COLOR DGPS/PLOTTER/SOUNDER
COLOR GPS/PLOTTER/SOUNDER
Safety Instructions for the Installer ....................... i
Equipment Lists ..................................................... ii
System Configuration ........................................... iv
1.1 Installation of Display Unit .............................................. 1-1
1.2 Installation of Antenna Unit ............................................. 1-3
1.3 Installation of Transducers ............................................... 1-4
1.4 Installation of Sensors .................................................... 1-14
2. Wiring ...............................................................2-1
3. Initial Settings ..................................................3-1
3.1 NMEA Setting .................................................................. 3-1
3.2 Output Data Sentences ..................................................... 3-3
3.3 Antenna Height ................................................................. 3-4
3.4 Baud Rate Setting (GP-1850DF only) .............................. 3-4
3.6 Depth Adjustment ............................................................. 3-6
3.7 External Equipment Setup (Option) ................................. 3-7
(for GP-1850F) .................................................4-1
PACKING LIST .................................................... A-1
OUTLINE DRAWINGS ......................................... D-1
INTERCONNECTION DIAGRAM ........................ S-1
SCHEMATIC DIAGRAM ...................................... S-2
INSTALLATION MANUAL
GP-1850DF
GP-1850F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-1850DF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno GP-1850DF

Summary of Contents for Furuno GP-1850DF

  • Page 1: Table Of Contents

    3.1 NMEA Setting ... 3-1 3.2 Output Data Sentences ... 3-3 3.3 Antenna Height ... 3-4 3.4 Baud Rate Setting (GP-1850DF only) ... 3-4 3.5 Beacon frequency Setting (GP-1850DF only) ... 3-5 3.6 Depth Adjustment ... 3-6 3.7 External Equipment Setup (Option) ... 3-7 3.8 Selecting the Echo Sounder Output Power ...
  • Page 2 9 - 5 2 , A s h i h a r a - c h o , N i s h i n o m i y a , J a p a n T e l e p h o n e : 0 7 9 8 - 6 5 - 2 1 1 1 T e l e f a x : 0 7 9 8 - 6 5 - 4 2 0 0...

  • Page 3: Safety Instructions For The Installer

    SAFETY INSTRUCTIONS Safety Instructions for the Installer WARNING WARNING Do not work inside the equipment unless totally familiar with electrical circuits. Hazardous voltage which can shock, burn or cause serious injury exists inside the equip- ment. Turn off the power at the mains switchboard before beginning the installation.

  • Page 4: Equipment Lists

    Standard supply l l a Optional equipment t i k x i f l i a Equipment Lists...
  • Page 5 Optional equipment (con't)

  • Page 6: System Configuration

    The GP-1850F/1850DF mainly consists of a display unit, a GPS antenna and a dual frequency transducer. A DGPS beacon receiver is provided inside the display unit for GP-1850DF type. The mini chart card drive in the display unit loads elec- tronic charts. External equipment which can be connected include water tempera- ture and speed sensors, autopilot, and DGPS beacon receiver (GP-1850F).

  • Page 7: Installation Of Standard Equipment

    1. Installation of Standard Equipment 1.1 Installation of Display Unit Mounting considerations The display unit can be installed on a tabletop, on the overhead or flush mounted in a console or panel. Hard Cover Figure 1-1 Tabletop, overhead mounting methods When selecting a mounting location for the display unit keep the following in mind: •...

  • Page 8: Mounting Procedure

    Mounting procedure Follow the procedure below to mount the display unit on a tabletop or the over- head. Tabletop, overhead mounting 1. Fix the hanger by four tapping screws M5 X 16. 2. Screw knob bolts in display unit, set it to hanger, and tighten knob bolts. 3.

  • Page 9: Installation Of Antenna Unit

    GPS satellite signal if the water freezes. • The length of the whip antenna for the GP-1850DF should be no longer than 1.2 meter to prevent antenna damage. Do not use a 2.5 meter whip antenna. •...

