Landmark 600, an Overview

Tech 21's proprietary, 100% analog circuitry has been adapted from

its SansAmp configuration into a 600-watt bass amp system with 2

distinctively different channels. The Landmark 600 offers a wide

range of the most desirable tube amp sounds, including Fender

SVT

styles, as well as a variety of overdriven tones --the ones that

typically require a complex mass of rack effects that haven't really

been tailored for bass in the first place. The interactive controls give

you access to specific tone shaping characteristics to create your

own custom sounds as well.

An Optional Footswitch further expands the amp's capabilities. In

addition to being able to remotely change channels, there is a MIX

function to simultaneously engage both channels, giving you 3

footswitchable sound options, and a MUTE switch which allows you

to silently tune your instrument.

For studio and live applications, our SansAmp Tube Amplifier

Emulation technology enables you to go straight into the mixer of a

recorder or PA system via the XLR Direct Output.

With the Landmark 600, you get a truckload of big amp sounds in a

single cost-effective package.

The Landmark 600 is powered by potentially hazardous voltage. Therefore, observe

the following safety precautions:

WARNING: To avoid the risk of fire, electric shock or injury, do not expose this unit

to moisture. Do not remove cover from chassis. Removing the cover exposes

extremely dangerous high voltages. There are no user-serviceable parts inside.

Hazardous voltages are present inside the chassis. Refer all servicing to qualified

service personnel.

CAUTION: Never modify the power cord. If the original power cord becomes dam-

aged, refer servicing to qualified service personnel.

and

WARNING: Attempting to repair this unit is not recommended and may void its war-

ranty. NOTE: In the U.S. and Canada, servicing is performed at factory only. In other

countries, please refer repairs to the local Tech 21 authorized distributor.

ADDITIONAL PRECAUTIONS:

1. Do not allow liquids or objects to penetrate unit.

2. When in use, provide proper ventilation at front and back of unit.

3. During heavy use, chassis may get hot to the touch. Handle with care.

4. Protect unit from strong impact.

5. Do not locate near heat.

6. This unit must be earth grounded.

Here's how to get your Landmark 600 up and running before reading the entire manu-

al. Note: By not reading the manual, you'll miss out on getting the most out of your

new investment!

1. Plug the Landmark 600 head into speaker cabinet(s). If possible, we recommend

using Speakon

If you're not using Tech 21's B410s, we recommend cabinets be rated for minimum

of 400W RMS at 8 or 600W RMS at 4 .

2. Plug the Landmark 600's AC cord into a wall socket.

3. Plug your instrument into the top-panel Input jack (on the left side).

4. Make sure the Level control on each channel is turned down. Then turn on the

Landmark 600 and adjust the Level controls accordingly.

5. Play your guitar and you should hear a sound coming through the amp. If not, check

that your guitar's volume control is turned up, recheck your connections, and be sure

your cable isn't faulty. If there is still no sound, refer to factory or qualified technician.
