JVC KW-NSX1 Instruction Manual

Monitor with dvd receiver
Hide thumbs Also See for KW-NSX1:
Table of Contents

Advertisement

Quick Links

MONITOR WITH DVD RECEIVER
MONITOR CON RECEPTOR DE DVD
MONITEUR AVEC RÉCEPTEUR DVD
KW-NSX1
Consists of KW-HUNSX1 (Main unit) and KS-NSX1 (SMARTPHONE ADAPTER unit).
Se compone de la KW-HUNSX1 (unidad principal) y del KS-NSX1 (ADAPTADOR SMARTPHONE).
Composé du KW-HUNSX1 (appareil principal) et du KS-NSX1 (unité SMARTPHONE ADAPTER).
For canceling the display demonstration, see page 7.
Para cancelar la demonstración en pantalla, consulte la página 7.
Pour annuler la démonstration des affichages, référez-vous à la page 7.
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l'installation et les raccordements, se référer au manuel séparé.
MANUEL D'INSTRUCTIONS
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
For customer Use:
Enter below the Model No. and
Serial No. which are located on
the top or bottom of the cabinet.
Retain this information for future
reference.
Model No.
Serial No.
LVT2355-001A
[J]
