User Guide
KVM series2-1611
Keyboard/Video/Mouse Switch
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TomTom Navigator 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu Siemens Computers TomTom Navigator 2

Summary of Contents for Fujitsu Siemens Computers TomTom Navigator 2

  • Page 1 User Guide KVM series2-1611 Keyboard/Video/Mouse Switch English...
  • Page 3 KVM series2-1611 Installer/User Guide Edition October 2005...

  • Page 4: Copyright And Trademarks

    DIN EN ISO 9001:2000. Copyright and Trademarks Copyright © 2005 Fujitsu Siemens Computers GmbH. All rights reserved. Delivery subject to availability; right of technical modifications reserved. All hardware and software names used are trademarks of their respective manufacturers.

  • Page 5: Table Of Contents

    Adding a KVM switch ........
  • Page 6 Setting Up the KVM s2-1611/Client System....13 Operations..........15 Controlling Your System at the Analog Port .
  • Page 7 4.4.6.3 Password protecting your console ......27 4.4.6.4 Logging in to your console ....... . . 28 4.4.6.5 Removing password protection from your console: .
  • Page 8 4.10.2.4 Exit ........... 39 Appendices .

  • Page 9: Preface

    KVM s2-1611 switch. The KVM s2-1611 consists of a rack mountable keyboard, video and mouse (KVM) switch configurable for analog or digital connectivity. Each KVM s2-1611 has 16 Fujitsu Siemens Rack Interface (RI) ports for connecting devices and oper- ates over standard LAN connections.

  • Page 10: Summary Of Contents

    Throughout the documentation and KVM s2-Client user interface, you will see the word “appliance” used generically to describe the KVM s2-1611 switch. Summary of contents Safety notes It is essential to read the following “Safety notes” chapter before starting to work with the KVM s2-1611.

  • Page 11: Safety Notes

    Safety notes This chapter provides radio frequency and safety information for your appliance. Radio frequency information United States radio frequency information Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 12: Precautions And Rack Mount Safety

    Precautions and rack mount safety Precautions and rack mount safety Avoiding potential video and/or keyboard problems when using the KVM s2-1611 • If the building has 3-phase AC power, ensure that the computer and monitor are on the same phase. For best results, they should be on the same circuit.

  • Page 13: Kvm Series2-1611

    KVM series2-1611 Quick Installation Guide 3.1.1.2 Additional items needed • One KVM s2-Adapter per attached server or switch 3.1.2 Setting up your network The KVM s2-1611 system uses IP addresses to uniquely identify the appliances and the computers running Client software. The KVM s2-1611 appliance supports both BootP (a subset of DHCP) and static IP addressing.

  • Page 14: Rack Mounting Your Appliance

    Mount the switch assembly to the rack cabinet by matching the holes in the “short side” of each bracket to an appropriate set of matching holes on your rack cabinet.

  • Page 15: Kvm Series2-1611 Hardware

    KVM series2-1611 KVM series2-1611 hardware The following table lists the port and connection information for your appliance. Server Ports Number Types Connectors Sync Types Plug and Play Video Resolution Configuration Port Number Type Connector Network Connection Number Type Connector Analog Port Number Type Connectors...

  • Page 16: Power Ratings

    Power, Dimensions and Standards 3.2.1 Power ratings Heat Dissipation Airflow Power Consumption AC-input power AC-input voltage rating AC-input voltage rating AC-input current rating AC-input cable AC-frequency Table 2: KVM s2-1611 Power Ratings 3.2.2 Dimensions and environmental conditions Dimensions (H x W x D) Weight Environmental Temperature...

  • Page 17: Installing The Kvm Series2-1611

    KVM series2-1611 Installing the KVM series2-1611 Figure 2 illustrates one possible configuration for your KVM s2-1611 appliance. Follow the detailed set of procedures following Figure 2 to successfully install your appliance. Network Configuration Port for updating firmware Power Cord Local Analog User Figure 2: Basic KVM s2-1611 Configuration Reducing the risk of electric shock or damage to your equipment...

