control
2
Initial Browser Setup
BX600 Digital KVM Switch
Keyboard/Video/Mouse Switch
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX600 and is the answer not in the manual?

Questions and answers

Related Manuals for Fujitsu Siemens Computers BX600

Summary of Contents for Fujitsu Siemens Computers BX600

  • Page 1 control Initial Browser Setup BX600 Digital KVM Switch Keyboard/Video/Mouse Switch English...

  • Page 2: Usa Notification

    USA Notification Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 Initial Browser Setup for the BX600...

  • Page 4: Copyright And Trademarks

    DIN EN ISO 9001:2000. Copyright and Trademarks Copyright © 2006 Fujitsu Siemens Computers GmbH. All rights reserved. Delivery subject to availability; right of technical modifications reserved.

  • Page 5: Table Of Contents

    Initial Browser Setup of the BX600 Installing the JRE for Windows Clients ........1 Installing the JRE for Linux Clients ..........2 DKVM network configuration ............2 Default IP address ..............2 IP address configuration ............3 Network port settings ..............3 Internet Browser Security Settings..........

  • Page 7: Initial Browser Setup Of The Bx600

    The JRE is a software bundle from Sun Microsystems that allows the client OS to run a Java application. A released Java Runtime Environment version is available on the Fujitsu Siemens Computers ServerStart CD/DVD and the DKVM Support CD...

  • Page 8: Installing The Jre For Linux Clients

    Installing the JRE for Linux Clients Initial Browser Setup of the BX600 2 Installing the JRE for Linux Clients Go to http://www.java.com/en/download/linux_manual.jsp There are two types of installation packages: • Linux RPM package • Linux self extracting binary file. To Install the JRE for Linux clients: Download the package that best suits your needs.

  • Page 9: Ip Address Configuration

    Initial Browser Setup of the BX600 DKVM network configuration Figure 1: KVM Configuration Page 3.2 IP address configuration Once you have access to the KVM Configuration page, if you want to use a static IP address, you can set the IP address of the KVM to any valid IP address you choose as long as that address is in the same subnet as that of the MMB.

  • Page 10: Internet Browser Security Settings

    DKVM network configuration Initial Browser Setup of the BX600 Virtual Media Port : 50002 Video Port : 50003 3.4 Internet Browser Security Settings To configure the IE6 browser with recommended security settings: Click on the Tools menu of the IE6 menu. Click on Internet Options of the Tools menu.
  • Page 11 Initial Browser Setup of the BX600 DKVM network configuration the SSL certificate to identify itself unless it is in possession of the corresponding private key. For a web browser to believe the SSL certificate is legitimate, that certificate must be signed by a trusted certificate authority known in advance to the browser.
  • Page 12 DKVM network configuration Initial Browser Setup of the BX600 Figure 4: Internet Explorer 6 Certificate Import Wizard Start Dialog Click the Next button. Figure 5: Internet Explorer 6 Certificate Import Wizard Certificate Store Dialog Click the Next button.
  • Page 13 Initial Browser Setup of the BX600 DKVM network configuration Figure 6: Internet Explorer 6 Certificate Import Wizard Complete Dialog Click the Finish button to complete the importation of the trusted certificate. You should see a warning similar to the following: Figure 7: Internet Explorer 6 Security Warning Click Yes to complete the installation of the certificate.
  • Page 14 DKVM network configuration Initial Browser Setup of the BX600 Figure 8: Internet Explorer 6 Internet Options Content Dialog Click the Certificates button. The Certificates Dialog appears. Figure 9: Internet Explorer 6 Certificates Dialog Click the Import button. The Certificate Import Wizard appears.
  • Page 15 Initial Browser Setup of the BX600 DKVM network configuration Figure 10: Internet Explorer 6 Certificate Import Wizard Click Next. Browse to the location of the trusted certificate file and click on the name of the cer- tificate or type-in the fully specified path to the certificate filename. Figure 11: Internet Explorer 6 Certificate Import Wizard Browser Click the Next button.
  • Page 16 DKVM network configuration Initial Browser Setup of the BX600 Figure 12: Internet Explorer 6 Certificate Import Wizard Store Dialog. Click in the empty circle next to the label Place all certificates in the following store. Click the Browse button and select Trusted Root Certification Authorities Click the Next button to reveal the following dialog box.