  • Page 10: Installation Of Transducers

    1.3 Installation of Transducers Installing the inside-hull mount transducer Necessary tools You will need the following tools: • Sandpaper (#100) • Silicone sealant Remarks on installation • Do the installation with the boat hauled out of the water. • Turn off the engine while installing the equipment. •...
  • Page 11 Attaching the transducer 1. Clean the transducer face to remove any foreign material. Lightly roughen the transducer face with #100 sandpaper. Also, roughen the inside of the hull where the transducer is to be mounted. 2. Warm the silicone sealant to 40 C before usage to soften it. Coat the trans- ducer face and mounting location with silicone sealant.
  • Page 12 Observing the picture 1. Press the [POWER] key to turn on the display unit. 2. Press the [SNDR] key to select the sounder display. 3. Press the soft key labeled "MODE/FREQ" to display the following message. Figure 1-8 MODE FREQ selection screen 4.
  • Page 13 32.8 DGPS 3D 50kHz Figure 1-10 Video sounder picture If the bottom is displayed in red and the light-blue color appears the mounting location is suitable. You can leave the transducer in position. If the bottom is not displayed in reddish brown, the mounting location is unsuit- able.
  • Page 14 Installing the thru-hull mount transducer Transducer mounting location This type of mounting provides the best performance of all, since the transducer protrudes from the hull and the effect of air bubbles and turbulence neat the hull skin is reduced. When the boat has a keel, the transducer should be at least 30 cm away from it.
  • Page 15 Acceptable transducer mounting locations Deep-V hull • Position 1/2 to 1/3 length of the hull from stern • 15 to 30 cm off center line (inside first lifting strakes). Figure 1-12 Transducer mounting location on deep-V hull High speed V-planing hull Figure 1-13 Transducer mounting location on high speed Typical through-hull mount transducer installations Fairing block...
  • Page 16 Procedure for installing the thru-hull mount transducer 1. With the boat hauled out of the water, mark the location selected for mounting the transducer on the bottom of the hull. 2. If the hull is not level within 15 in any direction, fairing blocks made out of teak should be used between the transducer and hull, both inside and outside, to keep the transducer face parallel with the water line.

  • Page 17: Installing The Transom Mount Transducer

    Installing the transom mount transducer This type of mounting is very commonly employed, usually on relatively small I/O or outboard boats. Do not use this method on an inboard motor boat because turbulence is created by the propeller ahead of the transducer. There are two methods of installation: flush with hull (for flat hulls) and projecting from hull (for deep V-hulls).

  • Page 18: Transducer Preparation

    M5 x 20 M5 x 20 Tape No. 1 M5 x 14 Figure 1-17 Transom mount transducer, mounting flush with hull Installing the transom mount transducer projecting from hull (for deep-V hulls) This method is employed on deep-V hulls and provides good performance be- cause the effects of air bubbles are minimal.
  • Page 19 Triducer 524ST-MSD, 525ST-MSD The triducer is designed for thru-hull mounting. Mounting considerations When selecting a mounting location keep the following points in mind: • Air bubbles and turbulence caused by movement of the boat seriously degrade the sounding capability of the transducer. The transducer should, therefore, be located in a position where water flow is the smoothest.

  • Page 20: Installation Of Sensors

    1.4 Installation of Sensors Transom mount water temperature sensor T-02MTB • Fix the cable at a convenient location with cable clamp. • When the cable is led in through the transom board, make a hole of approx. 17 mm diameter to pass the connector. After passing the cable, fill the hole with a sealing compound.
  • Page 21 Thru-hull mount water temperature sensor T-02MSB, T-03MSB • Select a mid-boat flat position. The sensor does not have to be installed per- fectly perpendicular. The sensor must not be damaged in dry-docking opera- tion. • Select a place apart from equipment generating heat. •...
  • Page 22 Through-hull mount water temperature/speed sensor ST-02MSB, ST-02PSB Select a suitable mounting location considering the following: • Select a mid-boat flat position. The sensor does not have to be installed per- fectly perpendicular. The sensor must not be damaged in dry-docking opera- tion.

  • Page 23: Wiring

    All wiring are terminated at the rear of the display unit. Antenna unit GPA-018 v G P-1850DFw GPA-019¢ GPA-017 (GP-1850DFw v G P-1850Fw Ground Figure 2-1 Display unit, rear view Power cable Connect the power cable to the power connector. Connect the leads to the battery (12 or 24 VDC);...

