Concert Series Owner's Manual
WARNING
Before installation, turn off the power
to the head unit or radio and discon-
nect the negative (-) lead of your
vehicle's battery.
Mounting the EQX
1. Select a permanent mounting site for the
EQX. Make sure you observe the Installation
Precautions listed on page 8.
2. Position the unit and use either a felt-tip pen
or spring-loaded center punch tool to mark
locations for the four mounting holes.
3. Drill a small pilot hole at each marked
location.
4. Secure the EQX with self-tapping screws.
12
Connecting the EQX
1. With ignition off, disconnect the negative (-)
lead from the vehicle's battery.
2. Connect +12 Vdc and Ground from the
vehicle's electrical system to the correspond-
ing +12 and GROUND terminals on the EQX.
Also connect the Remote turn-on signal
from the head unit to the REMOTE terminal.
3. Connect a set of RCA cables from the head
unit Left and Right outputs to the LINE
LEVEL INPUT (LEFT and RIGHT) on the
EQX Series II.
DO NOT CONNECT OUTPUTS AT
THIS TIME !
NOTE: For high-level signals, splice speaker
cable onto the radio's speaker wires and connect
the other end to the HIGH LEVEL INPUT (Left
and Right).