  • Page 17: Avoiding Security Alerts When Launching The Viewer

    Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 14: Internet Explorer 6 Security Warning Click Yes to complete the installation of the certificate 4 Avoiding Security Alerts when Launching the Viewer The dKVM embedded web server is also an SSL enabled web server. When you launch the console viewer the MMB web server presents an SSL certificate to the dKVM.
  • Page 18 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Click the View Certificate button. You will see the following: Figure 16: Internet Explorer 6 Certificate Information Dialog Click on Install Certificate and follow the instructions of the Certificate Import Wizard.
  • Page 19 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 18: Internet Explorer 6 Certificate Store Page of Certificate Wizard Click the Next button. Figure 19: Internet Explorer 6 Completing the Certificate Import Wizard Click on Finish. You should see a warning similar to the following:...
  • Page 20 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 20: Internet Explorer 6 Security Warning Dialog Click Yes to complete the installation of the certificate. If the last warning on the Security Alert dialog box is: The name on the security certificate is invalid or does not match the name of the site.
  • Page 21 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Now if you specify the MMB FQDN when accessing the MMB via the Internet Explorer browser, the “Security Alerts” dialog box should not be displayed. If you don’t have a third party certificate: Confirm the alert by clicking the Yes button.
  • Page 22 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 23: Java Warning - Security Dialog Click the Run button to launch the Viewer Console Application. The next window displayed should be a Remote Viewer Console Application similar to the one shown below.

  • Page 23: Mozilla Firefox 1.5 On Red Hat 4

    Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer 4.2 Mozilla Firefox 1.5 on Red Hat 4 Before getting started make sure the Firefox browser is configured to interface with SSL and is configured to automatically select the security certificate to be presented to a requesting web site.
  • Page 24 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 26: Firefox Certificate Manager Dialog Click the Import button to import the RemoteView CA Cert.der certificate. Figure 27: Finding the RemoteView CA Cert.der Certificate File Click the folder icon to locate the directory containing the RemoteView CA Cert.der file.
  • Page 25 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 28: Opening the RemoteView CA Cert.der Certificate File Click the Open button. The Downloading Certificate dialog box will appear: Figure 29: The Downloading Certificate Dialog Click the checkbox labeled Trust this CA to identify web sites. Click OK.
  • Page 26 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 30: Confirming the Certificate Use the scrollbar to find the certificate and confirm that it has been imported into the Firefox browser. You can also manage the past certificates from web sites that have been accepted by the browser by clicking the Web Sites tab and then clicking the View button.
  • Page 27 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer If the certificate is not signed by a trusted certificate authority that the browser recognizes, then the browser may present the following Website Certified by an Unknown Authority dialog: Figure 32: Firefox Certified by Unknown Authority Dialog Click on Examine Certificate to find out why the certificate is not recognized.
  • Page 28 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 34: Accepting Firefox Website Certificate Click OK. Thereafter Security Alert dialogs should stop appearing when the browser connects to the MMB web server. The first time you try to launch the console viewer you will be prompted by the following dialog.

  • Page 29: Mozilla 1.7.12 On Red Hat 4

    Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer The next window displayed should be a Remote Viewer Console Application similar to the one shown below. Figure 36: Firefox dKVM Viewer Window 4.3 Mozilla 1.7.12 on Red Hat 4 Before getting started make sure the Mozilla browser is configured to interface with SSL and is configured to automatically select the security certificate to be presented to a requesting web site.
  • Page 30 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 37: Red Hat Mozilla Preferences Dialog Click the Manage Cetificates button. The Certificate Manager dialog opens. Figure 38: Red Hat Mozilla Certificate Manager Dialog Click the Import button to import the RemoteView CA.Cert.der certificate.
  • Page 31 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 39: Red Hat Mozilla Certificate Selection Dialog Use the folder icon to locate the directory containing the RemoteView CA Cert.der file. Figure 40: Red Hat Mozilla Certificate Import Dialog Click on the certificate name or type it into the File name field.
  • Page 32 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 41: Red Hat Mozilla Downloading Certificate Dialog Click the Trust this CA to identify web sites checkbox. Click OK. The Certificate Manager dialog reappears. Figure 42: Confirming the Certificate Use the scrollbar to find the certificate and confirm that it has been imported to the Mozilla browser.
  • Page 33 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 43: Red Hat Mozilla Certified by Unknown Authority Dialog Click on Examine Certificate to find out why the certificate is not recognized. Figure 44: Red Hat Mozilla Domain Name Mismatch Dialog Click on View Certificate to find all of the certificates involved in the SSL handshake.
  • Page 34 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 45: Accepting Red Hat Mozilla Website Certificate Thereafter the Security Alert dialogs should stop being displayed when the browser connects to the MMB web server. The first time you try to launch the console viewer you will be prompted by the following dialog.

