D-Link DIR-855L User Manual

User manual
Hide thumbs Also See for DIR-855L:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for D-Link DIR-855L

Summary of Contents for D-Link DIR-855L

  • Page 2: Preface

    Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description November 13, 2007 DIR-855 Revision A1 with Firmware version 1.00...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Preface................i L2TP ............. 23 Manual Revisions ............. i Static (assigned by ISP) ....... 25 Trademarks ............... i Wireless Settings ..........26 802.11n/g (2.4GHz) ........26 Product.Overview............1 802.11n/a (5GHz) ......... 28 Package Contents............
  • Page 4 Table of Contents Connect.to.a.Wireless.Network......... 75 UPnP ............52 Internet Ping Block ........52 Using Windows Vista ..........75 ® Internet Port Speed ........52 Configure Wireless Security ......76 Multicast Streams ......... 52 Connect Using WCN 2.0 in Windows Vista ..

  • Page 5: Product.overview

    Secton  - Product Overvew Product Overview Package Contents D-Link.DIR-855.Xtreme.N ™ .Router ™ Power.Adapter Ethernet.Cable CD-ROM Stand Note: Using a power supply with a different voltage rating than the one included with the DIR-855 will cause damage and void the warranty for this product.

  • Page 6: System Requirements

    Secton  - Product Overvew System Requirements • An Ethernet-based Cable or DSL modem • IEEE 802.11n-draft or 802.11g wireless clients Network.Requirements • IEEE 802.11a wireless clients • 10/100/1000 Ethernet Computer.with.the.following: • Windows , Macintosh, or Linux-based operating ® system •...

  • Page 7: Introduction

    TOTAL.COVERAGE Provides greater wireless signal rates even at farther distances for best-in-class Whole Home Coverage. ULTIMATE.PERFORMANCE The D-Link Xtreme N router (DIR-855) is a draft 802.11n/802.11a compliant device that delivers real world performance ™ ™ of up to 14x faster than an 802.11g wireless connection (also faster than a 100Mbps wired Ethernet connection). Create a secure wireless network to share photos, files, music, video, printers, and network storage throughout your home.

  • Page 8: Features

    Secton  - Product Overvew Features •.Faster.Wireless.Networking - The DIR-855 provides up to 300Mbps* wireless connection with other 802.11n wireless clients. This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio. The performance of this 802.11n wireless router gives you the freedom of wireless networking at speeds 650% faster than 802.11g.

  • Page 9: Hardware Overview

    Secton  - Product Overvew Hardware Overview Connections Reset Pressing the Reset button restores the router to its original factory default settings. Connect a USB 1.1 or 2.0 flash drive to configure the wireless settings using WCN. Internet.Port LAN.Ports.(1-4) Power.Receptor The auto MDI/MDIX Internet port is Connect Ethernet devices such as Receptor for the supplied power...

  • Page 10: Leds

    Secton  - Product Overvew Hardware Overview LEDs OLED Screen Displays Internet connectivity. Menu Select to display the OLED main menu. Power.LED OLED.Screen Select to display statistics of the LAN, WAN, Performance A solid light indicates a Displays information and wireless connections. proper connection to the regarding the router.

  • Page 11: Installation

    Internet. • When running the Setup Wizard from the D-Link CD, make sure the computer you are running the CD from is connected to the Internet and online or the wizard will not work. If you have disconnected any hardware, re-connect your computer back to the modem and make sure you are online.

  • Page 12: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

  • Page 13: Network Diagram

    Secton  - Installaton Network Diagram D-Lnk DIR-855 User Manual...

  • Page 14: Connect To Cable/Dsl/Satellite Modem

    Secton  - Installaton Connect to Cable/DSL/Satellite Modem If you are connecting the router to a cable/DSL/satellite modem, please follow the steps below: 1. Place the router in an open and central location. Do not plug the power adapter into the router. 2.

