Diagram (Located Behind Control Door) Top Console (Module) Assembly...
Page 12 2. DRYER REAR VIEW Illus. No. Description Basket (Drive) Motor Assembly Blower Motor Mount Assembly Impellor (fan/blower) Assembly Idler Bearing Mount Assembly Tumbler Bearing Mount Assembly Electric Service Relay Box Heating Unit Data Label and Installation Label * Electric service connections are made in this box.
Page 13: Installation Procedures
INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable AMERICAN NATIONAL STANDARDS: ANSI.Z223.1-LATEST EDITION (National Fuel Gas Code) ANSI/NFPA NO. 70-LATEST EDITION (National Electric Code) or in CANADA, the installation must conform to applicable CANADIAN STANDARDS: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.
Page 14: Unpacking/Setting Up
B. UNPACKING/SETTING UP Remove protective shipping material (i.e., plastic wrap, and/or optional shipping box) from dryer. IMPORTANT: Dryer must be transported and handled in an upright position at all times. The dryer can be moved to its final location while still attached to the skid or with the skid removed.
Page 15 1. LEVELING DRYER a. To level dryer, place 4-inch square metal shims (refer to illustration above) or other suitable material under the base pads. It is suggested that the dryer be tilted slightly to the rear. 2. If more headroom is needed when moving dryer into position, the top console (module) may be removed.
Page 16: Dryer Enclosure Requirements
C. DRYER ENCLOSURE REQUIREMENTS Even though a 12-inch clearance is acceptable, it is recommended that the rear of the dryer be positioned approximately two (2) feet (24-inches) from the nearest obstruction (i.e., wall) for ease of installation, mainte- nance, and service. Bulkheads and partitions should be made from noncombustible materials. The clearance between the bulkhead header and the dryer must be a minimum of 4-inches and must not extend more than 4- inches to the rear of the dryer front.
Page 17: Fresh Air Supply
D. FRESH AIR SUPPLY When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the make-up air is inadequate, drying time and drying efficiency will be adversely affected.
Page 18: Exhaust Requirements
IMPORTANT: Make-up air must be provided from a source free of dry cleaning solvent fumes. Make-up air that is contaminated by dry cleaning solvent fumes will result in irreparable damage to motors and other dryer components. NOTE: Component failure due to dry cleaning solvent fumes will VOID THE WARRANTY. E.
Page 19 ALL duct work should be smooth inside with no projections from sheet metal screws or other obstructions which will collect lint. When adding ducts, the ducts to be added should overlap the duct to which it is con- nected. ALL duct work joints must be taped to prevent moisture and lint from escaping into the building. Additionally, inspection doors should be installed at strategic points in the exhaust duct work for periodic inspection and clean-out of lint from the duct work.
Page 20 2. SINGLE DRYER VENTING Where possible, it is suggested to provide a separate exhaust duct for each dryer. The exhaust duct should be laid out in such a way that the duct work travels as directly as possible to the outdoors with as few turns as possible.
Page 21 (minimum for gas dryers or 72 Kw electric dryers) or 16-inch (minimum for steam dryers or 80 Kw electric dryers) duct is added. IMPORTANT: The AD-120ES is not provided with a back draft damper. When exhausted into a multiple (common) exhaust line, a back draft damper must be installed at each dryer duct.
Page 22 The main duct may be any shape or cross sectional area, so long as the minimum cross section area is provided. The illustrations on page 19 and page 20 show the minimum cross section area for multiple dryer round or square venting.
Page 23 ADG-120ES FOR GAS MODELS ADE-120ES FOR 80 KW ELECTRIC MODELS...
Page 24 MULTIPLE DRYER VENTING (ADS-120ES) WITH 16" DIAMETER (2,750 CFM) EXHAUST CONNECTIONS AT COMMON DUCT...
Page 25: Electrical Information
F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electrical connections, material, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO.70-LATEST EDITION, or in CANADA, the Canadian Electrical Codes Parts 1 &...
Page 26 2. Electrical Service Specifications ADG-120ES Reversing, 3ø (G ADS-120ES Reversing, 3ø (S LECTRICAL IMPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B.
Page 27 ADE-120ES (72 Kw Electric) Reversing, 3ø LECTRICAL IMPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used.
Page 28 ADE-120ES (80 Kw Electric) Reversing, 3ø LECTRICAL IMPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used.
Page 29 3. Electrical Connections NOTE: A wiring diagram is included with each dryer and is affixed to the rear upper right guard/ panel of the dryer. The only electrical input connections to the dryer are the 3-phase (3Ø) power leads (L1, L2, and L3), GROUND, and in the case of 4 wire service, the neutral.
