Hallmark
H050
Use & Installation Instructions
NOTE: This appliance is fitted with a battery
powered ignition system. Should the ignition
system start to spark slowly - or not at all, the
battery will need replacing. See the section on
battery replacement.
The cooker must be installed in accordance with the regulations in force
and only used in a well ventilated space.
Read these instructions prior to installing or using the cooker and retain
them for future reference.
The data badge is located below the oven door on the plinth panel.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hallmark H050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Creda Hallmark H050

Summary of Contents for Creda Hallmark H050

  • Page 1 Hallmark H050 Use & Installation Instructions NOTE: This appliance is fitted with a battery powered ignition system. Should the ignition system start to spark slowly - or not at all, the battery will need replacing. See the section on battery replacement.
  • Page 2 For more information on our exciting product range ring Creda Answer Centre 08701 546474 Visit us on the NET at http:/www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our Feel browse our product range bubbling away free to to see what’s...

  • Page 3: Table Of Contents

    Contents Introduction For Your Safety Hotplate Grill Oven Oven Cooking Charts The “Slow Cook” Setting Storage Compartment Care and Cleaning / Battery Replacement Something Wrong with your cooker? Installation Instructions Key Contacts Back Cover...

  • Page 4: Introduction

    Introduction To help you make the best use of your cooker, PLEASE READ THIS BOOKLET CAREFULLY. Your new cooker is guaranteed and will give lasting service. The guarantee is only applicable if the cooker has been installed in accordance with the installation instructions. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation.

  • Page 5: For Your Safety

    For Your Safety PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR COOKER. Always Always make sure you understand the controls before using the cooker. Always check all controls on the cooker are turned off after use. Always stand back when opening the oven door to allow heat to disperse.
  • Page 6 For Your Safety Never Never leave children unsupervised where the cooker is installed as all surfaces will be hot during and after its use. Never allow anyone to sit or stand on any part of the cooker. Never store items that children may attempt to reach above the cooker.

  • Page 7: Hotplate

    Hotplate The hotplate has one large high speed burner, two normal simmering burners and one small simmering burner which will accommodate pans between 100mm (4”) and 200mm (8”) diameter. All pans should be positioned centrally over the burners. The pan supports should be fitted on the hotplate such that the indents along one side of each pan support are inner-most.

  • Page 8: Grill

    Grill The grill pan can be pulled out to safety stops for viewing and for turning the food. To remove the pan: pull it forward to the stop, lift it upwards and remove outwards. To Use the Grill 1. Press the ignition button and then push in and turn the grill control knob anti-clockwise to the large flame symbol.

  • Page 9: Oven

    Oven The oven has different heat zones – the thermostat settings refer to the temperature on the middle shelf; above this shelf it is hotter and below it is cooler. Two shelves enable full use of the temperatures inside the oven. Each shelf has a safety stop to prevent if from being pulled out too far when attending to food.
  • Page 10 Oven Anything requiring long slow cooking such as casseroles and rich fruit Cold Start cakes can be put into a cold oven. Satisfactory results can also be obtained Cooking with creamed mixture, rich pastries or yeast mixtures, but for perfection we recommend preheating the oven for about 15 minutes.

  • Page 11: Oven Cooking Charts

    Oven Cooking Chart The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed.

  • Page 12: Oven Cooking Chart

    Oven Cooking Chart Shelf Food Mark Positions Approx. Cooking Time and Comments Cakes, Pastries & Biscuits Small Cakes (16 per tray) 2 trays 1 and 3 17 - 25 mins. 1 tray 18 - 22 mins. Victoria sandwich (2 x 180mm / 7”) 1 and 3 20 - 30 mins Swiss Roll (3 egg quantity)

  • Page 13: The "Slow Cook" Setting

    The ‘Slow Cook’ Setting The ‘Slow Cook’ setting on the oven thermostat is used for slow cooking, keeping food warm and warming plates for short periods. 1. All dishes cooked by the ‘Slow Cook’ setting should be Using the ‘Slow Cook’...

  • Page 14: Storage Compartment

    Storage Compartment Take care as accessible surfaces inside the storage compartment will become hot when the oven is in use. The storage compartment is ideal for storing saucepans, meat pans etc. Do not use it for storing com- bustible materials, flammable liquids or aerosols.

  • Page 15: Care And Cleaning / Battery Replacement

    Care and Cleaning Clean the cooker regularly and wipe up spills soon after they occur to prevent them from becoming burnt on. Never use biological washing powder, caustic cleaners, harsh abrasives, scouring pads, aerosol cleaners or oven chemical cleaners of any kind. To move the cooker forward, open the oven door and with both hands positioned under the roof of the compartment, lift and pull forward.
  • Page 16 Care and Cleaning COOKER FINISH CLEANING METHOD Vitreous Enamel Cloth wrung out in hot soapy water. Stubborn Hotplate, burner caps, stains can be removed with a cream paste, grill pan, grill front panel, grill liquid cleaner or by rubbing with fine steel wool top panel,oven base and rear, soap pads.

  • Page 17: Something Wrong With Your Cooker

    Something Wrong With Your Cooker Before calling a Service Engineer, please check through the following lists. THERE MAY BE NOTHING WRONG. Problem Check Slight odour or small This is normal and should cease after a short period. amount of smoke when grill / oven used first time Oven cooks too fast or too...

  • Page 18: Installation Instructions

    Installation Instructions Prior to installation, ensure that the local distributions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the data badge which is fitted below the oven door on the plinth panel. This appliance is not designed to be connected to a combustion products evacuation device.
  • Page 19 Installation Instructions Technical Data Height 900mm Dimension Width 500mm Depth 600mm (excluding door handles) Gas connection ” BSP female) General Pressure test point Grill injector Gas rate adjustment None Aeration adjustment None Battery 1.5V Alkaline AA Natural Gas BURNER HEAT INPUT INJECTOR HOTPLATE 3.0 kW...
  • Page 20 Installation Instructions The cooker can be close fitted below hotplate level. This requires a minimum distance of 503mm between cupboard units of hotplate height. Cupboards or walls to the side of the cooker must be 125mm away. Wall cupboards above hotplate level must also be 500mm away as shown. Where cupboards or any overhead surfaces are fitted above the cooker allow a clearance of 500mm from the top of the grill to the underside of the overhead surface.
  • Page 21 Installation Instructions Unpack the components from inside the grill and oven: Check that the Unpacking the following parts are present. Cooker Grill pan and grid Pan supports (2) Oven shelves (2) Enamelled discs (4) Battery 1.5V Literature Aluminium burner bodies (4) The cooker must be fitted with a stability device firmly secured to the fabric of the building.
  • Page 22 Installation Instructions Operational After installation, check for gas soundness. The supply pressure can be Checks checked at the grill injector. Access to the injector is by first removing the rear panel at the back of the splashback. Then remove the fastening screw and slide the burner off the injector.

  • Page 24: Key Contacts

    08701 54 64 74 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
