- Page 1 E010E / R010E Installation & User Instructions You must read these instructions prior to using the appliance and retain them for future reference.
- Page 2 For more information on our exciting product range ring Creda Answer Centre 08701 54 64 74 Visit us on the NET at http://www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our Feel browse our product range...
-
Page 3: Table Of Contents
Controls Oven Timer Operation Solarplus Grill Grill Pan and Handle Grilling Procedure Grill Chart Using the Oven for Fan Cooking Using the Oven for Other Functions Temperature Conversion Chart Oven Temperature Charts Cooking Results Not Satisfactory? Care and Cleaning Installation... -
Page 4: Introduction
It is suggested that any pets be removed from the room until the smell has ceased. This odour is due to temporary finish on oven liners and elements and also any moisture absorbed by the insulation. -
Page 5: Safety Information
Always make sure all controls are turned off when you have finished cooking and when not in use. Always stand back when opening an oven door to allow any build up of steam or heat to disperse. Always use dry, good quality oven gloves when removing items from the oven/grill. - Page 6 Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot. Never heat up unopened food containers as pressure can build up causing the container to burst.
-
Page 7: Features
Oven Pilot Light Oven Temperature & Grill Selection Control Grill Control 24 Hour Digital Electronic Clock and Oven Timer Solarplus Grill Element Easy Glide™ Shelf Oven Fan Door Switch - Credaclean liners (E010E) - Vitreous enamel liners (R010E) Oven Door... -
Page 8: Controls
& Grill Control A &B Note: Resistance will be felt when turning from fan oven operation to full grill / half grill positions Cooling Fan A gentle flow of air will be blown below the control panel when the oven or grill is switched on. -
Page 9: Oven Timer Operation
Select foods which will take the same time to cook and require approximately the same temperature. Set the oven timer so that the food has just finished or about to finish cooking on your return to the oven. This will ensure the food has not cooled down and does not require reheating before serving. -
Page 10: Know Your Timer
“Manual” button twice – The “Auto” symbol will go out). Note: If at any time the display shows a ‘KEY’ symbol, it is likely that the timer has been set incorrectly. OVEN COOKING IS NOT POSSIBLE. The ‘KEY’ symbol can be deleted and the cooker returned to manual operation by: Simultaneously pressing the Minute Minder and the Cook Period buttons for a period of approximately 8 seconds. -
Page 11: Setting The Minute Minder
Electronic Clock and Automatic Oven Timer Operation SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and Auto symbol will be Step 4 Press &... -
Page 12: Auto Cooking Programmes
(b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically. - Page 13 Check that the correct time of day is set, if not follow instructions for setting the time of day. Step 2 Place food onto the correct shelf position in the oven and close the oven door(s). Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven function.
- Page 14 (d) Press & release the “Manual” button. (e) Start the sequence again. 5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply to the oven has been interrupted. Reset the timer to the correct time of day.
-
Page 15: Solarplus Grill
Solarplus Grill Your cooker is not fitted with a conventional grill. Creda have developed a Solarplus high speed grill which is designed to reduce your grilling times. It is quicker because it takes less time to warm up from cold. Conventional grills require 5 minutes pre-heat before food is placed beneath them, but for normal grilling the Solarplus grill can be used directly from cold without any pre-heat. -
Page 16: Grill Pan And Handle
If a detachable handle is required, do not replace the screw and washers. Note: If a fixed handle is required, the grill pan is unable to be kept in the main oven with the door closed. Grill Pan Food Grid and Anti-Splash Tray... -
Page 17: Grilling Procedure
When using the grill, a gentle flow of air will be detected coming from beneath the control panel. Step 4 After use, turn both controls A & B to their off ( ) position and close the oven door. Door Position for Grilling Note: Do not grill with the oven door closed. -
Page 18: Grill Chart
No. 2 = Low No. 1 = Very Gentle Heat Easy Glide™ Setting required Shelf Position from for cooking Pre- base of oven heat 5 or 6 1 min. 6 for 5-10 mins None 5 or 6 reduced to 5... -
Page 19: Using The Oven For Fan Cooking
Food or utensils should never be placed directly on the floor of the oven for cooking as air circulation is restricted. DO NOT allow young children near to the appliance when the oven is in use as the surfaces get extremely hot. - Page 20 Step 1 Ensure oven timer is set to manual. Ensure that the oven shelf is in the correct position. Place food centrally on the shelf ensuring the oven door is fully closed. Step 2 Turn knob (A) clockwise and select the required cooking temperature .
