- Page 1 INSTALLATION INSTRUCTIONS CONSOLE Air conditioners SILHOUETTE CONSOLES SPLIT CONSOLES CURTAIN WALL CONSOLES The Manufacturer strives for continuous improve- www.defy.co.za ments. For this reason, the text and illustrations in this book are subject to change without notice. Part Number 059 044...
-
Page 2: Installation Notes
To ensure optimum performance and customer satisfaction, please read these instructions carefully. All Defy Console type air-conditioners are tested and rated using the standard Defy wall sleeve and louvre assembly. Units can safely operate up to 43 °C outdoor temperature. They have been designed to produce the rated capacity at the lowest power consumption under International Standard Rating conditions.(ISO5151) at 27°C DB, 19°C WB indoor and 35°... -
Page 3: Prior To Installation
Silhouette Console Installation instructions MOUNTING HOLES CONSOLE UNIT MOUNTING HOLES WALL SLEEVE WALL APERTURE 100mm. ABOVE FINISHED FLOOR LEVEL (INDOOR) PRIOR TO INSTALLATION • Remove the filter assembly. • Loosen the two screws at the bottom corners of the access cover and remove it. •... -
Page 4: Electrical Connections
Split Console installation instructions ELECTRICAL CONNECTIONS NOTE. • • A 16A mains cable is connected to the indoor An electrical isolator must be installed close to unit. the condensing unit. • • If this cable is too short, a qualified electrician Ensure that the supply voltage is 230V 50 Hz. -
Page 5: Installation Of The Outdoor Unit
Installation of the Outdoor unit • Ensure that the voltage is 230V 50Hz. Also check that the model and capacity matches those of the in- door unit. • Select a position for the outdoor unit which allows for the shortest possible unobstructed pipe length. Ensure that the air intake and discharge are unobstructed and that there is enough room for servicing. -
Page 6: Electrical Installation
“This appliance must be earthed and Electrical the manufacturer and the seller do not accept Installation responsibility for any damage due to incorrect installation or electrical connection.” INTER CONNECTING WIRING DIAGRAM FOR SPLIT EVAP AND CONDENSER SECTION INTERCONNECTING SPLIT EVAP. AND COND. WIRING DIAGRAM WIRING FOR ELECTRONIC CONTROL ELECTRO MECHANICAL CONTROLS ELECTRONIC MODULE... - Page 7 Curtain Wall Console Installation Instruction WALL APERTURE WALL SLEEVE PRIOR TO INSTALLATION • Remove Front Inlet Grille and store in a safe place. • Remove both Filter Assemblies and store with the front inlet grille. • Remove the two screws securing the Front Cover assembly to the Chassis Assembly. •...
-
Page 8: Warranty
Warranty Defy Appliances (“the Company”) warrants to the purchaser to whom the product was sold by the dealer appointed by the company to distribute its products (“authorized dealer”) and in respect of which no prior sale of the product was made (“original purchaser”) that the Defy Air conditioning unit (“product”) sold with this certificate is free of defects...