Page 30 4. Grounding Grounding (earth) connections must be provided and installed in accordance with state and local codes. In the absence of the codes, grounding must conform to applicable requirements of the National Electric Code ANSI/NFPA NO.70LATEST EDITION, or in CANADA, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
Page 31: Gas Information
G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in CANADA, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91(L.P.
Page 32 2. Technical Gas Data a. Gas Specifications Manifold Pressure* Inline Pressure * Measured at gas valve pressure tap when the gas valve is on. b. Gas Connections: Inlet connection ----- 1-inch N.P.T. Inlet supply size ----- 1-inch N.P.T. (minimum) Btu/hr input (per dryer) ----- 375,000 1) Natural Gas Regulation is controlled by the dryer's gas valve's internal regulator.
Page 33 3. Piping/Connections ALL components/materials must conform to National Fuel Gas Code Specifications, or in CANADA, the Canadian Installation Codes (for General Installation and Gas Plumbing). It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of all the appliance Btu's being supplied.
Page 34 IMPORTANT: The dryer and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5kPa). NOTE: The dryer must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5kPa).
Page 35: Steam Information
H. STEAM INFORMATION It is your responsibility to have ALL steam plumbing connections made by a qualified professional to assure that the installation is adequate and conforms with local and state regulations or codes. IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure which will VOID THE WARRANTY.
Page 36 a. The pressure of the condensate in the steam supply will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made b. The steam supply piping to the dryer must include a 12-inch rise along with a drip trap and check valve. This will prevent any condensate from entering the steam coil.
Page 37 3. STEAM DAMPER AIR SYSTEM CONNECTIONS The ADS-120ES is manufactured with a pneumatic (piston) damper system which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve which is located at the rear inner top area of the dryer just above the electric service relay box (refer to the bottom illustration on page 34).
Page 38 5. STEAM DAMPER AIR PISTON (FLOW CONTROL) OPERATION ADJUSTMENT Although the damper operation was tested and adjusted prior to shipping at 80 psi, steam damper operation must be checked before the dryer is put into operation. Refer to page 37 for instructions to check system damper operation.
Page 39: Preparation For Operation / Start-Up
I. PREPARATION FOR OPERATION The following items should be checked before attempting to operate the dryer: 1. Read ALL "CAUTION," "WARNING," and "DIRECTION" labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label located in the front top console area as shown on page 8.
Page 40: Preoperational Tests
J. PREOPERATIONAL TESTS ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.
Page 41 IMPORTANT: There is no regulator provided in an L.P. dryer. The water column pressure must be regulated at the source (L.P. tank) or an external regulator must be added to each dryer. b. Electric Models 1) Check the oven contactor(s) to insure that the electric oven is cycling properly. c.
Page 42 8. Each dryer should be operated through one complete cycle to assure that no further adjustments are necessary and that ALL components are functioning properly. 9. Make a complete operational check of ALL operating controls. a. Microprocessor controller (computer) programs/selections... 1) Each microprocessor controller (computer) has been preprogrammed by the factory with the most commonly used parameter (program) selections.
Page 43: Operating Instructions
K. OPERATING INSTRUCTIONS NOTE: Before attempting to start the dryer make sure that the main door is closed and the lint drawer is securely in place. 1. To start the dryer. a. Microprocessor (Computer) Dryers 1) Display will read "FILL" (meaning no cycle in progress). 2) Press the letter on the keyboard (touchpad) corresponding to the cycle desired (i.e., Ke "E")...
Page 44: Shut Down Instructions
L. SHUT DOWN INSTRUCTIONS If the dryer is to be shut down (taken out of service) for a period of time, the following must be performed: 1. Discontinue power to the dryer either at the external disconnect switch or the circuit breaker. 2.
Page 45: Service/Parts Information
SERVICE/PARTS INFORMATION A. SERVICE 1. Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Service Department for a distributor in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.
Page 46: Warranty Information
WARRANTY INFORMATION A. RETURNING WARRANTY CARD(S) 1. Before any dryer leaves the ADC factory test area, a warranty card (ADC Part No. 112254) is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.
Page 47 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure (be specific). c. Date of dryer installation. d. Date of part failure. e.
Page 48: Routine Maintenance
ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location.
Page 49 STEAM DRYERS Clean the steam coil fins. We suggest using compressed air and a vacuum cleaner with brush attachment. WARNING: When cleaning steam coil fins, be careful not to bend the fins. If fins are bent, straighten by using a fin comb which is available from local air-conditioning supply houses.
Page 50: Adjustments
B. ADJUSTMENTS 7 Days After Installation and Every 6 Months Thereafter Inspect bolts, nuts, screws (bearing set screws), non-permanent gas connections (unions, shut-off valves, orifices, and grounding connections). Motor and drive belts should be examined. Cracked or seriously frayed belts should be replaced. Tighten loose V-belts when necessary. Complete operational check of controls and valves.