  • Page 15: Connect To Another Router

    Secton  - Installaton Connect to Another Router If you are connecting the D-Link router to another router to use as a wireless access point and/or switch, you will have to do the following before connecting the router to your network: •...
  • Page 16 7. Connect an Ethernet cable in one of the LAN ports of the router and connect it to your other router. Do not plug anything into the Internet port of the D-Link router. 8. You may now use the other 3 LAN ports to connect other Ethernet devices and computers. To configure your wireless network, open a web browser and enter the IP address you assigned to the router.

  • Page 17: Getting Started

    Secton  - Installaton Getting Started The DIR-855 includes a Quick Router Setup Wizard CD. Follow the simple steps below to run the Setup Wizard to guide you quickly through the installation process. Insert the Quick.Router.Setup.Wizard.CD in the CD-ROM drive. The step-by-step instructions that follow are shown in Windows XP.

  • Page 18: Configuration

    Secton  - Configuraton Configuration This section will show you how to configure your new D-Link wireless router using the web-based configuration utility. Web-based Configuration Utility To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address of the router (192.168.0.1).

  • Page 19: Setup Wizard

    Secton  - Configuraton Setup Wizard Click Launch.Internet.Connection.Setup.Wizard to begin. If you want to enter your settings without running the wizard, click Manual.Configuration and skip to page 19. Click Next to continue. Create a new password and then click Next to continue. D-Lnk DIR-855 User Manual...
  • Page 20 Secton  - Configuraton Select your time zone from the drop-down menu and then click Next to continue. Select the type of Internet connection you use and then click Next to continue. If you selected Dynamic, you may need to enter the MAC address of the computer that was last connected directly to your modem.
  • Page 21 Secton  - Configuraton If you selected PPPoE, enter your PPPoE username and password. Click Next to continue. Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.
  • Page 22 Secton  - Configuraton If you selected Static, enter your network settings supplied by your Internet provider. Click Next to continue. Click Connect to save your settings. Once the router is finished rebooting, click Continue. Please allow 1-2 minutes to connect. Close your browser window and reopen it to test your Internet connection.

  • Page 23: Manual Configuration

    Internet experience by correcting many common typo mistakes automatically, taking you where you intended to go and saving you valuable time. Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

  • Page 24: Pppoe (Dsl)

    Secton  - Configuraton Internet Setup PPPoE (DSL) Choose PPPoE (Point to Point Protocol over Ethernet) if your ISP uses a PPPoE connection. Your ISP will provide you with a username and password. This option is typically used for DSL services. Make sure to remove your PPPoE software from your computer.

  • Page 25: Pptp

    Secton  - Configuraton Internet Setup PPTP Choose PPTP (Point-to-Point-Tunneling Protocol ) if your ISP uses a PPTP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services. Address Mode: Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses.
  • Page 26 Secton  - Configuraton DNS Servers: The DNS server information will be supplied by your ISP (Internet Service Provider.) MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1400 is the default MTU.

  • Page 27: L2Tp

    Secton  - Configuraton Internet Setup L2TP Choose L2TP (Layer 2 Tunneling Protocol) if your ISP uses a L2TP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services. Address Mode: Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses.
  • Page 28 Secton  - Configuraton MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1400 is the default MTU. Clone MAC The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not Address: recommended that you change the default MAC address unless required by your ISP.

  • Page 29: Static (Assigned By Isp)

    Secton  - Configuraton Internet Setup Static (assigned by ISP) Select Static IP Address if all the Internet port’s IP information is provided to you by your ISP. You will need to enter in the IP address, subnet mask, gateway address, and DNS address(es) provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which are four octets separated by a dot (x.x.x.x).

