Insignia NS-28DD220NA16 Quick Setup Manual

INCLUDED ACCESSORIES

1
Remote control and
two AAA batteries
A Carefully place your TV face-down on a
+ +
cushioned, clean surface.
Power adapter
A
TV stands

FEATURES

M4 type (14 mm length) (4pcs.)

FIND YOUR USER GUIDE ONLINE!

Go to www.insigniaproducts.com, then
click Support & Service. Enter
NS-28DD220NA16 in the box under
Manual, Firmware, Drivers & Product
►
Information, then click .
STOP
Do not plug your power adapter in until
all other devices have been connected.

START HERE

How do I attach the stands to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver
B Secure the TV stands to the TV with the
four provided screws.
B
Front
Remote control sensor
Power indicator
EJECT MENU INPUT V O - L VOL+ CH CH
AV IN COMPONENT IN
ANT / CABLE
DC IN
L - AUDIO - R
VIDEO / Y P P
B R
Before using your new product, please read these
instructions to prevent any damage.

WALL MOUNT

How do I prepare my TV for wall mounting? (not for use with a TV stand)
You'll need: Soft surface.
A
Carefully place your TV face-down on a cushioned, clean surface.
OR B
See the instructions that came with your wall mount for more information about how
to correctly mount your TV.
X2
M4 type (14mm length) (4pcs.)

MAKING CONNECTIONS

2
How do I watch TV (cable, satellite, or antenna) or connect a device such as a DVD or Blu-ray disc player, game console, or tablet?
WHICH CABLES
Multi-purpose jacks: You can plug any device that uses HDMI into any HDMI jack. However,
DO YOU HAVE?
certain devices must be connected to the ARC jack. See the instructions that came with your
ARC-enabled device for more information.
HDMI
(BEST)
Best video quality
COMPONENT
Note: The component and AV jacks are shared. This means you can connect
BETTER
only one component or AV device at a time. We suggest upgrading to HDMI
(BEST) if your device supports it.
OR
AV
(GOOD)
DC IN
L - AUDIO - R
Note: Connect the yellow
video cable to the
green VIDEO/Y jack.
COAXIAL
GOOD
Quick Setup Guide
28" 720 p • 60Hz, LED TV/DVD combo
A
AUDIO/VIDEO OUT
AV IN COMPONENT IN
ANT / CABLE
VIDEO / Y P P
B R
ANT / CABLE
|
NS-28DD220NA16
Your TV has four VESA mounting
B holes on the back. If you attach a
wall-mount bracket to the back of
your TV, the bracket must be
securely attached, using all four
holes. If you do not use all four
mounting holes, your TV may fall and cause property damage
or personal injury. See the documentation that came with
your wall mount for complete mounting instructions.
AUDIO/VIDEO OUT
CABLE
