Philips CEM220/55 Installation Manual

Register your product and get support at
CEM220/55
EN Installation Guide
© 2008 Koninklijke Philips Electronics N.V.
All rights reserved.
1
a b c
d e f g
2
3 4
B
A B
A1 A2 A3 A4 A5 A6 A7 A8
B1 B2 B3 B4 B5 B6 B7 B8
A
a a
b
c
d
a
b
b
c
d
e
c
f
g
h
a b c d
i
d
Overview of parts 1 3 4
For cars with ISO connectors
These are the supplied parts needed to Caution
connect and install this unit.
• Be sure to connect the black ground (earth)
1 In-car audio system
lead fi rst.
2 Sleeve
3 Front panel
4 Trim plate
1
Connect the antenna and amplifi er as
5 Rubber cushion
illustrated, if applicable.
6 Disassembly tools
2
Cut off the bigger end of the supplied stan-
7 Screws 4 pieces
dard connector.
3
Check the car's wiring carefully and connect
them to the supplied standard connector.
Connect wires
4
Connect the supplied standard connector to
the unit.
Caution
1 Green/black Left speaker
Ensure that all loose leads are insulated with
•
strip (Rear)
electrical tape.
2 White/black Left speaker
2 3
For cars with ISO connectors
strip (Front)
1
Pull out the ISO connectors from car
3 Gray/black Right speaker
dashboard and connect them to the bigger
strip (Front)
end of the supplied standard connector.
4 Purple/black Right speaker
2
Connect the other end of the supplied
strip (Rear)
standard connector to the unit.
3
Connect the antenna and amplifi er as
illustrated, if applicable.
Connector Connect to
1 REAR LINE OUT R Rear right
speaker
2 REAR LINE OUT L Rear left speaker
3 SUB OUT Subwoofer
4 ANTENNA Antenna
5
a
b
c
d
5
Install the sleeve into the dashboard and
e RED Ignition key +12V DC
bend the tabs outward to fi x the sleeve.
when ON/ACC
6
Place the rubber cushion over the end of
f BLUE Motor/electric antenna
the bolt.
relay control lead/
7
Slide the unit into the dashboard until you
Amplifi er relay control
hear a click sound.
lead
8
Reconnect the negative terminal of the car
g BLACK Ground
battery.
h Orange/ Illumination switch
white
Turn on
i YELLOW To the +12V car battery
1 Press z to turn on the unit.
To turn off the unit, press z for 3
which is energized at all •
seconds.
times
Set clock
Attach the front panel 5
1 Press MENU/DISP for 3 seconds.
Press 3 or 4 repeatedly to until the cur-
2
1
Insert the right side of the panel in the
rently time is displayed.
chassis until it is correctly engaged.
3 Turn z clockwise to set hour.
2
Press the left side of the panel and point
4 Press z to confi rm.
the left hole at the left pillar.
5 Turn z anti-clockwise to set minute.
3
Release the panel to engage the left side.
6 Press z to confi rm.
4
Attach the trim plate.
View clock
Mount in the dashboard 5
1 Press MENU/DISP repeatedly until the clock
1
If the car does not have an on-board drive
is displayed.
or navigation computer, disconnect the
negative terminal of the car battery.
Listen to radio
• If you disconnect the car battery in a car
that has an on-board drive or navigation
Press SOURCE repeatedly to select Tuner.
1
computer, the computer may lose its
2 Press or to select band: [FM1], [FM2],
memory.
[FM3], [AM1], or [AM2] .
• If the car battery is not disconnected,
to avoid short-circuit, ensure that bare Press ∞ or § to tune to a radio station
3
wires do not touch each other.
manually.
2 • To search for a radio station
Remove the two screws on the top of the
automatically, press SEARCH.
unit.
3
Remove the mounting sleeve with the
supplied disassembly tools.
4
Ensure that car dashboard opening is
within these measurements:
Play audio fi les
1
Press on the front panel to release the
panel.
2
Insert a CD with the printed side facing up.
3
Close the panel.
Press 2; , to start play.
4
To pause CD play, press 2; .
•
To resume CD play, press 2; again.
•
Insert the USB device
1
Open the cover marked on the front
panel.
2
Insert the USB device into the USB socket.
» ToThe unit starts playing from the USB
device automatically.