  • Page 30: Wireless Settings

    Secton  - Configuraton Wireless Settings 802.11n/g (2.4GHz) Enable Wireless: Check the box to enable the wireless function. If you do not want to use wireless, uncheck the box to disable all the wireless functions. Schedule: Select the time frame that you would like your wireless network enabled.
  • Page 31 Secton  - Configuraton Channel Width: Select the Channel Width: Auto.20/40 - This is the default setting. Select if you are using both 802.11n and non-802.11n wireless devices. 20MHz - Select if you are not using any 802.11n wireless clients. Visibility Status: Select Invisible if you do not want the SSID of your wireless network to be broadcasted by the DIR-855.

  • Page 32: N/A (5Ghz)

    Secton  - Configuraton Wireless Settings 802.11n/a (5GHz) Enable Wireless: Check the box to enable the wireless function. If you do not want to use wireless, uncheck the box to disable all the wireless functions. Schedule: Select the time frame that you would like your wireless network enabled.
  • Page 33 Secton  - Configuraton Channel Width: Select the Channel Width: Auto.20/40 - This is the default setting. Select if you are using both 802.11n and non-802.11n wireless devices. 20MHz - Select if you are not using any 802.11n wireless clients. Visibility Status: Select Invisible if you do not want the SSID of your wireless network to be broadcasted by the DIR-855.

  • Page 34: Network Settings

    Secton  - Configuraton Network Settings This section will allow you to change the local network settings of the router and to configure the DHCP settings. LAN Settings Router IP Address: Enter the IP address of the router. The default IP address is 192.168.0.1.

  • Page 35: Dhcp Server Settings

    Secton  - Configuraton DHCP Server Settings DHCP stands for Dynamic Host Control Protocol. The DIR-855 has a built-in DHCP server. The DHCP Server will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.”...

  • Page 36: Dhcp Reservation

    Secton  - Configuraton DHCP Reservation If you want a computer or device to always have the same IP address assigned, you can create a DHCP reservation. The router will assign the IP address only to that computer or device. Note: This IP address must be within the DHCP IP Address Range.

  • Page 37: Usb Settings

    Secton  - Configuraton USB Settings Use this section to configure your USB port. There are two configurations to choose from: Network USB and WCN Configuration. Note: If using the Network USB option, users will need to install the Network USB Utility into the computers to share the USB device through the router.

  • Page 38: Virtual Server

    Secton  - Configuraton Virtual Server The DIR-855 can be configured as a virtual server so that remote users accessing Web or FTP services via the public IP address can be automatically redirected to local servers in the LAN (Local Area Network). The DIR-855 firewall feature filters out unrecognized packets to protect your LAN network so all computers networked with the DIR-855 are invisible to the outside world.
  • Page 39 Secton  - Configuraton This will allow you to open a single port. If you would like to open a range of ports, refer to page 36. Name: Enter a name for the rule or select an application from the drop-down menu. Select an application and click <<...

  • Page 40: Port Forwarding

    Secton  - Configuraton Port Forwarding This will allow you to open a single port or a range of ports. Name: Enter a name for the rule or select an application from the drop-down menu. Select an application and click << to populate the fields. IP Address: Enter the IP address of the computer on your local network that you want to allow the incoming...

  • Page 41: Application Rules

    Secton  - Configuraton Application Rules Some applications require multiple connections, such as Internet gaming, video conferencing, Internet telephony and others. These applications have difficulties working through NAT (Network Address Translation). Special Applications makes some of these applications work with the DIR-855. If you need to run applications that require multiple connections, specify the port normally associated with an application in the “Trigger Port”...

  • Page 42: Qos Engine

    Secton  - Configuraton QoS Engine The QoS Engine option helps improve your network gaming performance by prioritizing applications. By default the QoS Engine settings are disabled and application priority is not classified automatically. Enable This option is disabled by default. Enable this StreamEngine: option for better performance and experience with online games and other interactive applications,...

  • Page 43: Network Filters

    Secton  - Configuraton Network Filters Use MAC (Media Access Control) Filters to allow or deny LAN (Local Area Network) computers by their MAC addresses from accessing the network. You can either manually add a MAC address or select the MAC address from the list of clients that are currently connected to the Broadband Router.

