Creek Audio P43 Operating Instructions

CREEK P43 SPECIFICATION
TOTAL HARMONIC DISTORTION
FREQUENCY RESPONSE
LINE INPUTS
TAPE LOOPS
OUTPUTS
TAPE OUTPUTS
HEADPHONE OUTPUT (When module fitted)
GAIN FROM OUTPUT 2 & 3
GAIN FROM OUTPUT 1
MAXIMUM OUTPUT VOLTAGE PER MODULE
SIGNAL TO NOISE RATIO
SEPARATION
POWER CONSUMPTION
POWER REQUIREMENTS
SIZE
WEIGHT
Creek Audio Ltd reserve the right to change or modify the specification of its products without prior warning.
Creek Audio Ltd
2 Bellevue Road, Friern Barnet, London N11 3ER, England
Tel: 00 44 + (0)181-361 4133 Fax: 00 44 + (0)181-361 4136
E-mail: mcreek@ibm.net Internet: www.creekaudio.co.uk
< 0.005% 20 Hz to 20 kHz @ 1V
10 Hz to 30 kHz -1 dB
4
2
3
x 2
30 mW into 30 Ω Ω
x 1 (0dB)
x 2 (6dB)
4 V at 10 kΩ Ω
100 dB for 1 V output
> 60 dB at 1 kHz
6 W DC (max)
24 V
420 x 60 x 230 mm
16.5" x 2·4" x 9''
3 kg, 6.6 lb
Designed and made in the UK.
Thank you for purchasing the P43 Pre-Amp. You are now in possession of a State of
the Art product. The functions and operation of the P43 are extremely simple.
However, the following notes are provided to explain all aspects of its design and use.
OVERVIEW
The function of the P43 pre-amplifier is to allow the user
to control signals from various sources (Disc, CD,
Tuner, AV and Tape) and vary the amplitude (volume) of
the selected signal to a Power Amplifier, which is
designed to supply higher level signals to loudspeakers.
Therefore, a pre-amplifier should be as flexible as pos-
sible and, in this case, the Creek P43 has a wide range
of standard functions and is designed to be configured
to meet many different requirements.
Future up-grades are possible as it uses a system of
modular construction. Please read the following instruc-
tions carefully.
GETTING STARTED
Unpack the amplifier and keep the packing material
safe for any possible future use. Connect one of your
source components (a CD player for example) into the
sockets on the rear panel marked CD Input, using high
quality phono to phono interconnects. The P43 pre-
amplifier should be connected to a power amplifier, like
Creek
P43
& P43R

Operating Instructions