  • Page 24: Antenna Unit

    Antenna unit Connect the antenna cable to the ANT connector. Transducer Connect the transducer cable to the XDR connector. Water temperature/speed sensor Connect the water temperature sensor (option) or water temperature/speed sen- sor (option) to the TEMP/SPD connector. Ground The display unit contains several CPUs.
  • Page 25 Extending antenna cable length The standard cable is 10m long. For extension, in case of the GPA-016, GPA-018 and GPA-018S, an antenna cable set of 15m (GPA-018S and GPA-019S), 30m or 50m is available. Extension cable cannot be used with the GPA-017 or GPA-018. Extension cable line-up (in case of 30 m or 50 m) Fabricate the end of the antenna cable and attach the coaxial connector.
  • Page 26 How to attach the N-P-8DFB connector Dimensions in millimeters. Outer Sheath Armor Inner Sheath Shield Cover with heat-shrink tubing and heat. Clamp Gasket (reddish brown) Trim shield here. Trim aluminum tape foil here. Clamp Nut Solder through the hole. Figure 2-5 Fabrication of coaxial cable Remove outer sheath and armor by the dimensions shown left.

  • Page 27: Initial Settings

    3. Initial Setting 3.1 NMEA Setting NMEA port 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA PORT 1". 4. Select "FORMAT" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message. SETUP OUTPUT FORMAT PORT 1...
  • Page 28 DGPS port 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA/DGPS PORT 2". 4. Select "FORMAT" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message. s FORMAT DGPS 3D Figure 3-2 Output Format Display, DGPS port...

  • Page 29: Output Data Sentences

    3.2 Output Data Sentences Select output data sentences for external equipment as follows. 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA PORT 1". 4. Press the software key labeled "SELECT SNTNC." to display the following list. DGPS 3D Figure 3-3 Output Date Sentences Display 5.

  • Page 30: Antenna Height

    If you enter wrong antenna height, press the software key labeled "CLEAR". 7. Press the [ENTER] key. 8. Press the [PLOT] key to return to finish. 3.4 Baud Rate Setting (GP-1850DF only) This setting may not be done when AUTO MODE is selected. 1. Press the [MENU] key.

  • Page 31: Beacon Frequency Setting (Gp-1850Df Only)

    4. Confirm that "ON" is selected at "DGPS MODE" field for GP-1850DF. 5. Select "BEACON BAUD RATE" by the arrow key. 6. Press the software key labeled "EDIT" to display the following message. Figure 3-6 Beacon Baud Rate Display 7. Select beacon baud rate corresponding to DGPS reference station to use.

  • Page 32: Depth Adjustment

    4. Select "BEACON FREQUENCY" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message. Figure 3-8 Beacon Frequency Display 6. Select "AUTO" or "MANUAL" by the arrow key. When you select "MANUAL", operate the cursor pad to move the cursor to frequency dialog box. And press the arrow key to select the frequency desired.

  • Page 33: External Equipment Setup (Option)

    3.7 External Equipment Setup (Option) This section shows you how to set up the GP-1850F/1850DF when external equip- ment is connected. If a water temperature/speed sensor is installed, you should complete this section with the boat in the water and running, to confirm speed/ water temperature readout.

  • Page 34: Speed Adjustment

    Speed Adjustment Adjust speed when you select own speed source "OWN PDDWHL". 1. Press the [MENU] key. 2. Press the software key labeled "DISPLAY OPTIONS". 3. Press the software key labeled "NEXT PAGE" to display the following display. s SPEED SOURCE TEMP SOURCE TEMP GRAPH ZOOM MARKER...
  • Page 35 s SPEED SOURCE TEMP SOURCE TEMP GRAPH ZOOM MARKER SPEED ADJ. TEMP ADJ. DEPTH ADJ. 12.3kt DGPS 3D Figure 3-14 Display Setup 2 Display 4. Select "TEMP ADJ." by the arrow key. 5. For water temperature sensor-equipped sets, you may offset the water tem- perature readout if it is wrong.

  • Page 36: Selecting The Echo Sounder Output Power

    3.8 Selecting the Echo Sounder Output Power The echo sounder output power can be selected for 600 W (for transducer 520- 5PSD, 520-5PWD, 520-5MSD) or 1 kW (50/200-1T), and the default setting is 600 Note: Matching Box MB-1000 and cable assembly 02S4092 are required for 1kW transducer connection.
  • Page 37 Nut, washer Connector gasket Figure 3-15 Removing cover assembly 5. Move the jumper block on JP1 from 3-4 to 1-2 on the ANLG Board. Figure 3-16 ANLG Board Nuts Binding screws M3x10, 10 pcs. Cover assembly Panel/chassis assembly WARNING Do not connect the power cable with the cover removed.
  • Page 38 6. Remount the cover assembly. Note: Confirm that the following parts are attached: • Inside of the cover: Shield gaskets, GN gasket (See Figure 3-17.) • On ANLG Board: Connector gasket (See Figure 3-15.) Figure 3-17 Inside of the cover 7.

