BaTTery drive, MOBiLe TyPe
COMPaCT STandaLOne TherMaL PrinTer
2" eaSy LOading MOdeL
FTP-628WSL110/120
n OvervieW
The supply voltage of the FTP-628WSL Series is 20VAC
(via AC adaptor) or battery. The unit uses 2 inch wide
paper. The mechanism and interface board is a standard
multiple purpose unit.
The semi-rugged printer unit is most suitable for applications
such as handheld, mobile and portable devices, as well as
for various other equipment.
n FeaTureS
• Lightweight and ultra small size
• Easy paper loading
• Bluetooth®, infrared and serial interfaces
• 3.7V Lithion battery, 20 or 240 VAC adapter
• Drop-test - .5 meters
• Water resistant
• Prints 2-D barcodes
• 3 hour charge cycle
• Up to 6 paper rolls / charge
• Program download capability
• Thin label capability
• RoHS compliant
• IP54 compliant
Advertisement
Related Manuals for Fujitsu FTP-628WSL120
Summary of Contents for Fujitsu FTP-628WSL120
- Page 1 BaTTery drive, MOBiLe TyPe COMPaCT STandaLOne TherMaL PrinTer 2” eaSy LOading MOdeL FTP-628WSL110/120 n OvervieW The supply voltage of the FTP-628WSL Series is 20VAC (via AC adaptor) or battery. The unit uses 2 inch wide paper. The mechanism and interface board is a standard multiple purpose unit. The semi-rugged printer unit is most suitable for applications such as handheld, mobile and portable devices, as well as for various other equipment.
-
Page 2: Specifications
FTP-628WSL110 /120 Series n ParT nuMBer p i l ) l l p i l ) l l p i l ) l l p i l ) l l n SPeCiFiCaTiOnS i f i o i t n i l t i p t i p i t r i t c... - Page 3 FTP-628WSL110 /120 Series FTP-628WSL0/20 Specs continued c i f l a i r I ( l i f C ˚ ˚ 0 y t i ˚ 0 ˚ 0 y t i t s i c t i v i t , ) r , ) r v i t , ) r...
- Page 4 FTP-628WSL110 /120 Series n diMenSiOnS...
- Page 5 FTP-628WSL110 /120 Series n COMMandS Command Contents Horizontal tab. Line feed with printing. Feeds forms (new page). ECS RS Sets reverse printing. ESC US Resets reverse printing. ESC FF Data printing in page print mode. ESC ! + n Sets print mode. ESC %+n External registration character specification / cancellation.
- Page 6 Tel: (65) 6375-8560 Email: components@us.fujitsu.com Fax: (65) 6273-302 Web: http://us.fujitsu.com/printers/ Email: fcal@fcal.fujitsu.com Web: http://www.fujitsu.com/sg/services/micro/components/ ©2007 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective owners. Fujitsu Components America or its affiliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our products Fujitsu Components America, Inc. or its affiliates reserve the right to change specifications/datasheets without prior notice. Rev. February 2, 2007...