  • Page 44: Access Control

    Secton  - Configuraton Access Control The Access Control section allows you to control access in and out of your network. Use this feature as Parental Controls to only grant access to approved sites, limit web access based on time or dates, and/or block access from applications like P2P utilities or games.
  • Page 45 Secton  - Configuraton Enter a name for the policy and then click Next to continue. Select a schedule (I.E. Always) from the drop-down menu and then click Next to continue. Enter the following information and then click Next to continue. •...
  • Page 46 Secton  - Configuraton Select the filtering method and then click Next to continue. Enter the rule: Enable - Check to enable the rule. Name - Enter a name for your rule. Dest.IP.Start - Enter the starting IP address. Dest.IP.End - Enter the ending IP address. Protocol - Select the protocol.

  • Page 47: Website Filters

    Secton  - Configuraton Website Filters Website Filters are used to allow you to set up a list of allowed Web sites that can be used by multiple users through the network. To use this feature select to Allow or Deny, enter the domain or website and click Save.Settings. You must also select Apply.Web.Filter under the Access Control section (page 40).

  • Page 48: Inbound Filters

    Secton  - Configuraton Inbound Filters The Inbound Filter option is an advanced method of controlling data received from the Internet. With this feature you can configure inbound data filtering rules that control data based on an IP address range. Inbound Filters can be used with Virtual Server, Port Forwarding, or Remote Administration features.

  • Page 49: Firewall Settings

    Secton  - Configuraton Firewall Settings A firewall protects your network from the outside world. The DIR-855 offers a firewall type functionality. The SPI feature helps prevent cyber attacks. Sometimes you may want a computer exposed to the outside world for certain types of applications.

  • Page 50: Application Level Gateway Configuration

    Secton  - Configuraton Application Level Gateway Configuration Here you can enable or disable ALG’s. Some protocols and applications require special handling of the IP payload to make them work with network address translation (NAT). Each ALG provides special handling for a specific protocol or application.

  • Page 51: Routing

    Secton  - Configuraton Routing The Routing option is an advanced method of customizing specific routes of data through your network. Destination IP: Enter the IP address of packets that will take this route. Netmask: Enter the netmask of the route, please note that the octets must match your destination IP address.

  • Page 52: Advanced Wireless Settings

    Secton  - Configuraton Advanced Wireless Settings 802.11n/g (2.4GHz) Transmit Power: Set the transmit power of the antennas. Beacon Period: Beacons are packets sent by an Access Point to synchronize a wireless network. Specify a value. 100 is the default setting and is recommended. RTS Threshold: This value should remain at its default setting of 2432.

  • Page 53: N/A (5Ghz)

    Secton  - Configuraton Advanced Wireless Settings 802.11n/a (5GHz) Transmit Power: Set the transmit power of the antennas. Beacon Period: Beacons are packets sent by an Access Point to synchronize a wireless network. Specify a value. 100 is the default setting and is recommended. RTS Threshold: This value should remain at its default setting of 2432.

  • Page 54: Wish Settings

    Secton  - Configuraton WISH Settings WISH is short for Wireless Intelligent Stream Handling, a technology developed to enhance your experience of using a wireless network by prioritizing the traffic of different applications. Enable WISH: Enable this option if you want to allow WISH to prioritize your traffic.
  • Page 55 Secton  - Configuraton Name: Create a name for the rule that is meaningful to you. Priority: The priority of the message flow is entered here. The four priorities are defined as: BK: Background (least urgent) BE: Best Effort. VI: Video VO:.Voice (most urgent) Protocol: The protocol used by the messages.

  • Page 56: Advanced Network Settings

    Secton  - Configuraton Advanced Network Settings Enable UPnP: To use the Universal Plug and Play (UPnP ) feature ™ click on Enabled. UPNP provides compatibility with networking equipment, software and peripherals. WAN Ping: Unchecking the box will not allow the DIR-855 to respond to pings.

