Sub-Zero IC-24R Quick Reference Manual page 2

24" Integrated All Refrigerator—Column
SPECIFICATIONS
PRODUCT
Dimensions 24" W x 84"H x 24" D
Weight
CAPACITY
Refrigerator
ELECTRICAL
Supply 115 VAC, 60 Hz
Service 15 amp circuit
Overall dimensions do not include panels or
handles. Dimensions will vary with panel
thickness.
The depth of each integrated model is 24".
Allow for panel thickness when planning the
finished opening depth.
Specifications are subject to change without
notice. Visit subzero.com/specs for the most
up-to-date information.
Dimensions may vary ± 1 / " . Dimensions in
(3)
8
parentheses are millimeters unless otherwise
specified.
©Sub-Zero, Inc. all rights reserved.
DIMENSIONS
W
24"
340 lb
12.9 cu ft
84"*
(2134)
1
*83 / "
2 (2121) MIN TO
1
INSTALLATION
SIDE VIEW
NOTE: Shaded areas will be visible and should be finished to match cabinetry.
24"
(610) (610)
4 1 / "
2 (114)
69 1 / "
2
(1765)
3 5 / "
8 (92)
1
84 / "
2 (2146) MAX
A 4"
(102)
3
/ "
4 (45)
B 1
22 / "
2
(572)
25"
(635)
OPENING
DEPTH
TOP VIEW
84" H
24" W
(2134) (610)
OPENING OPENING WIDTH
HEIGHT
FRONT VIEW
subzero.com
ELECTRICAL
LEFT SIDE
OF OPENING
1
4 1 / " 9 /
A
2
(114) (241)
FLOOR
1 1
/ / " "
4 4 (6) (6)
3 1 / "
2
(89)
TYPICAL
3 / "
4 (19)
TYPICAL
"
2
1
4 / "
4
(108)
