Fujitsu FTP628 MCL383 Specifications

BATTERY DRIVE, FTP-608 Series
2" H
IGH SPEED THERMAL PRINTER WITH CUTTER
FTP628 MCL383, Easy Loading Method (ELM)
OVERVIEW
The easy loading FTP-608 MCL Series is ultra compact high
speed, battery driven thermal printer, printing on 2-inch wide
paper (58mm) where platens are removable. Our original
platen removal mechanism improved paper loading and
maintenance.
The FTP-608 MCL series can be used for a variety of
applications, such as portable terminals, POS, ticket issuing
terminals, label printers, banking terminals, and
measurement and medical equipment.
HIGHLIGHTS
• Easy loading type
Our unique platen removal mechanism improved paper
loading and maintenance. Easy to remove paper jam.
• Ultra compact
Height 33.0 mm, width 87.6 mm, depth 66.3 mm for the 2
inch model.
• Multi-Function Diecast Frame
Functions as heat sink for motor and high antistatic
resistance to ESD, and high shock and vibration
resistance.
• High speed printing
It can print at 80 mm/s (640 dotlines/s) maximum by using
Fujitsu's unique head drive control.
• High resolution printing
8 dots/mm of resolution printing is possible.
1