  • Page 57: Administrator Settings

    Secton  - Configuraton Administrator Settings This page will allow you to change the Administrator and User passwords. You can also enable Remote Management. There are two accounts that can access the management interface through the web browser. The accounts are admin and user.

  • Page 58: Time Settings

    Secton  - Configuraton Time Settings The Time Configuration option allows you to configure, update, and maintain the correct time on the internal system clock. From this section you can set the time zone that you are in and set the Time Server. Daylight Saving can also be configured to automatically adjust the time when needed.

  • Page 59: Syslog

    Secton  - Configuraton SysLog The Broadband Router keeps a running log of events and activities occurring on the Router. You may send these logs to a SysLog server on your network. Enable Logging to Check this box to send the router logs to a SysLog Server: SysLog Server.

  • Page 60: Email Settings

    Secton  - Configuraton Email Settings The Email feature can be used to send the system log files, router alert messages, and firmware update notification to your email address. Enable Email When this option is enabled, router activity logs Notification: are e-mailed to a designated email address.

  • Page 61: System Settings

    Secton  - Configuraton System Settings This section allows you to manage the router’s configuration settings, reboot the router, and restore the router to the factory default settings. Restoring the unit to the factory default settings will erase all settings, including any rules that you’ve created.

  • Page 62: Update Firmware

    You can upgrade the firmware of the Router here. Make sure the firmware you want to use is on the local hard drive of the computer. Click on Browse to locate the firmware file to be used for the update. Please check the D-Link support site for firmware updates at http://support.dlink.com.

  • Page 63: Ddns

    Secton  - Configuraton DDNS The DDNS feature allows you to host a server (Web, FTP, Game Server, etc…) using a domain name that you have purchased (www.whateveryournameis.com) with your dynamically assigned IP address. Most broadband Internet Service Providers assign dynamic (changing) IP addresses. Using a DDNS service provider, your friends can enter in your domain name to connect to your server no matter what your IP address is.

  • Page 64: System Check

    Secton  - Configuraton System Check Ping Test: The Ping Test is used to send Ping packets to test if a computer is on the Internet. Enter the IP Address that you wish to Ping, and click Ping. Ping Results: The results of your ping attempts will be displayed here.

  • Page 65: Schedules

    Secton  - Configuraton Schedules Schedules can be created for use with enforcing rules. For example, if you want to restrict web access to Mon-Fri from 3pm to 8pm, you could create a schedule selecting Mon, Tue, Wed, Thu, and Fri and enter a Start Time of 3pm and End Time of 8pm.

  • Page 66: Device Information

    Secton  - Configuraton Device Information This page displays the current information for the DIR-855. It will display the LAN, WAN (Internet), and Wireless information. If your Internet connection is set up for a Dynamic IP address then a Release button and a Renew button will be displayed.

  • Page 67: Log

    Secton  - Configuraton The router automatically logs (records) events of possible interest in it’s internal memory. If there isn’t enough internal memory for all events, logs of older events are deleted but logs of the latest events are retained. The Logs option allows you to view the router logs.

  • Page 68: Stats

    Secton  - Configuraton Stats The screen below displays the Traffic Statistics. Here you can view the amount of packets that pass through the DIR-855 on both the Internet, LAN ports and both the 802.11n/g (2.4GHz) and 802.11n/a (5GHz) wireless bands. The traffic counter will reset if the device is rebooted.

  • Page 69: Internet Sessions

    Secton  - Configuraton Internet Sessions The Internet Sessions page displays full details of active Internet sessions through your router. An Internet session is a conversation between a program or application on a LAN-side computer and a program or application on a WAN-side computer.

