  • Page 1 MP3 CD RECEIVER WITH BLUETOOTH CDE-125EBT • OWNER’S MANUAL Please read before using this equipment. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 1-1-8 Nishi Gotanda, 161-165 Princes Highway, Hallam Viale C. Colombo 8, 20090 Trezzano...

  • Page 3: Table Of Contents

    ENGLISH Contents Sound Setting Adjusting Subwoofer Level/Bass Level/Treble Operating Instructions Level/Balance (Between Left and Right)/ Fader (Between Front and Rear)/Defeat ..12 Setting the Bass Control ......... 12 WARNING Setting the Treble Control ....... 12 Adjusting the High Pass Filter ......13 WARNING ..........
  • Page 4 BT Hands-Free Calling iPod/iPhone (Optional) Setup Before Using ......... 17 Playback ............22 About BLUETOOTH ........17 Searching for a desired Song ......22 Before Using Hands-Free Function .... 17 Quick Search ...........22 How to connect to a BLUETOOTH Direct Search Function ........23 compatible device (Pairing) .....

  • Page 5: Operating Instructions

    ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Any function that requires your prolonged attention should only be Alpine Service Centre for repairing.
  • Page 6 We Irregular Shaped Discs recommend not using these accessories on discs played in Alpine CD players. Be sure to use round shape discs only for this unit and never use any special shape discs.

  • Page 7: Caution

    • Do not touch the surface. • Do not expose the disc to direct sunlight. Alpine accepts no responsibility for lost data, etc., even if data, etc. • Do not affix stickers or labels. is lost while using this product.

  • Page 8: Getting Started

    Attaching Getting Started Insert the right side of the front panel into the main unit. Align the groove on the front panel with the projections on the main unit. Rotary encoder Push the left side of the front panel until it locks firmly into the main unit.

  • Page 9: Setting Time

    Controllable with Remote Control OFF (Manual mode) DX SEEK This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. • The initial mode is Distance mode. Point the optional remote control transmitter at the remote-control sensor.

  • Page 10: Presetting Stations Automatically

    Presetting Stations Automatically CD/MP3 Press BAND repeatedly until the desired radio band is displayed. SOURCE/ Rotary encoder Press and hold TUNE/A.ME for at least 2 seconds. The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band.

  • Page 11: Repeat Play

    Press to select the desired track (file). CD mode: Returning to the beginning of the current track (file): Press : Only a track is repeatedly played back. Fast backward: Press and hold Advancing to the beginning of the next track (file): MP3 mode: Press Fast forward:...

  • Page 12: Searching For Cd Text

    Searching for CD Text Quick Search On discs utilizing CD Text, songs can be searched and played by using You can search for tracks (files). their recorded titles. For discs without CD Text, searches are made Press and hold /ESC for at least 2 seconds in the using the track numbers associated with each song.
  • Page 13 Supported playback sampling rates and bit rates Order of files Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be what Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, is expected.

  • Page 14: Sound Setting

    Setting the Bass Control Sound Setting You can change the Bass Frequency emphasis to create your own tonal preference. Rotary encoder (AUDIO/LOUD) SOURCE/ BAND Press SOUND/SETUP repeatedly to select the BASS mode. BASS TREBLE BASS Setting the Bass Centre Frequency -1 Press BAND to select the desired bass centre frequency.

  • Page 15: Adjusting The High Pass Filter

    Setting the Treble Centre Frequency Other Functions -1 Press BAND to select the desired treble centre frequency. 10.0 kHz 12.5 kHz 15.0 kHz 17.5 kHz 10.0 kHz SOURCE/ Emphasises the displayed treble frequency ranges. Setting the Treble Level Turn the Rotary encoder to select the desired treble level (–7~+7).

  • Page 16: Displaying Time

    About the indication display Using the Front AUX Input Terminal When displaying Text, the following indicators are lit according to the mode. Connect a portable music player, etc. by simply connecting it to the input on the front panel. An optional adapter cable is required (standard RCA to 3.5ø...

  • Page 17: Setup

    Sound Customizing SETUP Subwoofer On and Off SUBW ON (Initial setting) / SUBW OFF You can flexibly customize the unit to suit your own preferences and usage. From the SETUP menu, Sound Customizing, Visual When the subwoofer is on, perform the steps below to adjust the Customizing, etc., can be modified.

  • Page 18: Mp3

    Setting the AUX+ SETUP Mode AUX+ ON / AUX+ OFF (Initial setting) An external device (such as a portable music player) can be connected Playing MP3 Data (PLAY MODE) to the Full Speed connector of this unit. A conversion cable CD-DA (Initial setting) / CDDA/MP3 (KCE-237B) for building up the AUX IN (optional) is required.

