Autostart AS-6320 FM Wiring Manual

Programming Options

Mode 1
*indicates default setting
Function 1 – Ignition-Controlled Door locks
OPTION 1* Ignition Lock disabled
OPTION 2 Ignition lock enabled
OPTION 3 Ignition unlock only
OPTION 4 Ignition lock only
Function 2 – Secure Lock
OPTION 1* Secure Lock disabled (1-sec. disarm pulse.)
OPTION 2 Secure Lock enabled in smart mode.
OPTION 3 Secure Lock disabled (0.5 Sec disarm pulse)
OPTION 4 Secure Lock enabled in normal mode.
OPTION 5 Standard secure lock enabled (no rearm pulse when
ignition is on)
Function 3 – Door Locks Pulse Timing
OPTION 1* 7/10 second lock/unlock pulses.
OPTION 2 4 seconds lock/unlock pulses.
OPTION 3 7/10 seconds lock pulse and two 1/4 second unlock
pulses.
OPTION 4 1/10 second lock/unlock pulses.
Function 4 – AUX 3 Programming
OPTION 1* Constant while the
OPTION 2 1-sec. Trunk 1 output when
for 3 sec. while Ignition is OFF and data output.
OPTION 3 with disarm/rearm (shock is ignored while
TRUNK
zone 3 is opened.)
OPTION 4 1 sec output ON/OFF
TRUNK
Function 5 – AUX 2 Programming
OPTION 1* Priority Door access (Pressing
triggers AUX 2)
Car Finder enabled (pressing
triggers Car Finder)
LOCK
The Driver's Door unlocks upon the 1st
pressing of the
All Doors unlock on any subsequent pressing
of the
UNLOCK
OPTION 2 Toggle ON/OFF with a 30-second timeout (press
and then
SHIFT LOCK
Mode 3
*indicates default setting
Function 1 – Siren Chirps
OPTION 1 Warning Chirps only; Lock Confirmation if the Lock
button is press 2nd time.
OPTION 2* Chirps enabled.
OPTION 3 Chirps enabled with Open-Zone notification.
(Siren warning 10 sec. after arming if a door is left
open)
(Also used for vehicles with Dome Light Delay).
OPTION 4 Chirps disabled and Lock confirmation if the Lock
button is press 2nd time.
Function 2 – Passive Or Active Arming
OPTION 1 Active Arming
OPTION 2* Passive Arming (30 sec.)
OPTION 3 Passive Arming (30 sec.) / no TWO-STAGE
DISARM
OPTION 4 Active Arming with Disarmed Notification.
Function 3 – Ignition Monitoring: Siren Mode / Horn Mode
OPTION 1 Siren Mode: Ignition Monitoring – disabled.
OPTION 2* Siren Mode: Ignition Monitoring – enabled.
OPTION 3 Horn Mode: Ignition Monitoring – disabled.
OPTION 4 Horn Mode: Ignition Monitoring – enabled.
button is pressed
TRUNK
button pressed
TRUNK
a 2nd time
UNLOCK
and then
SHIFT
button;
UNLOCK
button.
) Car Finder disabled.
AS-6320FM
PROGRAMMING OPTIONS AND WIRING DIAGRAM
OPTION 3 Constant output while pressed (press
) Car Finder disabled.
LOCK
OPTION 4 Priority Door access on 2
enabled.
The Driver's door unlocks upon the 1
pressing of the
UNLOCK
All Doors unlock upon the 2
the button.
UNLOCK
Mode 2
*indicates default setting
Function 1 – N/A
OPTION 1 N/A
OPTION 2* N/A
OPTION 3 N/A
Function 2 – Safe Start
OPTION 1 Safe Start enabled
OPTION 2* Safe Start disabled
OPTION 3 Swap Start – increased safety mode:
To Start: press
SHIFT
Press the Start button to activate Aux 2.
Function 3 – Engine Run Time
OPTION 1 Run time - 4 minute in Gas mode / 9 minutes Diesel
mode.
OPTION 2* Run time - 15 minute in Gas mode / 20 minutes Diesel
mode.
OPTION 3 Run time - 25 minute in Gas mode / 30 minutes
Diesel mode.
Function 4 – Idle/Turbo Mode
OPTION 1 Idle/Turbo Mode disabled
OPTION 2* Turbo Mode enabled
OPTION 3 Turbo Mode disabled
Function 5 – Engine Type and Cold Weather Mode
OPTION 1 Diesel Engine Mode and 20-minute run time in Cold
Weather Mode.
OPTION 2* Gasoline Engine Mode and 4-minute run time in Cold
Weather Mode.
OPTION 3 Diesel Engine Mode and 9-minute run time in Cold
Weather Mode.
Function 4 – Shock Sense / Warn Away
OPTION 1 Shock Sense - Ignored / Warn Away – ignored
OPTION 2* Shock Sense - monitored / Warn Away – monitored
OPTION 3 Shock Sense - Monitored / Warn Away – ignored
OPTION 4 Shock Sense - Ignored / Warn Away – monitored
Function 5 – Ignition Valet
OPTION 1 Ignition Valet - DISABLED
OPTION 2* Ignition Valet - ENABLED
OPTION 3 Ignition Valet – ENABLED
Mode 4
*indicates default setting
Function 1 – MULTI-LEVEL FEATURES
OPTION 1 Multi-car Features, Basic Features, Customized
Features
OPTION 2* Basic Features, Multi-car Features, Customized
Features
OPTION 3 Customized Features, Multi-car Features, Basic
Features
OPTION4 Basic Features, Customized Features,
Features
and then
SHIFT
nd Unlock, and Car Finder
st , 3 rd , 5 th ...
button.
nd , 4 th , 6 th ... pressing of
and then buttons.
LOCK
Multi-car