Page 51: Troubleshooting
IMPORTANT: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
Page 52 2. Failed arc suppressor (A.S.) board. 3. Failed drive motor. 4. Failed microprocessor controller (computer). C. Drive motor (reversing) operates in one direction only ... stops and restarts in same direction ... 1. Failed drive motor contactor (relay). 2. Failed arc suppressor (A.S.) board. 3.
Page 53 G. Both drive motor and blower motor not operating (do not start) ... microprocessor controller (computer) motor indicator dots are on ... 1. Failed arc suppressor (A.S.) board. 2. Failed microprocessor controller (computer). H. Both drive motor and blower motor run a few minutes and then stop...microprocessor controller (computer) display continues to read time or percent of extraction and all indicator dots are off ...
Page 54 K. Microprocessor controller (computer) will not accept any keyboard entries, i.e., L.E.D. display reads "FILL" and when keyboard entries are selected, the L.E.D. display continues to read "FILL" ... 1. Failed keyboard label (touchpad) assembly. 2. Failed microprocessor controller (computer). L.
Page 55 P.No heat (GAS MODEL ONLY)...ignitor sparks, burner goes on and off right away ... 1. DSI ignitor / flame-probe out of adjustment...reposition closer to the flame area. 2. Sail switch is fluttering ... a. Lint screen dirty. b. Restriction in exhaust duct work. 3.
Page 56 S. Dryer operates but is taking too long to dry ... 1. Exhaust duct work run too long or is undersized...back pressure cannot exceed .3 inches Water Column (W.C.). 2. Restriction in exhaust ... a. Exhaust back draft damper is sticking partially closed. b.
Page 57: Timer Models
Dryer or scraping noise at basket (tumbler) area ... 1. Check for object caught in basket (tumbler) / wrapper area. 2. Basket (tumbler) is out of proper alignment ... a. Check both vertical and lateral alignment. b. Check gap between front panel and basket (tumbler) front...set screws may have come loose, and basket (tumbler) walked forward or backwards.
Page 58 B. Drive motor (only) not operating (does not start)... 1. Failed drive motor contactor. 2. Failed reversing timer (for Reversing Models ONLY). 3. Failed drive motor. C. Blower (impellor/fan) motor (only) not operating (does not start)... 1. Tripped or failed overload. 2.
Page 59: Electric Models
ELECTRIC MODELS 1. Fault in sail switch circuit ... a. Sail switch out of adjustment and/or has failed. b. Sail switch is not closing or is fluttering ... 1) Check blower (impellor / fan) motor and rotation direction. 2) Restriction in exhaust. 2.
Page 60 b. Lint accumulation in location exhaust system. 5. Insufficient make-up air. 6. Failed hi-limit thermostat (for GAS and ELECTRIC MODELS ONLY). 7. Failed lint compartment automatic (225º) safety thermostat circuit. 8. Extractors not performing properly. 9. Low and/or inconsistent gas pressure (for GAS MODELS ONLY). 10.
Page 61 K. Dryer scraping noise at basket (tumbler) area... 1. Check for object caught in basket (tumbler) / wrapper area. 2. Basket (tumbler) is out of proper alignment. a. Check both vertical alignment and lateral alignment. b. Check gap between front panel and basket (tumbler) ... set screws may have come loose, and basket (tumbler) walked forward or back.
Page 62: Reversing Timer Spin/Dwell Adjustments
REVERSING TIMER SPIN/DWELL ADJUSTMENTS Timer models have an electric reversing timer in the electric service box which is located in the upper left rear area of the dryer. Both the Dwell (stop) Time and basket (tumbler) Spin Time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below).
Page 63: Procedure For Functional Check Of Replacement Components
PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor (computer) Board a. Upon completing installation of the replacement microprocessor (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motor(s) and the heat indicator dots, in the microprocessor (computer) L.E.D. display are on.
Page 64 e. Open main door. The dryer must stop and ALL output indicator lights on the back side of the microprocessor (computer) board must go out. f. Try to restart the dryer with the main door open. g. The microprocessor (computer) board's L.E.D. display must read "DOOR." h.
Page 65 ADC 112185 1- 07/05/95-100 4* 09/04/96-250 7* 01/19/98-100 10* 03/12/99-100 11- 08/13/99-100 13- 05/09/00-125 14- 09/28/00-100 2- 07/27/95-250 3* 03/20/96-250 5* 03/12/97-250 6- 10/14/97-100 8- 04/16/98-100 9* 07/17/98-200 12* 01/03/00-125...
