Bios Flash Memory Organization; Intel Visual Bios Setup Display Areas; Bios Setup Program Function Keys - Intel DB85FL Specification

Intel Desktop Board DB85FL Technical Product Specification
Table 32 lists the BIOS Setup program menu features.
Table 32. Intel Visual BIOS Setup Display Areas
Home 1 Home 2
Displays Environmental
monitoring
processor,
graphics, display and
memory, and attached SATA
configuration with devices
quick launch to
tuning, UEFI
apps, BIOS
update, and
system profiles
Table 32. Intel Visual BIOS Setup Display Areas (continued)
Performance
Displays and
Configures Memory,
Graphics, Bus, and
Processor overrides
Table 33 lists the function keys available for menu screens.
Table 33. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key
<←> or <→>
<↑> or <↓>
<Tab>
Mouse
<Enter>
<F9>
<F10>
<Esc>
3.2

BIOS Flash Memory Organization

The Serial Peripheral Interface Flash Memory (SPI Flash) includes a 96 Mb (12288 KB)
flash memory device.
60
Home 3
System,
desktop
board,
chassis, and
processor
information
Security Power
Sets passwords Configures power
and security management features
features and power supply
controls
Description
Selects a different menu screen (Moves the cursor left or right)
Selects an item (Moves the cursor up or down)
Selects a field (Not implemented)
Allows control of all options and slider controls in Intel Visual BIOS
Executes command or selects the submenu
Load the default configuration values for the current menu
Save the current values and exits the BIOS Setup program
Exits the menu
Devices &
Main Peripherals
Displays Configures
processor, advanced
memory, features
configuration, available
event log, through the
date, and chipset and
time other discrete
controllers
Boot
Selects boot
options and
boot display
options
Cooling
Real-time system
monitoring, adjust
fan speeds, set
temperature set
points, and define
system voltage
settings
continued
Exit
Saves or discards
changes to Setup
program options