  • Page 18: Installing The Kvm Series2-1611 Hardware

    Installing/Configuring the KVM s2-1611 3.3.1 Installing the KVM series2-1611 hardware Connect a terminal or PC running terminal emulation software (such as HyperTerminal) to the configuration port on the back panel of the appliance using a RS232 DB9 null modem cable. The terminal should be set to 9600 baud, 8 bits, 1 stop bit, no parity and no flow control.

  • Page 19: Adjusting The Mouse Acceleration

    KVM series2-1611 you enter your selection, you will be returned to the Network Configuration menu. Select option 2 and specify if you are using a static or BootP IP address. Use a static IP address for ease of configuration. If you are using a BootP address, please configure your BootP server to provide an IP address to the appliance, skip step 4 and continue to the next procedure.

  • Page 20: Adding A Kvm Switch

    24 servers. KVM s2-Adapter PS/2, USB and Sun cables are available Local Analog User Server 1 Figure 4: KVM s2-1611 Configuration with a Cascaded KVM Switch Cascaded KVM Switch KVM s2-Adapter Server 1 KVM series2-1611 KVM s2-1611...

  • Page 21: Connecting/Turning On Your Kvm S2-1611

    KVM series2-1611 Mount the KVM switch into your rack cabinet. Locate a length of CAT 5 cabling to connect your appliance to the KVM s2-Adapter for your switch. Attach one end of the CAT 5 cabling to the RJ45 connector on the KVM s2- Adapter.

  • Page 22: Setting Up The System

    Setting up the System KVM series2-1611 software. See the KVM series2-1611 Quick Installation Guide for an overview of the hardware and software installation procedure. 590-332-501E...

  • Page 23: Operations

    The Port column indicates the RI port to which a server is connected. If you con- nect a legacy KVM switch to the appliance, the port numbering displays the RI port first, then the switch port to which the server is connected. For example, in Figure 5, servers 06-03 and 01-02 are connected to switches.

  • Page 24: Viewing The Status Of Your Appliance

    Selecting servers You can also press the Control key twice within one second to launch OSCAR. You can use this key sequence in any place you see Print Screen throughout this installer/user guide. 4.2.2 Viewing the status of your appliance The status of the servers in your system is indicated in the right columns of the Main dialog box.

  • Page 25: Soft Switching

    Soft switching is the ability to switch servers using a hot key sequence. You can soft switch to a server by pressing Print Screen and then typing the first few char- acters of its name or number. If you have set a Screen Delay Time and you press the key sequences before that time has elapsed, OSCAR will not display.
  • Page 26 Left and Right Arrow keys to move the cursor. Press Enter again to quit the edit mode. Completes a switch in the Main dialog box and exits OSCAR. Toggles back to previous selection. Immediately disengages user from a server;...

  • Page 27: Configuring Oscar

    Set up a custom scan pattern for up to 16 servers. Set passwords to restrict server access. Enable the screen saver. Identify the appropriate number of ports on an attached cascade switch. Identify servers by unique names.

  • Page 28: Assigning Server Names

    Accessing the Setup menu Figure 6: Setup Dialog Box 4.4.2 Assigning server names Use the Names dialog box to identify individual servers by name rather than by port number. The Names list is always sorted by port order. Names are stored in the KVM s2-Adapter, so even if you move the cable/server to another RI port, the name and configuration will be recognized by the appliance.

  • Page 29: Assigning Names To Servers

    4.4.3 Assigning device types While the appliance automatically discovers cascade switches attached to your unit, you will need to specify the number of ports on the cascade switch through the Devices dialog box. The appliance recognizes KVM switches. You will see an Sw-8 or Sw-24 appear in the Type category.

  • Page 30: Accessing The Devices Dialog Box

    For ex- ample, if the switch is connected to RI port 6, the switch port would be listed as 06 and each server under it would be numbered sequentially 06-01, 06-02 and so on.

