Vauxhall Agila Quick Reference Manual

Vehicle features
Side air vents (1): Window defroster nozzles (2):
Unheated or heated air (depending on Air distribution switch set to V or J:
the position of the temperature switch) Unheated or heated air will be directed
will be directed into the vehicle. onto the windscreen and onto the door
windows.
Turn knurled wheel clockwise to open
side air vents and anticlockwise to close.
To increase the air supply, set the fan to
a higher speed and set the air
distribution switch to M.
The air flow can be directed as desired
by tilting and swivelling the slats.
Outside temperature: Trip odometer:
A fall in temperature is indicated Switchable from overall odometer to
immediately and a rise in temperature one of two trip odometers (A and B)
after a time delay.
To switch from overall odometer (ODO)
to trip odometer A (TRIP A)
To warn the driver that the road surface
or trip odometer B (TRIP B):
may be icy, when the temperature drops
Press the reset knob briefly to switch
below 3 °C the symbol : appears on the
between the three options.
display.
Reset trip odometer A or B by
When the outside temperature
pressing and holding down the reset
increases, the symbol : does not
knob for approx. 2 seconds.
disappear from the display until the
temperature reaches 5 °C.
Caution: The road surface may already
be icy even though the display indicates
a few degrees above 0 °C.
Refer to Owner's Manual for detailed information.
Instruments and controls
Fuel Filler Cap:
To open: Unlock filler cap with ignition
key 3 and unscrew. Remove filler cap
carefully so that pressure can escape
slowly.
Attach filler cap to bracket on flap and
turn to secure.
To close: Replace filler cap and turn,
overcoming the resistance, until the lock
on the cap engages audibly. Lock filler
cap with the ignition key 3.
Fuel Tank:
Use unleaded fuel for petrol engines.
Fuel tank capacity - 41 litres
Transmission:
Engaging reverse gear: With vehicle
stationary, 3 seconds after depressing
clutch, push lever to right and engage
reverse.
Engine oil:
Check every 300 miles and prior to long
journeys.
Important: It is the owner's responsibility
to maintain the correct level of an
appropriate quality oil in the engine.
Tyre pressures (psi) for loads:
up to 3 persons full load
Front Rear Front Rear
33 33 35 44
1. Door window defroster vents 8. Stalk for turn signals, headlight
flash, dipped and main beam
2. Side air vents
9. Horn
3. Front passenger airbag 3
10. Instruments
4. Heating, ventilation, air
conditioning system 3 11. Windscreen wiper and wash system,
rear window wash system 3
5. Centre air vents
12. Front fog lights 3
6. Hazard warning flashers
13. Exterior lights
7. Display 3 for time, radio, date
and outside temperature 14. Fog tail light
15. Headlight range adjustment
Vehicle security
Unlocking: Locking:
To unlock driver's door only: Press button e on remote control - or -
Press button c on remote control once turn key in lock on one of the front doors
- or - turn key in driver's door lock towards rear of vehicle, turn it back to
towards front of vehicle, return it back to the vertical position and remove.
the vertical position and remove. To lock with anti-theft locking system 3:
To unlock entire vehicle: Press button e on remote control again
Press button c on remote control twice within 2 seconds of locking - or - with the
within 5 seconds - or - turn key in lock on doors closed, turn key in lock on one of
one of the front doors towards front of the front doors towards rear of vehicle
vehicle twice, turn it back to the vertical again after locking, then turn it back to
position and remove. the vertical position and remove.
TS 1537-A-07
Note: some items described may be optional 3.
16. Bonnet release lever
17. Ignition switch with steering
column lock (not visible)
18. Accelerator pedal
19. Brake pedal
20. Clutch pedal
21. Ashtray 3 or storage compartment
22. Cigarette lighter 3
23. Radio 3 or storage compartment
24. Glove compartment
Engine immobiliser:
z Deactivated when key is in ignition
z Activated when key is removed
Engine can not be started in any other
way so keep spare key in a safe place
Door lock cylinders:
Will free-wheel if forcefully rotated with
an incorrect key.
To reset, turn cylinder until the slot is
vertical using the correct key, then
remove and re-insert key. If cylinder still
free-wheels, turn key through 180º and
repeat the operation.
July 2006
