Projector Overview

Projector Outlook

Front/upper side
# Description
1 Control panel
2 Projection lens
3 Elevator button
4 Lens cap
Rear side
(S1213Hne/T212DTB/XS-X13HGM/
S1313WHne/T222DTB/XS-W13HGM)
1 2 3 4 5 6
RS232 LAN USB B
VGA OUT
11
# Description
1 RS232 connector
2 LAN (RJ45 port for 10/100M
Ethernet)
3 Mini USB connector
4 Remote control receiver
5 HDMI (MHL) connector
6 Monitor loop-through output
connector
7 Analog RGB signal/HDTV/
component video input connector
1
2
3
4
#
5
6
7
(S1210/T210/XS-X10/S1212/
T212A/XS-X13E/S1312W/T222A/
XS-W13E)
7 8 9 10
S-VIDEO AUDIO-R
AUDIO
IN 1
VGA IN 1
AUDIO
IN 2
VIDEO AUDIO-L
AUDIO
VGA IN 2
OUT
12 13
#
8
9
10 Audio input connector
11 Power socket
12 Tilt adjusting wheel
13 Kensington™ lock port
5
6
7
Description
Power key and Power indicator
LED
Focus ring
Remote control receiver
1 3 6 7
RS232 USB B
VGA OUT VGA IN
Description
S-Video input connector
Composite video input connector
Audio input connector (L/R)
Audio output connector
3
8 9 10
S-VIDEO AUDIO-R
AUDIO
IN
AUDIO
OUT
VIDEO AUDIO-L
