MX822ST
DIGITAL
PROJECTOR
Features
Native XGA (1024 x 768) Resolution
3,500 ANSI Lumens, 13,000:1 Contrast Ratio
PointDraw 3.0 Ready, 0.62 Short Throw Ratio
SmartEco™ Power Saving Technology
DLP
®
3D via PC & Blu-Ray/DVD Player
LAN Control/Display, USB Reader/Display
*Optional Wireless Display, Optional PointDraw Interactivity
Input and Output Terminals
1 2 3
4
5
6
13
14 15 16
1
Audio Out (Mini Jack)
2
Audio In 1 (Mini Jack)
3
Audio In L/R (RCA)
4
PointDraw 3.0 port
5
Monitor Out (D-sub 15pin)
6
Computer In 1 & 2 (D-sub 15pin)
HDMI
7
8
RS232 (DB-9pin)
BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618
BenQ is a registered trademark of BenQ Corp. DLP
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
7
8
9 10 11 12
USB (Type B)
9
10
USB (Type Mini B)
USB (Type A)
11
LAN (RJ45)
12
13
Microphone
14
Composite Video In (RCA)
15
S-Video In (Mini DIN 4pin)
16
DC 12V Trigger (3.5mm Jack)
Tel: (949) 255-9500
®
is a registered trademark of Texas Instruments. All rights reserved.
I
Specifications
Projection System
DLP
®
Native Resolution
XGA (1024x768)
Brightness
3,500AL
Contrast Ratio
13,000:1
Display Color
1.07 Billion Colors
Lens
F=2.8, f=7.26 mm
Aspect Ratio
Native 4:3 (5 aspect ratio selectable)
Throw Ratio
0.62 (78" @ 0.99m)
Image Size (Diagonal)
55"~100" Max up to 300"
Zoom Ratio
Fixed
Lamp Type
310W
Lamp Life
2500/3000/3500 hours
Keystone Adjustment
1D, Vertical +/- 30 degrees
Projection Offset
130% ±5%
Resolution Support
VGA(640 x 480) to UXGA(1600 x 1200)
Horizontal Frequency
31~100 KHz
Vertical Scan Rate
50~120 Hz
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Compatibility
Video Compatibility: NTSC, PAL, SECAM
3D Compatibility:
PC: 120Hz Frame Sequential 3D for resolutions up to WXGA,
PC: 60Hz Top-bottom 3D for resolutions up to SXGA+
Video: 60Hz Frame Sequential 3D for resolutions up to 480i
Computer in (D-sub 15pin)
Interface
Monitor out (D-sub 15pin)
Composite Video in (RCA)
S-Video in (Mini DIN 4pin)
HDMI
Audio in (Mini Jack)
Audio in (L/R)
Audio out (Mini Jack)
Speaker
USB (Type mini B)
USB (Type A)
USB (Type B)
RJ45
DC 12V Trigger (3.5mm Jack) x 1
RS232 (DB-9pin)
IR Receiver
PointDraw 3.0 port
Dimensions (WxHxD)
12.9" x 5.1" x 9.8"
Weight
8.1 lbs (3.64 kg)
Power Supply
AC100 to 240 V, 50 to 60 Hz
Power Consumption
370W(typical), Standby<0.5W
36/34 dBA (Normal/Economic mode)
Audible Noise
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/
On-Screen Display
French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/
Languages
Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/
Russian/ Simplified Chinese/Spanish/ Swedish/ Turkish/ Thai/
Traditional Chinese (28 Languages)
Picture Modes
Dynamic/Presentation/sRGB/Cinema/User 1/User 2
Accessories (Standard)
Lens Cover, Remote Control w/ Battery, Power Cord, User Manual CD,
Quick Start Guide, Warranty Card, VGA(D-sub 15pin) Cable
Accessories (Optional)
Wireless Dongle WDRL 3070
Spare Lamp Kit
Wall Mount WM06G3
3D Glasses _D3
Carry bag
PD03_PenKit
PD03_Pen
8400460-2681-3 / 9H.J8D77.34A
UPC / Part #
Limited Warranty
3-Year Parts & Labor / 1-Year or 2000 hours of lamp life
*Lamp life results will vary depending on environmental conditions and usage. Actual product's features and specifications
are subject to change without notice.
www.BenQ.us
x 2 (Share with component)
x 1
x 1
x 1
x 1
x 2
x 1
x 1
20W x 1
x1 (USB Display)
x 2 (USB Reader & Wireless Display &
Remote Desktop & Document Camera)
x 1 (Work with PD pen, FW download)
x 1 (LAN control, LAN display, audio)
x 1
x 2 (Front+real)
x 1
5J.J0614.A21
5J.J6R05.001
5J.J4R10.011
5J.J7K25.001
5J.J2V09.011
5J.J8E26.A01
5J.J8E26.A11
MX822ST 04-23-13-BQus
