- Page 1 WWW.SHARKCLEAN.COM LIFT-AWAY ™ STEAM POCKET ® S3901K N OWNER’S GUIDE S3901K_N_11_IB_E_120410_3.indd 1 12-04-10 11:40 AM...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WARNING: WHEN USING YOUR SHARK ® STEAM MOP, BASIC SAFETY TO REDUCE THE RISK OF FIRE, ELECTRIC PRECAUTIONS SHOULD ALWAYS SHOCK OR INJURY: BE FOLLOWED, INCLUDING THE 1. Use the system only for its intended use. - Page 3 12. DO NOT put any objects into openings. Do not 21. Extreme caution should be exercised when use with any opening that is blocked. using this appliance to clean stairs. 13. DO NOT put hands or feet under the steam 22.
- Page 4 This manual covers model number: S3901K N 11 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz. Power: 1550 Watts Water Capacity: 300ml (10.14 oz.) TOLL FREE: 1-800-798-7398 S3901K_N_11_IB_E_120410_3.indd 4 12-04-10 11:40 AM...
-
Page 5: Table Of Contents
Contents Thank you for Getting Started ....................2 purchasing Getting Started With Your Steam Mop ..............4 the Shark ® Using Your Steam Mop ..................6 Lift-Away ™ Using Your Carpet Glider ..................9 Steam Pocket Getting Started With Your Removable Handheld Steamer ........10 ®... -
Page 6: Getting Started
Getting Started When assembling your steam mop there may be a little water in or around the water tank. This is because we test all our steam mops 100% before you buy them, so you get a quality Shark Lift-Away Pro Steam ®... - Page 7 Fig. 1 Fig. 4 Fig. 2 Fig. 5 Fig. 3 Fig. 6 ACCESSORIES: CONTROLS: DIRECT STEAM NOZZLE STEAM TRIGGER Loosen and dislodge compact dirt found in corners When using the Handheld Steamer, press and hold or tight places. (Fig. 1) the steam trigger to start steaming.
-
Page 8: Getting Started With Your Steam Mop
Secure the plugged into the wall. To prolong the life of your assembled handle and pole by using the large Shark Lift-Away Pro Steam Pocket ®... - Page 9 fig. 5 fig. 3 fig. 6 fig. 4 Select either the All-Purpose Mop Head or the IMPORTANT: Do not use on unsealed wood Triangle Mop Head and accompanying cleaning or unglazed ceramic floors. On surfaces that pad. Use the lavender loop on the side of the have been treated with wax or some no wax cleaning pad to slide the mop head into the pad floors, the sheen may be removed by the heat...
-
Page 10: Using Your Steam Mop
120-volt electrical outlet. (fig. 7) Visit www.NavigatorClean.com for other great quick cleaning products to complement your The ON/STEAM SETTING button will be blue. Steam Mop, such as the Shark Navigator™ If the light does not turn on, reference the ®... - Page 11 Press the ON/STEAM SETTING button twice for SETTING button until the light blinks blue as in MOP. MOP setting is for normal, everyday steam standby mode. cleaning. (fig. 10) NOTE: When using your Shark Lift-Away ® ™ Press the ON/STEAM SETTING button three...
- Page 12 Using Your Steam Mop - cont’d The Shark Lift-Away Pro Steam Pocket Mop has three unique steam settings so ® ™ ® you can use the perfect amount of steam for the cleaning task at hand. See below for tips on when to use each setting.
-
Page 13: Using Your Carpet Glider
When the water tank is empty, the Steam Mop will stop producing steam. You can refill the water tank at any time as long as the mop is unplugged from the outlet. Follow the instructions from page 5. This applies to switching the mop heads or cleaning pad as well. -
Page 14: Getting Started With Your Removable Handheld Steamer
Getting Started With Your Removable Handheld Steamer Your Shark Lift-Away Pro Steam Pocket ® ™ ® Mop is designed to clean surfaces that will withstand high heat and moisture. Do not use on unsealed wood surfaces (especially wooden antique furniture),... -
Page 15: Using Your Removable Handheld Steamer With Direct Steam Nozzle
Using Your Removable Handheld Steamer with Direct Steam Nozzle Cleaning Tip: The Direct Steam Nozzle creates direct steam spray to clean and sanitize hard to reach nooks & crannies and other places where germs may build up. Use the Direct Steam Nozzle to loosen and dislodge compact dirt often found in corner and tight places where traditional methods and cleaning tools tend to push dirt into, making it tough to reach and clean. -
Page 16: Using Your Removable Handheld Steamer With Garment Steamer
Using Your Removable Handheld Steamer with Garment Steamer Cleaning Tip: The Garment Steamer is ideal for removing wrinkles from clothing and freshening and grooming upholstery. A terry bonnet and frame with bristles provides controlled steaming for most types of clothing. A specialized bonnet is ideal for freshening couches and other upholstery, where odors may accumulate. -
Page 17: Using Your Removable Handheld Steamer With Accessory Hose
Using Your Removable Handheld Steamer with Accessory Hose fig. 21 fig. 22 CAUTION: Do not press the steam trigger To use the Accessory Hose, first attach the Accessory Hose to the Handheld Steamer by while attaching or removing the Accessory Hose. snapping the Accessory Hose into the main CAUTION: Do not use the Accessory Hose nozzle. -
Page 18: Using Your Removable Handheld Steamer With Flat Scrubber
Using Your Removable Handheld Steamer with Flat Scrubber Cleaning Tip: The Flat Scrubber is designed for cleaning a variety of surfaces and is exceptional on those that are large and flat including counter tops, table tops, walls mirrors, windows, stairs, shelves and other similar surfaces. Super absorbent bonnet loosens, lifts, and locks in dirt and grime while sanitizing at the same time. -
Page 19: Care And Maintenance
Handheld Steamer into the the tank over a sink. Replace the water cap. cradle of the mop housing. (fig. 26) (fig. 28) Then slide the top end of the Handheld Steamer To store the Shark Lift-Away Pro Steam ® ™... - Page 20 Care and Maintenance - cont. Cleaning Tip: To prevent clogging, it is recommended that you periodically clean the Direct Steam Nozzle and the extension hose stem with the cleaning tool provided or a paper clip. fig. 30 fig. 31 fig. 32 CARE OF YOUR CLEANING PAD AND CLEANING THE NOZZLE BONNETS...
-
Page 21: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS Your steam mop should be securely plugged into a 120V AC electrical outlet only. The Shark Lift-Away ® ™ Pro Steam Pocket ® Check your fuse or breaker. will not turn-on. If your unit still does not work, call Customer Care at 1-800-798-7398. - Page 22 Notes TOLL FREE: 1-800-798-7398 S3901K_N_11_IB_E_120410_3.indd 18 12-04-10 11:40 AM...
-
Page 23: Warranty
SERVICE”. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice. Product Registration Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark product within ® ten (10) days of purchase. You will be asked to provide the store name, date of purchase and model number along with your name and address. - Page 24 EURO-PRO Operating LLC U.S.: Newton, MA 02459 Canada: Ville St. Laurent, Québec H4S 1A7 1-800-798-7398 www.sharkclean.com COPYRIGHT © 2012 EURO-PRO OPERATING LLC PRINTED IN CHINA S3901K _N.E.120410.3 Illustrations may differ from actual product. S3901K_N_11_IB_E_120410_3.indd 20 12-04-10 11:40 AM...