  • Page 39: Installation Of Dgps Beacon Receiver (For Gp-1850F)

    4. Installation of DGPS Beacon Receiver The DGPS beacon receiver GR-7000A can be incorporated in the GP-1850F to provide it with DGPS capability. Six installation kits are available as shown. GR-802-1650-10A-018 (W/whip ant.) GR-802-1650-10N-018 GR-802-1650-10N-019 (for GP-1850F) GR-802-1650-15A-018S (W/whip ant.) GR-802-1650-15N-018S GR-802-1650-15N-019S...
  • Page 40 Disassembly Procedure 1. Turn off the power. Wait at least one minute before opening the cover, to allow capacitors to discharge. 2. Remove nuts attached to DGPS, NMEA and power supply connectors at the rear of the display unit. Nut, washer WARNING Do not connect the power cable with the cover...
  • Page 41 Installation of DGPS receiver Procedure 1. Dismount chassis assembly from panel/chassis assembly by disconnecting the connector and PH8P from J8 on MAIN Board shown in the figure below. View Remove two ties. Cable w/8P connector Figure 4-2 Dismounting chassis assembly 2.
  • Page 42 Do not touch the connector with bare hands; use gloves. Use radio pincers to remove, and pull out straightly. Plug in connector straightly. 3. Fasten the GR-7000A (DGPS beacon receiver) to the heat sink with four 3X8 screws as shown in the figure below. GN-7707 Figure 4-4 Installation of DGPS beacon receiver 4.
  • Page 43 7. Wire cable assembly as shown in the figure below. Reattach this tape as shown right after the DGPS connection. To J8 of GN-7707 ANLG Board 8. Mount the ANLG board on the heat sink referring to step 2. Fasten cable assy. S.FL2-2LP0.7-D-WHT (250), 8P connector cable and 6P connector cable by cable tie (CV-100, supplied) as shown in the figure below.
  • Page 44 MAIN Board 14P0311B A view 8P connector to J8 6P connector to J7 11.Reassemble the display unit. Washer (Torque: 1.37-1.57 N m) Figure 4-9 Remounting the cover Note : When reattaching the cover, confirm the following parts are attached. • Inside of the cover : Shield gaskets, GN gasket (See Figure 4-10.) •...
  • Page 45 Figure 4-10 Inside of the cover Checking the DGPS installation 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SYSTEM MENU". 4. Press the software key labeled "SELF TEST". 5. Press the software key labeled "MEMORY•I/O TEST" to display the following message.

  • Page 46: Appendix Triducer 525St-Pwc/Pwd

    APPENDIX TRIDUCER 525ST-PWC/PWD This appendix provides a copy of the installation instructions for AIRMAR triducer. If you loose the original supplied with the triducer, use this appendix. INSTALLATION INSTRUCTIONS Transom Mount Transducer or TRIDUCER Multisensor with Integral Release Bracket Model P66 U.S.
  • Page 47 APPENDIX TRIDUCER 525ST-PWC/PWD P66 Installation template for starboard side of boat Drill at locations labeled "B" for the following transom angles: 16 through 22 Drill at locations labeled "A" for the following transom angles: 2 through 15 Align arrow with bottom of transom Align template vertically Align template arrow with bottom edge of transom...
  • Page 48 2 -10 transom angle 11 transom angle NO SHIM shim with taper down parallel parallel 12-18 transom angle NO SHIM angle slight reversed angle Figure 5. Sensor angle adjustment on transom To adjust the sensor’s angle relative to the hull, use the tapered plastic shim provided.
  • Page 53 Connecting DGPS beacon receiver A DGPS beacon receiver whose output format is RS-232C can be connected to the GP-1850F. Below is the example of interconnection between the GP-1850F and FURUNO beacon receiver GR-80. GP-1850F DGPS Figure 4-11 Connecting DGPS beacon receiver...
