Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 3 mm diameter screws are enclosed in
the screw pack.
Screw Type B
Diameter (mm)
3
30
Length (mm)
25
149.90 mm
Tightening Screw
Allen Key
Allen Key
Tightening Screw
Washer Type
Large
V
83.27 mm
12.11 mm
39
Small
V
