FujiFilm FinePix S1000 Specification Sheet

S P E C I F I C A T I O N S
DIGITAL CAMERA FinePix S1000fd
* 1
Number of effective pixels 10.0 million pixels
CCD sensor 1/2.3-inch CCD
Storage media Internal memory (Approx. 24MB) / xD-Picture Card™ (16MB - 2 GB) /
SD memory card / SDHC memory card * 2
Still image: JPEG (Exif Ver. 2.2 * 3 )
File format
Movie: AVI (Motion JPEG) with sound
Audio: WAVE format, Monaural sound
[Design rule for Camera File system compliant/DPOF-compatible]
Number of recorded pixels Still image: 3648×2736 / 3648×2432 (3:2 format) / 2592×1944 /
2048×1536 / 1600×1200 / 640×480 pixels
Lens Fujinon 12× Optical zoom lens, F2.8 (Wide) - F5.0 (Telephoto)
Lens focal length f=5.9mm - 70.8mm, Equivalent to 33 - 396mm on a 35mm camera
Aperture F2.8 - F5.6 (Wide) / F5.0 - F8.0 (Telephoto), max 5 steps in 1/3 EV increment
Digital zoom Approx. 5.7×
Focus distance Normal: Wide angle: Approx. 40cm / 1.3 ft. to infinity
Telephoto: Approx. 1.5m / 4.9 ft. to infinity
Macro: Wide angle: Approx. 5cm / 2.0 in. to 3m / 9.8 ft.
Telephoto: Approx. 80cm / 2.6 ft. to 3m / 9.8 ft.
Super Macro: Approx. 2cm / 0.8 in. to 1m / 3.3 ft.
Sensitivity Auto / Auto (800) / Auto (400) / Equivalent to
ISO 64 / 100 / 200 / 400 / 800 / 1600 (Standard Output Sensitivity)
Exposure control
TTL 256-zones metering
Exposure modes Programmed AE, Aperture Priority AE, Shutter Priority AE
Shooting modes Mode dial: Auto, Natural Light, SP1, SP2, P, A, S, M, Panorama, Movie
SP1 / SP2: Portrait, Landscape, Sport, Night, Fireworks, Sunset, Snow, Beach,
Museum, Party, Flower, Text, PS (Picture Stabilization)
Shutter speed 1/4 sec. to 1/2000 sec. (Auto mode)
8 sec. to 1/2000 sec. (All other modes)
Continuous shooting Top-3 (max. 1.4 frames/sec.), Last-3 (max. 1.4 frames/sec.),
Long-period (max. 0.5 frames/sec.)
Top-6, High speed (max. 3.3 frames/sec., 5M pixels)
Top-15, Ultra High speed (max. 7.5 frames/sec., 2M pixels)
Auto focus (Area, Multi, Center) / Continuous AF / Manual focus
Focus
AF assist illuminator available
White balance Automatic scene recognition
Preset (Fine, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White),
Fluorescent light (Cool White), Incandescent light), Custom
Self-timer Approx. 10 sec./2 sec. delay
Flash Auto flash
Effective range: (ISO AUTO):
Normal: Wide angle: Approx. 40cm / 1.3 ft. to 8.7m / 28.5 ft.
Telephoto: Approx. 1.5m / 4.9 ft. to 4.8m / 15.7 ft.
Macro: Wide angle: Approx. 30cm / 1.0 ft. to 3m / 9.8 ft.
Telephoto: Approx. 80cm / 2.6 ft. to 3m / 9.8 ft.
Flash modes:
Red-eye removal OFF: Auto, Forced Flash, Suppressed Flash, Slow Synchro
Red-eye removal ON: Red-eye Reduction Auto, Red-eye Reduction & Forced Flash,
Suppressed Flash, Red-eye Reduction & Slow Synchro
Electronic viewfinder
0.2-inch, Approx. 200,000 dots FLCD monitor
(R/G/B colors are displayed in a single dot) Approx. 94% coverage
LCD monitor 2.7-inch, Approx. 230,000 dots,
TFT color LCD monitor, Approx. 97% coverage
Movie recording
640×480 pixels, 30 frames/sec.
320×240 pixels, 30 frames/sec.
With monaural sound, with Electronic Image Stabilization
* Zoom function cannot be used during movie recording.
Photography functions Panorama shooting mode, Face detection (with red-eye removal), High speed shooting,
Best framing, Post shot assist windows, Frame No.memory, Histograms
Playback functions Slide show, Face detection (with red-eye removal), Trimming, Multi-frameplayback (with Micro thumbnail),
Sorting by date, Image rotate, Voice memo, Histograms (Highlight warning)
Video output
NTSC / PAL selectable
Digital input/output USB 2.0 High speed
* 4
Power supply 4×AA type alkaline batteries (included), Ni-MH rechargeable batteries (optional) or
Lithium batteries (optional), DC coupler CP-04 with AC power adapter AC-5VX (optional)
102.5 (W) × 73 (H) × 67.8 (D) mm / 4.1 (W) × 2.9 (H) × 2.7 (D) in.