  • Page 70: Wireless

    Secton  - Configuraton Wireless The wireless client table displays a list of current connected wireless clients. This table also displays the connection time and MAC address of the connected wireless clients. WISH The WISH details page displays full details of wireless clients that are connected when WISH is enabled. D-Lnk DIR-855 User Manual...

  • Page 71: Support

    Secton  - Configuraton Support D-Lnk DIR-855 User Manual...

  • Page 72: Wireless.security

    Secton  - Securty Wireless Security This section will show you the different levels of security you can use to protect your data from intruders. The DIR-855 offers the following types of security: • WPA2 (Wi-Fi Protected Access 2) • WPA2-PSK (Pre-Shared Key) •...

  • Page 73: Wireless Security Setup Wizard

    Secton  - Securty Wireless Security Setup Wizard To run the security wizard, click on Setup at the top and then click Launch.Wireless.Security.Setup.Wizard. Check the Manually. set. 5GHz. band. Network. Name... box to manually set your desired wireless network name for the 5GHz band.
  • Page 74 Secton  - Securty If you selected Automatically, the summary window will display your settings. Write down the security key and enter this on your wireless clients. Click Save to save your settings. If you selected Manually, the following screen will appear. D-Lnk DIR-855 User Manual...

  • Page 75: Add Wireless Device With Wps Wizard

    Secton  - Securty Add Wireless Device with WPS Wizard From the Basic > Wizard screen, click Add.Wireless.Device. with.WPS. Select Auto to add a wireless client using WPS (Wi-Fi Protected Setup). Once you select Auto.and click.Connect, you will have a 120 second time limit to apply the settings to your wireless client(s) and successfully establish a connection.

  • Page 76: Configure Wpa-Personal (Psk)

    Secton  - Securty Configure WPA-Personal (PSK) It is recommended to enable encryption on your wireless router before your wireless network adapters. Please establish wireless connectivity before enabling encryption. Your wireless signal may degrade when enabling encryption due to the added overhead. 1..Log into the web-based configuration by opening a web browser and entering the IP address of the router (192.168.0.1).

  • Page 77: Configure Wpa-Enterprise (Radius)

    Secton  - Securty Configure WPA-Enterprise (RADIUS) It is recommended to enable encryption on your wireless router before your wireless network adapters. Please establish wireless connectivity before enabling encryption. Your wireless signal may degrade when enabling encryption due to the added overhead. 1..
  • Page 78 Secton  - Securty 8. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is the default port. 9. Next to RADIUS Server Shared Secret, enter the security key. 10. If the MAC Address Authentication box is selected then the user will need to connect from the same computer whenever logging into the wireless network.

  • Page 79: Connect.to.a.wireless.network

    Secton 5 - Connectng to a Wreless Network Connect to a Wireless Network Using Windows Vista ® Windows Vista ® users may use the built-in wireless utility. If you are using another company’s utility or Windows ® 2000, please refer to the user manual of your wireless adapter for help with connecting to a wireless network. Most utilities will have a “site survey”...

  • Page 80: Configure Wireless Security

    Secton 5 - Connectng to a Wreless Network Configure Wireless Security It is recommended to enable wireless security (WPA/WPA2) on your wireless router or access point before configuring your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
  • Page 81 Secton 5 - Connectng to a Wreless Network 3. Enter the same security key or passphrase that is on your router and click Connect. It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router.

  • Page 82: Connect Using Wcn 2.0 In Windows Vista

    Secton 5 - Connectng to a Wreless Network Connect Using WCN 2.0 in Windows Vista ® The router supports Wi-Fi protection, referred to as WCN 2.0 in Windows Vista . The following instructions for setting ® this up depends on whether you are using Windows Vista to configure the router or third party software.

  • Page 83: Using Windows ® Xp

    Secton 5 - Connectng to a Wreless Network Connect to a Wireless Network Using Windows ® Windows XP users may use the built-in wireless utility (Zero Configuration Utility). The following instructions are for ® Service Pack 2 users. If you are using another company’s utility or Windows 2000, please refer to the user manual ®...

