Installation Steps
SET RADIO SELECT SWITCH
Alpine
Visteon, Sony
1
1.The radio select rotary switch on the side of the interface must be adjusted to the proper radio
setting before plugging the interface into the vehicle (see page 2 for setting chart).
2. Only one of the two provided radio harnesses will be used. Remove the factory installed radio to determine the correct harness for your
particular vehicle.
3. Make all connections as described in the connection chart on page 1. Vehicles without a factory amplifier: Connect the aftermarket radio's
front and rear speaker wires to the vehicle connector. Vehicles with a factory amplifier: The factory amplifier only accepts two channels
of audio input (left and right). Connect the front outputs of the aftermarket radio to the rear inputs of the vehicle connector. This will allow
navigation voice prompts and Bluetooth calls to be heard. The rear speaker outputs of the aftermarket radio are not used. Fading is not
supported in this application. The factory amplifier's fading is controlled by data communication from the factory radio. Neither the aftermarket
radio or the RP interface have the ability to control the amplifier's fader.
4. Connect the SWC wire according to the chart on page 1 (aftermarket radio MUST support a wired remote input)
5. If you wish to reassign functions to the SWC follow the programming instructions in the next section.
Optional Steering Wheel Control Programming
IMPORTANT! The interface comes pre-programmed for all of the vehicles factory SWC functions and does not require programming
unless you wish to re-assign the SWC functions to different buttons. The SWC can always be restored to default settings by
pressing the program button on the side of the interface once and waiting for the timeout.
Default SWC Button Assignments
Alpine
Volume +
Volume + Volume +
Volume -
Volume -
Source
Source
Track +
Track +
Track -
Track -
Preset +
Preset +
Voice
Mute
Phone
Receive
If you wish to re-assign the SWC functions, the interface must be programmed in the specific order shown in the chart on the next
page. If you come across a function in the chart that your steering wheel does not have, or you do not want to program, press and
release the program button on the side of the interface to skip that function. The LED will flash off and on confirming that you have
successfully skipped that function and are ready to proceed to the next one.
SET RADIO SELECT SWITCH
SET RADIO SELECT SWITCH
Alpine
1
Pacific Accessory Corporation
Pacific Accessory Corporation
Advent,
BOYO, Dual,
Blaupunkt
7
8
JVC
Kenwood
Volume +
Volume -
Volume -
Source
Source
Track +
Track +
Track -
Track -
Preset
Disc/Radio + Band
Mute
Mute
Receive
Answer
Advent,
BOYO, Dual,
Blaupunkt
Visteon, Sony
7
8
| Santa Ana, California 92705 | Ph. 866-931-8021 | support@pac-audio.com
®
©2011 Pacific Accessory Corporation
Radio Replacement & Steering Wheel Control Interface