  • Page 31: Changing The Display Behavior

    Operations Figure 10: Device Modify Dialog Box Choose the number of ports supported by your switch and click OK. This appliance does not support 24 port switches at this time. Repeat steps 1–3 for each port that needs a device type assigned.

  • Page 32: Choosing The Default Display Order Of Servers

    Print Screen. Entering Ø will instantly launch OSCAR with no delay. Click OK. Setting a Screen Delay Time allows you to complete a soft switch without OSCAR displaying. To perform a soft switch, see Soft switching in this chapter. 4.4.5 Controlling the status flag The status flag displays on your desktop and shows the name or EID number of the selected server or the status of the selected port.

  • Page 33: Accessing The Flag Dialog Box

    Operations OSCAR Flag Table 8: OSCAR Status Flags 4.4.5.1 Accessing the Flag dialog box Press Print Screen . The Main dialog box will appear. Click Setup - Flag. The Flag dialog box appears. Figure 12: Flag Dialog Box 4.4.5.2 Determining how the status flag is displayed Select Name or EID to determine what information will be displayed.

  • Page 34: Setting Console Security

    Seting console security To position the status flag on the desktop: Click Set Position to gain access to the Position Flag screen. Left-click on the title bar and drag to the desired location. Right-click to return to the Flag dialog box. Figure 13: Position Flag Changes made to the flag position are not saved until you click OK in the Flag dialog box.

  • Page 35: Setting Or Changing The Password

    In the Repeat box, type the password again and press Enter . Click OK to change only your password, and then close the dialog box. If you should lose or forget your password, you must return your switch. See theTechnical Support section for contact information.

  • Page 36: Logging In To Your Console

    Enabling/exiting Screen saver mode then returns you to the Security dialog box. Click OK. 4.4.6.4 Logging in to your console Press any key or move the mouse. The Password dialog box appears. Type your password, then click OK. The Main dialog box appears if the password was entered properly. 4.4.6.5 Removing password protection from your console: From the Main dialog box, click Setup - Security;...

  • Page 37: Exiting The Screen Saver Mode

    Operations Activation of the screen saver mode disconnects the user from a server; no server is selected. The status flag displays Free. 4.4.6.7 Exiting the screen saver mode Press any key or move your mouse. The Main dialog box appears and any previ- ous server connection will be restored.

  • Page 38: Resetting Your Keyboard And Mouse

    Resetting Your Keyboard/Mouse Figure 15: User Status Dialog Box Figure 16: Disconnect Dialog Box Click OK to disconnect the user and return to the User Status dialog box. -or- Click X or press Escape to exit the dialog box without disconnecting a user. If the User Status list has changed since it was last displayed, the mouse cursor will turn into an hourglass as the list is automatically updated.
  • Page 39 Operations Press Print Screen . The Main dialog box will appear. Click Commands - Display Versions. The Version dialog box appears. The top half of the box lists the subsystem versions in the appliance. Figure 17: Version Dialog Box Click Digital to view the Digitizer unit firmware versions. The Digital Version dialog box appears.

  • Page 40: Scanning Your System

    Scanning Your System Figure 19: KVM s2-Adapter Selection Dialog Box Select a KVM s2-Adapter to view and click the Version button. The KVM s2- Adapter Version dialog box appears. For more information on loading firm- ware, see Chapter 5. Figure 20: KVM s2-Adapter Version Dialog Box Click X to close the Version dialog box.

  • Page 41: Adding Servers To The Scan List

    Operations Scanning is only available to the analog user. 4.8.1 Adding servers to the scan list Press Print Screen . The Main dialog box will appear. Click Setup - Scan. The Scan dialog box appears. Figure 21: Scan Dialog Box Determine the order within the list to add the server.

  • Page 42: Removing A Server From The Scan List

    Starting the scan mode Press Alt+End to move the cursor to the last server in the list. In the Sec column, type the number of seconds (from 3 to 255) of desired time before the scan moves to the next server in the sequence. Move the cursor to the next line or press the Down Arrow and repeat steps 2-5 for each of the remaining servers to be included in the scan pattern.