  • Page 19: Bt Hands-Free Calling

    For handling of the BT compatible device, Press and hold SOUND/SETUP for at least 2 consult your ALPINE dealer or ALPINE website. seconds to activate the SETUP mode. • Depending on the surroundings, BLUETOOTH wireless connection may be unstable.

  • Page 20: Setting The Search Mode

    “ID UNSENT” will also be displayed. the time of printing. Alpine reserves the right to change or modify any information or specifications without notice or obligation.

  • Page 21: Answering A Call

    Press /ENT. Answering a Call The selected telephone will be called. If one name has several numbers registered in the telephone Incoming calls are announced by the received call ring tone and a book, press /ENT after selecting the name*, then turn the displayed message (PHONE).

  • Page 22: Voice Dial Operation

    Voice Dial Operation USB memory (Optional) You can call the telephone by performing voice operation. Press and hold /VOICE DIAL for at least 2 seconds. The speak mode is activated, and “SPEAK” is displayed. Say the telephone number, name you want to call into the microphone.

  • Page 23: Usb Memory Connection (Optional)

    (sold separately) separately) An iPod/iPhone can be connected to this unit by using the proprietary ALPINE FULL SPEED Connection Cable (KCE-433iV) (sold separately). When this unit is connected by using the cable, the controls Remove USB memory on the iPod are not functional.

  • Page 24: Playback

    Press /ESC to activate the search selection mode. Playback “ ” indicator lights up. Turn the Rotary encoder to select the ARTIST Press SOURCE/ to switch to the iPod mode. search mode, and then press /ENT. TUNER DISC USB AUDIO iPod* /AUX+* PLAYLIST...

  • Page 25: Direct Search Function

    Direct Search Function Random Play Shuffle (M.I.X.) The unit’s direct search function can be used to search for an album, The Shuffle function of the iPod/iPhone is displayed as on this song, etc., more efficiently. In PLAYLIST/ARTIST/ALBUM/SONG/ unit. PODCAST/GENRE/COMPOSER/AUDIOBOOK mode, you can Shuffle Albums: quickly target any song.

  • Page 26: Repeat Play

    This guide will help you isolate the problem if the (off) unit is at fault. Otherwise, make sure the rest of your system is properly (Repeat One) connected or consult your authorized Alpine dealer. To cancel repeat play, select (off) with the above Basic procedure.

  • Page 27: Indication For Cd Player

    Press the button again for at least 2 seconds. - Securely re-mount the unit. If the disc still does not eject, consult your Alpine dealer. • The disc is very dirty. - Clean the disc. • The disc has scratches.

  • Page 28: Indication For Usb Memory

    Indication for USB memory Indication for iPod Mode • Abnormal current is run to the USB connector device (an error • The iPod/iPhone is not connected. - Make sure the iPod/iPhone is correctly connected (refer to message may be displayed if the USB device that is not compatible with the unit is connected).

  • Page 29: Specifications

    GENERAL Specifications Power Requirement 14.4 V DC (11-16 V allowable) FM TUNER SECTION Maximum Power Output 50 W × 4 Tuning Range 87.5-108.0 MHz Maximum Pre-Output Voltage 2 V/10 k ohms Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms) Bass ±14 dB at 100 Hz Alternate Channel Selectivity 80 dB...

  • Page 30: Installation And Connections

    When connecting the CDE-125EBT to the fuse box, make safety-related system), or tanks should NEVER be used for sure the fuse for the intended circuit of the CDE-125EBT has the installations or ground connections. Using such parts could disable appropriate amperage.

  • Page 31: Installation

    ”, use an appropriate screw for the chosen mounting location. Connect each input lead coming from an amplifier to the corresponding output lead coming from the left rear of the CDE-125EBT. Connect all other leads of Detachable Front the CDE-125EBT according to details described in Panel the CONNECTlONS section.

  • Page 32: Connections

    Connections To iPod/iPhone Antenna (Blue) POWER ANT To power antenna (Blue/White) REMOTE TURN-ON To amplifier (Pink/Black) AUDIO INTERRUPT IN Not used (Orange) ILLUMINATION To the instrument cluster illumination lead (Red) IGNITION Ignition Key (Yellow) BATTERY (Black) Battery (Grey) Speakers SPEAKER RIGHT FRONT Front Right (Grey/Black)
  • Page 33 • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
  • Page 34 About the Rules of Bluetooth Electromagnetic Radiation Regulation Country Rules of Electromagnetic Radiation Regulation Approved by TRA Thailand This telecommunication equipment conforms to technical standard NTC TS1010-2550 Australia Declaration of Conformity New Zealand...
