Ryobi JS481L Repair Sheet page 3

The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
ORBITAL JIG SAW or when ordering parts.
KEY PART
NO. NUMBER DESCRIPTION
1 730372033 Power Cord ..................................................... 1
2 551060001 Bend Relief ..................................................... 1
3 202137001 Housing Assembly .......................................... 1
4 202141001 Cover Assembly .............................................. 1
5 550424001 Detent Button ................................................. 1
6 680909001 Spring ............................................................. 1
7 524208001 Orbital Adjustment Knob ................................ 1
8 760476002 Switch Assembly ............................................ 1
9 280202002 Circuit Board Assembly .................................. 1
10 611841001 Bushing ........................................................... 1
11 630845001 Guide Plate ..................................................... 1
12 631252001 Spring Plate .................................................... 1
13 693232001 Spring ............................................................. 1
14 304944002 Saw Bar Assembly .......................................... 1
15 690227083 Wood Cutting Blade ........................................ 1
16 6620802 Screw (M4 x 18 mm, Pan Hd.) ...................... 11
17 660007002 Screw (M3 x 12 mm) ....................................... 3
18 660165017 Screw (M4 x 8 mm) ......................................... 4
19 524163001 Base Plate ....................................................... 1
20 670974003 Insert Nut (M5) ................................................ 1
21 634115001 Clamp Pad ...................................................... 1
22 640783004 Saw Base ........................................................ 1
23 301010011 Base Adjustment Lever Assembly .................. 1
24 301008001 Positive Stop Screw ........................................ 1
25 678050001 Washer (OD11.2 x ID5.2 x 0.8t) ...................... 1
26 941121005 Data Label ....................................................... 1
27 671419002 Ball Bearing (KEJIE 608ZZ) ............................. 1
RYOBI ORBITAL JIG SAW – MODEL NUMBER JS481L
PARTS LIST
QTY
KEY PART
NO. NUMBER DESCRIPTION
28 291118002 Brush Assembly .............................................. 2
29 291085001 Motor Assembly .............................................. 1
30 202224001 Bearing Plate Assembly .................................. 1
31 660436009 Screw (M4 x 30 mm) ....................................... 2
32 680335076 Washer (OD12 x ID6 x 0.5t) ............................ 2
33 631081003 Drive Plate ....................................................... 1
34 611712001 Counterbalance .............................................. 1
35 681071001 Pin (5 x 12 mm) ............................................... 1
36 611629001 Gear Assembly ............................................... 1
37 693176001 Drive Sleeve .................................................... 1
38 634134001 Washer (OD12 x ID5 x 1t) ............................... 1
39 692821001 Retaining Ring ................................................ 1
40 681597001 Needle Bearing ............................................... 1
41 670704001 Retaining Ring ................................................ 1
42 621355001 Orbital Adjustment Rod .................................. 1
43 305086001 Blade Guide Assembly ................................... 1
44 693114002 Torsion Spring ................................................. 1
45 671143001 Pin ................................................................... 1
46 671147006 Guard Wire ...................................................... 1
47 941002005 Logo Label ...................................................... 1
48 941001010 Orbital Label ................................................... 1
Not Shown:
631097001 Optional Edge Guide Kit
301009001 Optional Dust Port Assembly
988000859 Operator's Manual
6-7-13
(REV:05)
3
QTY