  • Page 43: Cancelling Scan Mode

    Operations 4.8.4 Cancelling scan mode Select a server if OSCAR is open. -or- Move the mouse or press any key on the keyboard if OSCAR is not open. Scanning will stop at the currently selected server. -or- Press Print Screen . The Main dialog box will appear. Click Commands.

  • Page 44: Broadcasting To Selected Servers

    Terminal Operations When broadcasting mouse movements, all systems must have identical mouse drivers, desktops (such as identically placed icons) and video resolu- tions for the mouse to work accurately. In addition, the mouse must be in ex- actly the same place on all screens. Because these conditions are extremely difficult to achieve, broadcasting mouse movements to multiple systems may have unpredictable results.

  • Page 45: Accessing The Terminal Menu

    Operations Figure 24: Network Configuration Menu 4.10.1.1 Accessing the Terminal menu Connect a terminal or PC running terminal emulation software (such as HyperTerminal) to the configuration port on the back panel of the KVM s2- 1611 using a RS232 DB9 null modem cable. The terminal should be set to 9600 baud, 8 bits, 1 stop bit, no parity and no flow control.

  • Page 46: Activating Security

    Exit be accessed without first entering a password. 4.10.2.3.1 Activating security Select the Set/Change Password menu option. You will be prompted with the option to continue. Enter a Y . Type a password for this KVM s2-1611 and press Enter. This password must be a minimum of 5 characters and can be up to a maximum of 12 characters (10 are visible).

  • Page 47: Appendices

    Save the FLASH upgrade file to the appropriate directory on the TFTP server. Once this is complete, the following steps will upload the new FLASH file. When upgrading your switch firmware, ensure that the keyboard coun- try codes with your system correspond with the firmware loaded in your switch.

  • Page 48: Upgrading The Kvm S2-Adapter Firmware

    Do not cycle power to the server or disconnect the KVM s2-Adapter during this process. A loss of power will render the KVM s2-Adapter inoperable and require the switch to be returned to the factory for repair. 5.1.2.1 Simultaneously upgrading multiple KVM s2-Adapters Press Print Screen .

  • Page 49: Upgrading Firmware

    Appendices Figure 25: KVM s2-Adapter Status Dialog Box Click one or more types of adapters to upgrade. Click Upgrade. Figure 26: KVM s2-Adapter Upgrade Dialog Box The KVM s2-Adapter Upgrade dialog box appears. Click OK to initiate the upgrade and return to the KVM s2-Adapter Status dialog box. 5.1.2.2 Upgrading KVM s2-Adapter firmware individually Press Print Screen .
  • Page 50 Upgrading firmware individually Figure 27: Version Dialog Box Click KVMS2 to view individual cable version information. Figure 28: KVM s2-Adapter Selection Dialog Box Select a KVM s2-Adapter to upgrade and click the Version button. The KVM s2-Adapter Version dialog box appears. Appendices 590-332-501E...

  • Page 51: Sun Advanced Key Emulation

    Appendices Figure 29: KVM s2-Adapter Version Dialog Box Click the Load Firmware button. The Load dialog box appears. Figure 30: KVM s2-Adapter Load Dialog Box Click OK to initiate the upgrade and return to the Status dialog box. During an upgrade, the KVM s2-Adapter status indicator in the Main dialog box will be yellow.
  • Page 52 Sun Advanced Key Emulation Lock key. The Scroll Lock LED blinks. Use the indicated key in the following table as you would use the advanced keys on a Sun keyboard. Sun Key (US) Compose Compose Power Open Help Props Front Stop Again Undo...

  • Page 53: Technical Support

    Appendices Technical Support Our Technical Support staff is ready to assist you with any installation or operat- ing issues you encounter with your Fujitsu Siemens product. If an issue should develop, follow the steps below for the fastest possible service: Check the pertinent section of this manual to see if the issue can be resolved by following the procedures outlined.