-
Page 21: Using The Oven For Other Functions
Extra care should be taken when warming bone china, as it may be damaged in a hot oven. DO NOT place food or plates directly on the oven floor as this could damage both the oven lining and the plates which are being warmed. -
Page 22: Temperature Conversion Chart
Temperature Conversion Chart Mark Main Conventional Oven – – Main Oven... -
Page 23: Oven Temperature Chart - Meat
Beef Rare 60 Medium 70 Fan Oven Cooking Note: Up to three shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Temperature heat... -
Page 24: Oven Temperature Chart - Baking
10 this chart refer to cakes made with block margarine or butter only. Fan Oven Cooking Note: Up to three shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre-... -
Page 25: Cooking Results Not Satisfactory
Remember when using a food mixer or processor not to over-cream soft margarine. Refer to the cooking times and temperatures given in the Oven Temperature Charts provided, however, it may be necessary to increase or decrease temperatures by 10˚C to suit personal taste. -
Page 26: Care And Cleaning
Care and Cleaning Warning: Before cleaning, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. 1. “CREDACLEAN” OVEN LINERS (E010E) MAIN OVEN SIDE LINERS AND REAR PANEL 2. VITREOUS ENAMEL OVEN LINERS (R010E) (a) How "Credaclean"... -
Page 27: Cleaning The Oven
MAIN OVEN BASE (a) Base of Main Oven. Wipe out the oven with a damp soapy cloth. For more stubborn stains on the base of the oven use a well soaped fine steel wool soap pad. GRILL/ (b) Grill/Meat Pan & Oven Shelves. - Page 28 Warning: Before removing lamp lens, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. Open the oven door and remove the oven shelves. Using a thick cloth, grip the lamp lens, unscrew anti- clockwise and remove the lens.
-
Page 29: Cleaning The Doors
Refit the door inner glass as follows. NOTE: The inner door glass has a special reflective coating on one side. Replace the door inner glass so that the statement: “IMPORTANT THIS FACE TOWARDS THE OVEN” can be read from the inner side of the door. -
Page 30: Installation
Installation Instructions Important This equipment is designed specifically for domestic purposes and Creda Limited cannot accept responsibility if used in any other type of installation. All Creda oven units are suitable for installation under Creda hob units. This appliance must not be installed over any appliance that generates heat. -
Page 31: Electrical Installation
Fig. 1. (e) If an oven unit is installed adjacent to a tall cabinet, steam escaping from the oven when the door is opened could condense on, and perhaps stain the adjacent surface. -
Page 32: Final Installation
Where a hob is fitted adjacent to or above an oven a 30 amp or 45 amp double pole switch with a minimum contact clearance of 3mm should be used to feed both units via separate suitably rated cables. -
Page 33: Installation Instructions
51 x 457mm min area 50mm Fig. 1 Oven 50mm Tall Cabinet When fitting a hob above an oven always use these installation instructions in conjunction with the hob instructions. Use 2.5mm High Temp Cable. Refer to Electrical Installation. Fig. 3... - Page 34 Installation Instructions Fig. 4 Double Pole Control Switch Cable if Hotplate fitted Conduit Box Cable if hob fitted adjacent to oven Cable to Oven Refer to Electrical Installation Fig. 5 Single Oven in tall Cabinet 585mm max 578mm if cooker...
-
Page 35: Something Wrong
(a) Check If you find :- Display is blank. Then it is likely that there is no electricity supply to your oven. Check: (i) That the main cooker wall switch is turned on. (ii) Check other appliances to see if you have a power cut. -
Page 36: Repair Service
Genuine Parts & Accessories For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
