Toshiba Portege R600-ST520W Specifications

Portégé R600-ST520W Detailed Product Specification
Model Name Description
R600-ST520W Genuine Windows Vista® Business, Intel® Core™ 2 Duo Processor SU9400, 3GB
DDR2, 160GB HDD, DVD-SuperMulti, 12.1" widescreen WXGA, Intel® Wireless
WiMAX/WiFi Link 5350AGN, Webcam, Bluetooth v2.1 + EDR, 3 year standard
limited warranty (1-year warranty on battery)
C1
Operating System
• Genuine Windows Vista® Business (SP1, 32-bit version)
o Downgrade media for Genuine Windows® XP Professional
Processor and Chipset
Intel® Centrino® 2 with vPro™ processor technology
featuring:
o Intel® Core™ 2 Duo Processor SU9400
1.4GHz, 3MB L2, 800MHz FSB with 64-bit
• Chipset
o Mobile Intel® GS45 Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiMAX / WiFi Link 5350AGN (802.11a/g/n +
4
WiMAX)
• Wired LAN
o Intel® Pro 82567LM Gigabit Network Connection (with AMT 4.1)
5
Memory
• Configured with 3GB PC2-6400 DDR2 SDRAM
• 3GB (Min)/5GB (Max), 1GB on motherboard with one memory slots
occupied with 2GB PC2-6400 memory module
Storage Drive Capacity
• 160GB (5400 RPM) Serial ATA hard disk drive; 9.5mm height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R) drive supporting 9 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
8
Display
• 12.1" diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) - Transreflective type
o LED sidelight
9
Graphics
• Mobile Intel® Graphics Media Accelerator 4500MHD with 128MB-
1340MB dynamically allocated shared graphics memory
Sound
• Built-in mono speaker
• Sound volume control dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Toshiba Assist button
o Toshiba Outdoor Display Switch
Communications
• Integrated Webcam
• Intel® PRO/1000 - 10/100/1000 Ethernet
• Integrated Intel® Wireless WiMAX / WiFi Link 5350AGN (802.11a/g/n +
10
WiMAX)
• Bluetooth® version 2.1 plus Enhanced Data Rate (EDR)
Expandability
• ExpressCard™ slot
• Secure Digital (SDHC) slot
Ports
• Video
o RGB (monitor) output port
• Audio
2
3
6
7
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 3 ports
o 2 x USB v2.0
o 1 x eSATA/USB combo port with USB Sleep and
o 64-pin docking connector
• Security
C1
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 11.1" x 8.5" x 0.77"(f)/1.0"(r) with
feet
• Weight: Starting at 2.4 lbs depending upon configuration
• LCD Cover Color: Aluminum Silver
Power
• 45W (15V x 3A) 100-240V AC Adapter.
• Dimensions (WxDxH): 3.66" x 1.09" x 1.57"
• Weight: starting at 0.4 lbs
13
Battery
• (5800mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.1" x .79" x 1.72"
• Weight: starting at 0.69 lbs
• Battery Life (measured by MobileMark™)
o Included 6-cell battery: 7 hours, 32 minutes
Toshiba EasyGuard®
• Protect & Fix
o PC Health Monitor
o Shock Absorbing Design
o Hard Disk Drive Protection
o Spill-Resistant Keyboard
o Magnesium Alloy Casework
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad® TruePrint® technology
o Infineon TPM Software Professional Package
o Trusted Platform Module (TPM v1.2)
o TOSHIBA Secure Digital Token Utility
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
• Optimize
o TOSHIBA Zooming Utility
o One-touch Resolution Change
o TOSHIBA Power Saver Utility
o TOSHIBA Optical Disc Drive Power On/Off Utility
o Wireless On/Off Switch
o TOSHIBA Fn-esse® Shortcut Utility
Portégé R600-ST520W
Part Number UPC
PPR61U-01J033 883974187461
11
Charge
14
15
16
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
17
CompuTrace®
12