  • Page 84: Configure Wpa-Psk

    Secton 5 - Connectng to a Wreless Network Configure WPA-PSK It is recommended to enable WPA on your wireless router or access point before configuring your wireless adapter. If you are joining an existing network, you will need to know the WPA key being used. 1..
  • Page 85 Secton 5 - Connectng to a Wreless Network 3. The Wireless. Network. Connection box will appear. Enter the WPA-PSK passphrase and click Connect. It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router.

  • Page 86: Troubleshooting

    1..Why.can’t.I.access.the.web-based.configuration.utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website on the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself.
  • Page 87 • Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your the web management.
  • Page 88 Secton  - Troubleshootng 3..Why.can’t.I.connect.to.certain.sites.or.send.and.receive.emails.when.connecting.through.my.router?. If you are having a problem sending or receiving email, or connecting to secure sites such as eBay, banking sites, and Hotmail, we suggest lowering the MTU in increments of ten (Ex. 1492, 1482, 1472, etc). Note: AOL DSL+ users must use MTU of 1400.
  • Page 89 Secton  - Troubleshootng You should start at 1472 and work your way down by 10 each time. Once you get a reply, go up by 2 until you get a fragmented packet. Take that value and add 28 to the value to account for the various TCP/IP headers. For example, lets say that 1452 was the proper value, the actual MTU size would be 1480, which is the optimum for the network we’re working with (1452+28=1480).

  • Page 90: Wireless.basics

    Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

  • Page 91: What Is Wireless

    Why.D-Link.Wireless? D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. How.does.wireless.work? Wireless works similar to how cordless phone work, through radio signals to transmit data from one point A to point B.
  • Page 92 Who.uses.wireless?. Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home • Gives everyone at home broadband access •...

  • Page 93: Tips

    The wireless connection in public places is usually called “hotspots”. Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like: Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.

  • Page 94: Wireless Modes

    Appendx A - Wreless Bascs Security Don’t let you next-door neighbors or intruders connect to your wireless network. Secure your wireless network by turning on the WPA or WEP security feature on the router. Refer to product manual for detail information on how to set it up. Wireless Modes There are basically two modes of networking: •...

  • Page 95: Networking.basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 96: Statically Assign An Ip Address

    Appendx B - Networkng Bascs Statically Assign an IP address If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below: Step.1 Windows Vista Click on Start > Control.Panel > Network.and.Internet > Network.and.Sharing.Center > Manage. ®...

  • Page 97: Technical.specifications

    Appendx C - Techncal Specficatons Technical Specifications Standards Frequency.Range • IEEE 802.11n (draft) • 2.4GHz to 2.483GHz (802.11g/n) • IEEE 802.11g • 5.15GHz to 5.825GHz (802.11a) • IEEE 802.11a • IEEE 802.3 Transmitter.Output.Power • IEEE 802.3u • 15dBm ± 2dB Security External.Antenna.Type •...

  • Page 98: Contacting.technical.support

    • Hardware Revision (located on the label on the bottom of the router (e.g. rev A2)) • Serial Number (s/n number located on the label on the bottom of the router). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.

  • Page 99: Warranty

    Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
  • Page 100 Warranty Period and is subject to the same limitations and exclusions. If a material non-conformance is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to replace the non-conforming Software, the price paid by the original licensee for the non-conforming Software will be refunded by D-Link;...
  • Page 101 • The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D-Link Systems, Inc., 17595 Mt.
  • Page 102 RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 103 Appendx E - Warranty CE.Mark.Warning: This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC.Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 104 Appendx E - Warranty ICC.Notice: Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device. IMPORTANT.NOTE: IC.Radiation.Exposure.Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.

  • Page 105: Registration

    Appendx F - Regstraton Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.3 July 9, 2009 D-Lnk DIR-855 User Manual...

This manual is also suitable for:

Dir-855
