Acer S1370WHn Service Manual

Acer S1370WHn Service Manual

Hide thumbs Also See for S1370WHn:

Advertisement

Quick Links

Download this manual See also: User Manual

SERVICE MANUAL

S1370WHn
Date
Revise Version
Description
2012.07.15
V1.0
Initial Issue
Copyright July 2012 All Rights Reserved
Prepared:
Joe
Checked: Simon
Approved: Alick

Advertisement

loading
Need help?

Need help?

Do you have a question about the S1370WHn and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acer S1370WHn

Summary of Contents for Acer S1370WHn

  • Page 1: Service Manual

    SERVICE MANUAL S1370WHn Date Revise Version Description 2012.07.15 V1.0 Initial Issue Copyright July 2012 All Rights Reserved Prepared: Checked: Simon Approved: Alick...
  • Page 2 Preface This manual is applied to S1370WHn projection system. The manual gives you a brief description of basic technical information to help in service and maintain the product. Your customers will appreciate the quick response time when you immediately identify problems that occur with our products.We expect your customers will appreciate the...

  • Page 3: Chapter 1 Introduction

    Assemble System Fan Module 2-23 Assemble Engine Module 2-24 Assemble Front Cover Module 2-26 Assemble Speaker Module and Dust Filter Hold 2-27 Assemble Main Board Module and Shielding 2-28 Assemble Keypad and Zoom Ring 2-30 Assemble Top Cover Module 2-31 S1370WHn Confidential...
  • Page 4 Video Performance RJ45 Port Test and Lan Setting Optical Performance Measure 4-10 Burn-In Test 4-11 Others 4-12 Chapter 5 Firmware Upgrade Section 1: System Firmware Upgrade Equipment Needed DLP Composer Lite Setup Procedure Get into FW Download Mode S1370WHn Confidential...
  • Page 5 EDID Introduction Equipment Needed Setup Procedure EDID Key-In Procedure Un-lock SNID and Default Language Reset Appendix A Exploded Overview FRU list Appendix B Serial Number System Definition PCBA Code Definition Appendix C Equipment needed Hardware and Docklight168 setup procedure RS232 function command summary table S1370WHn Confidential...
  • Page 6 ● 288 mm x 225 mm x 83.3 mm (11.3” x 8.9” x 3.3”) (W x D x H) ● AC input 100 - 240 V, 50 - 60 Hz ● S1370WHn: -190W for Osram Lamp driver @ normal operation, Power Supply...
  • Page 7 65% Japan standard (Minimum; Full power mode) Uniformity ● 80% Japan standard (Typical; Full power mode) 80% Japan standard (Typical; Full power mode) ● Operating: 5°C ~ 40°C Operating: 5°C ~ 40°C Temperature ● Storage: -10°C ~ 60°C Storage: -10°C ~ 60°C Confidential S1370WHn...
  • Page 8 1152x864 77.10 SXGA 1280X1024 63.98 1280X1024 77.90 1280X1024 79.98 1280X1024 91.15 1280x960 60.0 QuadVGA 1280x960 75.0 SXGA+ 1400x1050 65.32 UXGA 1600x1200 75.0 640x480 31.5 640x480 66.6(67) 35.0 800x600 37.88 Power Mac G4 1024x768 48.36 1152x870 68.68 1280x960 75.20 Confidential S1370WHn...
  • Page 9 50(25) 28.1 1080p 1920x1080 67.5 1080p 1920x1080 56.3 1080p 1920x1080 27.00 1080p 1920x1080 23.97 26.97 HDMI Digital HDMI - PC Signal Compatibility Resolution H-Sync [KHz] V-Sync [Hz] 640x480 31.47 640x480 37.86 640x480 37.5 640x480 43.27 640x480 119.51 61.61 Confidential S1370WHn...
  • Page 10 60.02 1024x768 119.804 98.80 1152x864 67.50 SXGA 1152x864 77.1 1280x1024 64.0 1280x1024 77.0 1280x1024 80.0 1280x1024 91.1 640x480 31.50 640x480 66.6(67) 35.00 800x600 37.88 PowerBook G4 1024x768 48.36 1152x870 68.68 1280x960 75.20 i Mac DV (G3) 1024x768 60.3 Confidential S1370WHn...
  • Page 11 28.1 1080p 1920x1080 67.5 1080p 1920x1080 56.3 1080p 1920x1080 27.00 1080p 1920x1080 23.97 26.97 Horizontal scan rate: 30 k - 100 kHz Vertical scan rate: 50 - 85 Hz,120Hz (for 3D mode only) Max. pixel rate: 165 MHz Confidential S1370WHn...

  • Page 12: Product Overview

    1-3 Product Overview Projector Outlook Front /Upper side Item Description Item Description Power button Remote control receiver Control panel Tilt adjusting wheels Focus rings Security bar Focus ring Zoom lens Confidential S1370WHn...

  • Page 13: Rear Side

    Composite video input connector input connector (VGA IN 2) S-Video input connector Audio output connector Monitor loop-through output connector Dust filter inlets (VGA-Out) PC analog signal/HDTV/component Power socket video input connector (VGA IN 1) RS232 connector KensingtonTM lock port Confidential S1370WHn...
  • Page 14 Control Pannel Item Icon Function Description POWER Power Indicator LED LAMP Lamp Indicator LED TEMP Temp Indicator LED Automatically synchronizes the projector RESYNC to the input source. SOURCE Changes the active source. Confidential S1370WHn...