  • Page 35: Mozilla 1.7.5 On Suse9

    Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 47: Red Hat Mozilla dKVM Viewer Window 4.4 Mozilla 1.7.5 on SUSE9 Before getting started make sure the Mozilla browser is configured to interface with SSL and is configured to automatically select the security certificate to be presented to a requesting web site.
  • Page 36 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 48: Suse Mozilla Certificate Preferences Dialog Click the Manage Certificates button. The Certificate Manager will appear. Figure 49: SUSE Mozilla Certificate Manager Dialog Click the Import button to import the RemoteView CA Cert.der certificate.
  • Page 37 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 50: SUSE Mozilla Certificate Selection Dialog Use the folder icon to locate the directory containing the RemoteView CA Cert.der file. Figure 51: SUSE Mozilla Certificate Import Dialog Click on the certificate name or type it into the File name field.
  • Page 38 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 52: SUSE Mozilla Downloading Certificate Dialog Click the Trust this CA to identify web sites checkbox. Click OK. The Certificate Manager dialog will reappear. Figure 53: Confirming the Certificate Use the scrollbar to find the certificate and confirm that it has been imported to the Mozilla browser.
  • Page 39 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 54: SUSE Mozilla Certified by Unknown Authority Dialog Click the Examine Certificate button. If the common name of that certificate does not match Domain name (or the IP address) for the dKVM, then a Security Error: Domain Name Mismatch dialog box is displayed.
  • Page 40 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 56: Accepting SUSE Mozilla Website Certificate The Security Alert dialogs should no longer be displayed when the browser connects to the MMB web server. The first time you try to launch the console viewer you will be prompted by the following dialog.
  • Page 41 Initial Browser Setup of the BX600 Avoiding Security Alerts when Launching the Viewer Figure 58: SUSE Mozilla Download Manager Next the Java viewer .jar file will begin its one-time initial download. Figure 59: SUSE Mozilla Java Web Start Indicator Finally, the viewer application presents its signed certificate for verification and asks you for permission to run the application.
  • Page 42 Avoiding Security Alerts when Launching the Viewer Initial Browser Setup of the BX600 Figure 60: SUSE Mozilla Java Security Dialog Click the Run button to launch a Viewer Console Session similar to the display below. Figure 61: SUSE Mozilla dKVM Viewer Window...

  • Page 43: Finding The Dkvm Ip-Address When Using Dhcp

    Initial Browser Setup of the BX600 Finding the dKVM IP-address when using DHCP 5 Finding the dKVM IP-address when using DHCP The dKVM IP address is displayed on the “KVM Configuration” web page. To get there, do the following: Point your browser to the MMB IP Address to get the primary Blade Server System Information web page shown below.

  • Page 44: Integrating The Dkvm Ip Address With Https Setting

    Finding the dKVM IP-address when using DHCP Initial Browser Setup of the BX600 Figure 63: KVM Configuration Web Page You should see the assigned KVM IP Address displayed on this page. 5.1 Integrating the DKVM IP address with https setting There is no need to integrate the DKVM IP address with the https setting.

  • Page 45: Resolutions Supported By The Dkvm Console Viewer

    Initial Browser Setup of the BX600 Finding the dKVM IP-address when using DHCP 5.2 Resolutions supported by the DKVM Console Viewer Analog video detected and provided to the remote console viewer will be in the range of 640 x 480 to 1024 x 768. The video resolutions supported will be as follows: Resolution Refresh Rate Horizontal Freq...
  • Page 46 Finding the dKVM IP-address when using DHCP Initial Browser Setup of the BX600...