Dimensions
(excluding accessories and attachments)
Weight Approx. 325g / 11.5 oz. (excluding accessories, batteries and memory card)
*1 Number of effective pixels: The number of pixels on the image sensor which receive input light through the
optical lens, and which are effectively reflected in the final output data of the still image.
*2 Please see the Fujifilm website to check memory card compatibility.
*3 Exif 2.2 is a newly revised digital camera file format that contains a variety of shooting information for
optimal printing.
*4 Manganese dry, nickel-cadium and lithium AA batteries cannot be used with this product.
*5 "CIPA DC-002-2003 'Standard Procedure for Measuring Digital Still Camera Battery Consumption' "
(extract) Pictures shall be taken at a temperature of 23˚C, with the LCD monitor turned on, the zoom
moved from full wide-angle to full telephoto (or vice-versa) and back again to its original position every
30 seconds, the flash used at full power every second shot and the camera turned off and on again onve
every 10 shots.
Microsoft, Windows, and Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United
States and/or other countries. Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and
other countries. xD-Picture Card™, SD logo and all other trademarks are the property of their respective holders.
F U N C T I O N S
Shutter button
Zoom lever
AF-assist illuminator /
Self-timer lamp
Battery cover
Viewfinder (EVF)
Intelligent Face Detection/
Red-eye removal button
Indicator lamp
USB socket/A/V OUT
EVF/LCD (monitor selector)
(Audio/Visual output) socket
button
LCD monitor
4-direction button
DISP (Display)/BACK button
Exposure compensation button
Number of images / recording time
Still image
Modes
3648×2432
Number of recorded pixels 3648×2736 (3:2 fomat) 2592×1944 2048×1536 1600×1200 640×480 Movie recording time: sec.
JPEG JPEG
Quality JPEG JPEG JPEG JPEG JPEG VGA (30 fps) QVGA (30 fps)
Fine Normal
Internal memory
5 9 11 19 30 38 170 29 sec.
(Approx. 24MB)
TM 256MB 52 103 116 202 319 399 1777 4.7 sec.
xD-Picture Card
512MB 104 207 233 404 639 799 3551 9.3 min.
18.7 min.
1GB 209 415 466 809 1279 1599 7108
2GB 418 830 927 1599 2559 3199 12796 36.8 min.
SD memory card 512MB 100 199 222 386 606 754 3438 9.0 min.
1GB 202 402 452 784 1239 1549 6885 18.1 min.
2GB 410 815 910 1569 2511 3139 12559 35.6 min.
SDHC memory card 4GB 801 1592 1776 3064 4903 6129 24518 70.5 min.*
8GB 1604 3188 3557 6137 9819 12274 49097 141.0 min.*
Actual number of frames and recording time varies depending on the types of memory card or shooting conditions.
* A movie recording will stop automatically when the movie file size becomes approx. 2GB.
OPTIONAL ACCESSORIES
xD-Picture Card™ DPC-M512 / DPC-M1GB / DPC-M2GB
PC Card Adapter DPC-AD
Compact Flash™ Card Adapter DPC-CF
AC Power Adapter AC-5VX
DC coupler CP-04
Accessory availability may vary by country.
Please check with your local Fujifilm representative to confirm product availability
ACCESSORIES INCLUDED
4×AA type Alkaline batteries / Shoulder strap / Lens cap / Lens cap cord /
USB cable / A/V cable / CD-ROM: FinePixViewer / Owner's manual
Guide to number of available frames for battery operation
Battery LCD monitor status Number of frames
4×AA type alkaline batteries LCD monitor ON Approx. 300 frames
5
According to the Camera & Imaging Products Association (CIPA) standards.*
For more information, please visit our Website:
http://www.fujifilm.com/products/digital_cameras/index.html
Specifications are subject to change without notice.
All sample photos are simulated images.
Ref. No. EB-709E
(SK·08·01·F1120·F9711) Printed in Japan©2008 FUJIFILM Corporation
Flash pop-up button
Strap mount
Microphone
Speaker
Lens
Mode dial
Continuous button
ON/OFF switch
Playback button
(Photo mode) button
MENU/OK button
Movie
46 sec.
7.4 min.
14.8 min.
29.6 min.
59.2 min.
14.3 min.
28.7 min.
57.4 min.
113.5 min. *
227.3 min. *
Compact, Lightweight,
10.0
Megapixels
12
x Zoom!
12x 2.7
Optical Zoom -Inch LCD
N E W
