Tech 21 Bass Power Engine 60 Owner's Manual page 5

NOTEWORTHY NOTES & CONSIDERATIONS
1) Powering Up and Powering Down. To avoid the typical loud pop and
potential harm to the Bass Power Engine speaker, power up in this order:
For Mono Applications:
For Stereo Applications:
With PA System: Be sure to keep the PA volume fader down until all
connections are made and everything is turned on. Before shutting anything
off, remember to turn the PA volume fader down.
2) Hum. If nothing is plugged into the input of the Bass Power Engine, you may
notice a slight hum caused by the open input transformer. When you plug something
into the input, the circuit will be completed and the hum will disappear.
3) EQ. We recommend starting with all controls flat. Then use each sparingly as
needed for whatever room you're in. Remember, you need not set everything at max
to obtain maximum results. It would be rare that turning all the tone controls up would
accomplish a favorable sound. In most instances, a slight cut of the Mid control
should be adequate.
4) Volume. When chaining the Bass Power Engine with an amp, be sure to set the
Level control to match (approx.) the output volume of the amp. If the Bass Power Engine
is set higher than the amp, it may cause undesirable distortion. Note: Rely on your ears.
The position of the level knobs of the amp and Bass Power Engine may not necessarily
be the same.
5) Enjoy!
1st: Amp or pre-amp/processor
2nd: Bass Power Engine 60
Power down in reverse order.
1st: Stereo processor
2nd: Amp or pre-amp/processor
3rd: Bass Power Engine 60
Power down in reverse order.
7
BASS POWER ENGINE 60 SPECIFICATIONS
Note: With on-going product development and improvements, specifications and/or
the cosmetic appearance of these units may change without prior notice.
Model Number:
Input Impedance:
Nominal Input Level:
Optimal Output Load:
Power Output:
Maximum Power Consumption:
AC Input Power (factory set):
Cycles:
Speaker:
Cabinet:
Dimensions:
Weight:
Optional Accessory:
Replacement parts (i.e., knobs, grill panel, speaker, logo plate, handle, etc.) are
available through your authorized dealer, distributor or directly from Tech 21.
BPE60
10kΩ
-20dBu to +4dBu
8Ω
60W
120W
100V, 117V, 230V, 240V
50/60 Hz
NOTE: Each unit is constructed for specific
voltages. AC power cannot be switched.
Tech 21 Model #2112-B. Custom-designed
12" / 100W - 8Ω
Constructed of plywood with custom
chrome-plated steel grill.
18.25"w x 18.75"h x 14.25"d
36 lbs.
Black vinyl cover with silver embroidered logo
8
