Insignia NS-28E200NA14 Quick Setup Manual

START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: A Phillips screwdriver and a soft surface to lay the TV on.
QUICK
A Lay the TV down on a soft surface.
B Secure the stand column to the stand with the four 14 mm screws provided.
SETUP GUIDE
C Insert the stand assembly into the back of TV.
D Secure the stand assembly to the TV with the four 8 mm screws provided.
28" LED TV
NS-28E200NA14
Thank you
for purchasing this state-of-the-art
How do I prepare my TV for wall mounting?
Insignia television. We hope you enjoy
(not for use with a TV stand)
the quality and reliability of this
• Lay the TV down on a soft surface.
television for years to come.
Included accessories
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service.
Enter your model number in the box under
M4 (8 mm length) (4)
Manual, Firmware, Drivers & Product
Information, then click .
M4 (14 mm length) (4)
- OR -
See the instructions that came with your wall mount for more information about how to correctly mount your TV.
Which cables do you have?
Your TV has several different jacks for connecting devices. For the
STOP!
best video quality, use the best available connection. Use the cables
that came with your devices.
Do not plug your
power cord in until all
other devices have
VIDEO QUALITY
been connected.
BEST
BETTER
Component video and analog audio
GOOD
Composite video and analog audio
GOOD
Power cable
Note: You can use the HDMI 1/ARC/DVI jack to connect a DVI device to your TV. Attach an
HDMI-to-DVI adapter to the end of the HDMI cable. The adapter connects to the DVI
device's jack. See your online User Guide for more information about different types of
HDMI (ARC, DVI, MHL).
Features
Front view
Remote control
and two AAA
batteries
Power indicator
Remote control sensor
Back view
Power connector
Stand column
and screws (Screws
are for securing the
stand column to
the TV)
TV stand and screws
(Screws are for
securing the TV
Y / VIDEO
stand to the stand
DIGITAL
column) C C O O M M P P O O N N E E N N T T / / A A V V
OUTPUT
Note: Images do not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
A
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, MHL-enabled device, Roku Streaming Stick, or camcorder?
Using an HDMI cable (BEST)
JACK TYPE CABLE CONNECTOR
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
/AUDIO
OUT
2
MHL
How do I connect my TV to an antenna or cable wall jack?
1
ARC/DVI
USB
PC / DVI
ANT / CABLE VGA
AUDIO IN
B C
M4 (14 mm)
MHL PORT
2
MHL
1
ARC/DVI
AUDIO/VIDEO OUT
Component cable option
Y / VIDEO
DIGITAL PC / DVI
C C O O M M P P O O N N E E N N T T / / A A V V ANT / CABLE VGA
OUTPUT AUDIO IN
AUDIO/VIDEO
OUT
VIDEO
AV cable option
Y / VIDEO
DIGITAL PC / DVI
C C O O M M P P O O N N E E N N T T / / A A V V ANT / CABLE VGA
OUTPUT AUDIO IN
M4 (8 mm)
D
Multi-purpose jacks: You can plug
any device that uses HDMI into the
HDMI 2/MHL or HDMI 1/ARC/DVI jack.
However certain devices must be
connected to the HDMI 2/MHL
or HDMI 1/ARC/DVI jack. See the
instructions that came with your MHL,
ARC, or DVI device for more
information.
Note: The component and AV jacks are
shared. This means you can connect
only one component or AV device at a
time. We suggest using HDMI if your
device supports it.
Note: Connect the yellow video cable
connector to the green Y/VIDEO jack
on the back of your TV.
CABLE
OVER
