Page 1: Repair Parts
COOKTOP DDRAFT Repair Parts List MODEL NUMBER CVE1400B-C When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: CONTROL ASSEMBLY Model: CVE1400B-C C10-231...
-
Page 3: Control Assembly
Section: CONTROL ASSEMBLY Part No. Description Series Qty 71001559 ESCUTCHEON Note: ESCUTCHEON (BLK) Y704864 SCREW Note: SCREW, SWITCH 703650 SWITCH, INFINITE Y04100035 NUT, PUSH Note: NUT, PAL 71001562 BOX, LIGHT ASSY. Note: BOX ASSY., LIGHT 71001564 SWITCH, FAN (BLK) Note: (BLK) 71001579 RELAY, FAN 71001565... - Page 4 Section: TOP ASSEMBLY Model: CVE1400B-C C15-228...
-
Page 5: Top Assembly
Section: TOP ASSEMBLY Part No. Description Series Qty Y04100372 MAIN TOP (BLK)----N Note: (BLK) Y707347 SCREW ----S Note: SCREW, GRILL 71001576 GRILL, AIR Note: (BLK) Y04100528 DRIPBOWL, 8" (BLK) Note: (8" BLK) Y04100527 DRIPBOWL, 6" (BLK) Note: (6" BLK) Y04100166 ELEMENT 8"... - Page 6 Section: BURNER BOX ASSY. Model: CVE1400B-C C14-278...
- Page 7 Section: BURNER BOX ASSY. Part No. Description Series Qty 1 N 04100395 BOX, BURNER 2 N 04100396 BAFFLE, BURNER BOX Note: BAFFLE, BURNER BOX 701662 RIVET Note: RIVET Y707121 SCREW Note: SCREW, BURNER BOX Y707124 NUT,SQUARE Note: NUT, SQUARE Y700502 SCREW Note: SCREW (#8AB/WASHER) N 04100398 LIMIT SHIELD Note: SHIELD, LIMIT...
- Page 8 Section: BLOWER ASSEMBLY-PLENUM Model: CVE1400B-C C18-31...
- Page 9 Section: BLOWER ASSEMBLY-PLENUM Part No. Description Series Qty 71001577 PLENUM ASSY. Note: PLENUM ASSY Y704761 RING, RESTRICTOR 712008 SCROLL, BLOWER ASSY. Y704762 RETAINER Note: RETAINER, RING 702889 LOCKNUT CAP, W/NYLON INSERT Note: LOCKNUT CAP Y704758 RING, INLET Y707831 CLIP Note: CLIP, COVER 701958 CLIP, TINNERMAN Note: CLIP, COVER 71001578...
